哈尔滨蔬菜基地土壤中喹诺酮类抗生素的污染现状
Pollution Status of Quinolones Antibiotics in Soil of Harbin Vegetable Base
-
摘要: 建立超高效液相色谱-紫外检测（LC-UV）结合质谱检测（MS）法测定哈尔滨周边蔬菜基地土壤中喹诺酮类抗生素残留，并对其生态风险进行评估。样品经乙腈-磷酸盐缓冲液提取，C18固相萃取小柱富集、净化后用甲醇洗脱液进行洗脱。采用多反应监测负离子模式内标法检测蔬菜基地土壤中喹诺酮类抗生素残留。确定最佳提取条件，包括样品提取时间、温度和提取溶剂量等。4种喹诺酮类抗生素在相关范围内线性关系良好，相关系数为0.9994~0.9997。4种喹诺酮类抗生素的加标样品检测值的相对标准偏差为1.13%~2.15%，加标回收率为68.1%~80.2%。哈尔滨蔬菜基地土壤中检出的喹诺酮类抗生素残留浓度范围为21.73~132.45 μg·kg-1，双城蔬菜基地中仅检测出环丙沙星（CIP），为116.53 μg·kg-1；五常蔬菜基地检测出环丙沙星和诺氟沙星（NOR），其中环丙沙星的检出量最高，为132.45 μg·kg-1；平房蔬菜基地检测出环丙沙星和恩诺沙星（ENR），残留量分别为128.54 μg·kg-1和21.73 μg·kg-1；呼兰蔬菜基地土壤中环丙沙星、恩诺沙星、洛美沙星（LOM）和诺氟沙星均被检出，浓度分别为20.54、120.35、37.41和37.41 μg·kg-1。生态风险评估结果表明，土壤中检测出的抗生素的风险商（RQ）值均≥1，表现出高度风险，对生态系统具有潜在的不利影响。Abstract: An ultra-high performance liquid chromatography-ultraviolet detection (LC-UV) combined with mass spectrometry (MS) method was established to determine quinolone antibiotic residues in the soil of vegetable bases around Harbin, and to evaluated their ecological risks. The samples were extracted with acetonitrile-phosphate buffer, enriched and purified by C18 solid phase extraction cartridge, and eluted with methanol eluent. Multiple reaction monitoring negative ion mode internal standard method was used to detect quinolone antibiotic residues in vegetable base soil. In this experiment, the sample extraction time, temperature and extraction solvent were tested to determine the optimal extraction conditions. The four quinolone antibiotics had a good linear relationship in the relevant range, with correlation coefficients ranging from 0.9994 to 0.9997. The relative standard deviations of the spiked samples of the four quinolone antibiotics were 1.13%~2.15%, and the spiked recoveries were 68.1%~80.2%. The residual concentrations of quinolone antibiotic in the soil of Harbin vegetable base ranged from 21.73 to 132.45 μg·kg-1, and only ciprofloxacin (CIP) was detected in Shuangcheng vegetable base at 116.53 μg·kg-1. Ciprofloxacin and norfloxacin (NOR) were detected in Wuchang vegetable base, with the highest detection amount of ciprofloxacin at 132.45 μg·kg-1. Ciprofloxacin and enrofloxacin (ENR) were detected in Pingfang vegetable base, and the residues were 128.54 μg·kg-1 and 21.73 μg·kg-1, respectively. Ciprofloxacin, enrofloxacin, lomefloxacin (LOM), and norfloxacin were all detected in the soil of Hulan vegetable base, with concentrations of 20.54, 120.35, 37.41 and 37.41 μg·kg-1. The ecological risk assessment results showed that the risk quotient (RQ) values of antibiotics detected in the soil were all greater than 1, showing a high risk and potential adverse effects on ecosystems.
-
-
Zhang Q Q, Ying G G, Pan C G, et al. Comprehensive evaluation of antibiotics emission and fate in the river basins of China:Source analysis, multimedia modeling, and linkage to bacterial resistance[J]. Environmental Science & Technology, 2015, 49(11):6772-6782 Zhi S L, Shen S Z, Zhou J, et al. Systematic analysis of occurrence, density and ecological risks of 45 veterinary antibiotics:Focused on family livestock farms in Erhai Lake Basin, Yunnan, China[J]. Environmental Pollution, 2020, 267:115539 Hu Y A, Cheng H F. Elevated antimicrobial residues in animal food products call for institutional changes on veterinary drug management and animal food product surveillance in China[J]. International Journal of Antimicrobial Agents, 2018, 51(1):165-166 苏丹丹, 刘惠玲, 王梦梦. 施用粪肥蔬菜基地抗生素残留的研究进展[J]. 环境保护科学, 2015, 41(1):117-120 Su D D, Liu H L, Wang M M. Review of antibiotic residues in manure-amended vegetable fields[J]. Environmental Protection Science, 2015, 41(1):117-120(in Chinese)
Feng Y, Zhang W J, Liu Y W, et al. A simple, sensitive, and reliable method for the simultaneous determination of multiple antibiotics in vegetables through SPE-HPLC-MS/MS[J]. Molecules, 2018, 23(8):E1953 Hu X G, Zhou Q X, Luo Y. Occurrence and source analysis of typical veterinary antibiotics in manure, soil, vegetables and groundwater from organic vegetable bases, Northern China[J]. Environmental Pollution, 2010, 158(9):2992-2998 漆辉, 马莎, 张乙涵, 等. 抗生素残留在土壤环境中的行为及其生态毒性研究进展[J]. 安徽农业科学, 2011, 39(18):10906-10908 , 10951 Qi H, Ma S, Zhang Y H, et al. A review on behaviour and ecological toxicity of antibiotics residue in soil environments[J]. Journal of Anhui Agricultural Sciences, 2011, 39(18):10906-10908, 10951(in Chinese)
提清清, 高增文, 季慧慧, 等. 抗生素在土壤中的吸附行为研究进展[J]. 土壤, 2017, 49(3):437-445 Ti Q Q, Gao Z W, Ji H H, et al. Adsorption of antibiotics in soils:A review[J]. Soils, 2017, 49(3):437-445(in Chinese)
吴小莲, 莫测辉, 严青云, 等. 东莞市蔬菜基地蔬菜中喹诺酮类抗生素污染特征及健康风险[J]. 中国环境科学, 2013, 33(5):910-916 Wu X L, Mo C H, Yan Q Y, et al. Content levels and health risk of quinolone antibiotics from vegetables of Dongguan farms[J]. China Environmental Science, 2013, 33(5):910-916(in Chinese)
吴小莲, 向垒, 莫测辉, 等. 长期施用粪肥蔬菜基地蔬菜中典型抗生素的污染特征[J]. 环境科学, 2013, 34(6):2442-2447 Wu X L, Xiang L, Mo C H, et al. Concentrations of antibiotics in vegetables from manure-mended farm[J]. Environmental Science, 2013, 34(6):2442-2447(in Chinese)
郎朗, 狄静波, 王戈, 等. 哈尔滨市蔬菜基地四环素类抗生素的污染现状[J]. 环境科学与技术, 2018, 41(8):153-159 Lang L, Di J B, Wang G, et al. Study on the tetracycline antibiotics pollution in soil of vegetable bases in Harbin[J]. Environmental Science & Technology, 2018, 41(8):153-159(in Chinese)
管荷兰, 于海凤, 王嘉宇. 氟喹诺酮类抗生素在土壤中的归趋及其生态毒性研究进展[J]. 生态学杂志, 2012, 31(12):3228-3234 Guan H L, Yu H F, Wang J Y. Fate and ecological toxicity of fluoroquinolone antibiotics in soil:A review[J]. Chinese Journal of Ecology, 2012, 31(12):3228-3234(in Chinese)
谭华东, 张汇杰, 武春媛. 超声辅助提取-QuEChERS/GC-MS法快速测定土壤中六六六和滴滴涕[J]. 分析试验室, 2019, 38(11):1303-1308 Tan H D, Zhang H J, Wu C Y. Rapid determination of hexachlorocyclohexane and dichlorodiphenyltrichloroethane in soil using ultrasound-assisted QuEChERS/GC-MS[J]. Chinese Journal of Analysis Laboratory, 2019, 38(11):1303-1308(in Chinese)
邰义萍, 莫测辉, 吴小莲, 等. 绿色和有机蔬菜基地土壤中喹诺酮类抗生素的污染特征[J]. 农业环境科学学报, 2012, 31(1):125-130 Tai Y P, Mo C H, Wu X L, et al. Occurrence of quinolone antibiotics in the soils from a green and an organic vegetable fields[J]. Journal of Agro-Environment Science, 2012, 31(1):125-130(in Chinese)
陈淼, 俞花美, 葛成军, 等. 环丙沙星在热带土壤中的吸附-解吸特征研究[J]. 环境污染与防治, 2013, 35(2):38-42 , 49 Chen M, Yu H M, Ge C J, et al. Studied on the ciprofloxacin adsorption-desorption characteristics of three tropical soils[J]. Environmental Pollution & Control, 2013, 35(2):38-42, 49(in Chinese)
Gao L H, Shi Y L, Li W H, et al. Occurrence and distribution of antibiotics in urban soil in Beijing and Shanghai, China[J]. Environmental Science and Pollution Research International, 2015, 22(15):11360-11371 Wei R C, Ge F, Zhang L L, et al. Occurrence of 13 veterinary drugs in animal manure-amended soils in Eastern China[J]. Chemosphere, 2016, 144:2377-2383 潘兰佳, 唐晓达, 汪印. 畜禽粪便堆肥降解残留抗生素的研究进展[J]. 环境科学与技术, 2015, 38(S2):191-198 Pan L J, Tang X D, Wang Y. Research progress of residual antibiotics degradation in livestock and poultry feces composting[J]. Environmental Science & Technology, 2015, 38(S2):191-198(in Chinese)
Tahrani L, van Loco J, Ben Mansour H, et al. Occurrence of antibiotics in pharmaceutical industrial wastewater, wastewater treatment plant and sea waters in Tunisia[J]. Journal of Water and Health, 2016, 14(2):208-213 黄铢玉, 方龙香, 宋超, 等. 抗生素恩诺沙星在渔业中的研究进展[J]. 农学学报, 2019, 9(11):57-62 Huang Z Y, Fang L X, Song C, et al. Antibiotic enrofloxacin in fishery:A review[J]. Journal of Agriculture, 2019, 9(11):57-62(in Chinese)
Gao L H, Shi Y L, Li W H, et al. Occurrence of antibiotics in eight sewage treatment plants in Beijing, China[J]. Chemosphere, 2012, 86(6):665-671 Hu X G, Zhou Q X, Luo Y. Occurrence and source analysis of typical veterinary antibiotics in manure, soil, vegetables and groundwater from organic vegetable bases, Northern China[J]. Environmental Pollution, 2010, 158(9):2992-2998 -
