青岛某燃煤电厂排污口邻近海域表层沉积物重金属生态风险评价
Ecological Risk Assessment of Heavy Metals in Surface Sediment near A Coal-fired Power Plant Sewage Outlet in Qingdao
-
摘要: 沿海地区燃煤发电厂海水烟气脱硫系统长期、大量排放含有重金属的脱硫海水，可能会对排污口附近海域生态系统造成危害，然而目前关于这方面的研究尚少。本研究连续3年跟踪监测了该排污口附近海域表层沉积物中重金属As、Cd、Cr、Cu、Hg、Pb和Zn的含量，其平均浓度分别为3.54、0.36、26.22、18.04、0.04、24.37和47.21 mg·kg-1。为降低传统沉积物重金属风险评价过程中的不确定性，分别采用Monte Carlo模拟与沉积物质量基准(SQGs)和潜在生态风险指数(PERI)相结合的概率方法对其生态危害进行了评价。SQGs结果显示，4次监测Cu、Pb和Cd分别以50%、65%和80%的概率处于低风险，其他4种重金属以90%以上的概率处于低风险。PERI结果显示，4次监测Hg分别以34.41%、79.72%、60.39%和85.91%的概率处于中等风险，其他6种重金属的潜在生态危害均以100%的概率为轻微程度，7种重金属的综合生态危害以90%以上的概率为轻微程度。总体来讲，4次监测沉积物中重金属污染程度均为轻微，表明燃煤电厂脱硫海水的长期排放并未造成排污口附近海域表层沉积物重金属的污染。同时，本文结果表明采用Monte Carlo模拟法与传统污染指数法相结合的概率方法能够更好地表征重金属的生态危害，为工业污染水域风险缓解提供更加详细的决策支持。
-
关键词:
- 重金属 /
- 沉积物 /
- 风险评价 /
- 燃煤电厂 /
- Monte Carlo模拟
Abstract: Large amounts of waste consisting of heavy metal-containing seawater are discharged from coal-fired power plants into adjacent seas daily, which is harmful to the ecosystem of the sea near the outfall. However, very few studies have been carried out on the ecological risk of these heavy metals. This study conducted a three-year continuous monitoring to the average concentrations of heavy metals in the surface sediments of the sea located near the outfall of a coal-fired power plant in Qingdao. The average concentrations of As, Cd, Cr, Cu, Hg, Pb and Zn were 3.54, 0.36, 26.22, 18.04, 0.04, 24.37 and 47.21 mg·kg-1, respectively. In order to reduce the uncertainties in the traditional risk assessment of heavy metals in surface sediment, this study combined Monte Carlo simulations with sediment quality benchmarks (SQGs) and potential ecological risk index (PERI), respectively, to conduct the ecological risk assessment. The results of SQGs showed that, during the four sampling times, risk degrees of Cu, Pb and Cd were low with 50%, 65% and 80% probability, respectively; As, Cr, Hg, and Zn were also at the low risk degree with more than 90% probability. The PERI results showed that, during the four sampling times, the risk degree of Hg was moderate with 34.41%, 79.72%, 60.39% and 85.91% probability, respectively; the potential ecological risk degree of the other six heavy metals were low with 100% probability. The combined ecological risk of these seven heavy metals was at the low degree with more than 90% probability. In general, the heavy metal contamination degree of sediment in the four monitoring times was low, indicating that the long-term discharge of desulfurized seawater from coal-fired power plants did not cause heavy metal contamination in the surface sediments near the outfall. Meanwhile, the results of this study revolved that the probabilistic approach combining Monte Carlo simulation and traditional pollution index method can better characterize the ecological risk of heavy metals and provide a detailed decision support for the risk mitigation of industrially polluted waters.-
Key words:
- heavy metals /
- sediments /
- ecological risk assessment /
- coal-fired power plant /
- Monte Carlo simulation
-
-
Liu X Y, Sun L M, Yuan D X, et al. Mercury distribution in seawater discharged from a coal-fired power plant equipped with a seawater flue gas desulfurization system [J]. Environmental Science and Pollution Research International, 2011, 18(8): 1324-1332 Córdoba P. Status of flue gas desulphurisation (FGD) systems from coal-fired power plants: Overview of the physic-chemical control processes of wet limestone FGDs [J]. Fuel, 2015, 144: 274-286 Clarke L B. The fate of trace elements during coal combustion and gasification: An overview [J]. Fuel, 1993, 72(6): 731-736 Aunela-Tapola L, Hatanpää E, Hoffren H, et al. A study of trace element behaviour in two modern coal-fired power plants: Ⅱ. Trace element balances in two plants equipped with semi-dry flue gas desulphurisation facilities [J]. Fuel Processing Technology, 1998, 55: 13-34 Radojevi M. The use of seawater for flue gas desulphurization [J]. Environmental Technology, 1989, 10(1): 71-76 Barrero F V, Ollero P, Gutiérrez Ortiz F J, et al. Catalytic seawater flue gas desulfurization process: An experimental pilot plant study [J]. Environmental Science & Technology, 2007, 41(20): 7114-7119 Zhuang W, Gao X L. Integrated assessment of heavy metal pollution in the surface sediments of the Laizhou Bay and the coastal waters of the Zhangzi Island, China: Comparison among typical marine sediment quality indices [J]. PLoS One, 2014, 9(4): e94145 Ranjbar Jafarabadi A, Riyahi Bakhtiyari A, Shadmehri Toosi A, et al. Spatial distribution, ecological and health risk assessment of heavy metals in marine surface sediments and coastal seawaters of fringing coral reefs of the Persian Gulf, Iran [J]. Chemosphere, 2017, 185: 1090-1111 Carballeira C, De Orte M R, Viana I G, et al. Assessing the toxicity of chemical compounds associated with land-based marine fish farms: The sea urchin embryo bioassay with Paracentrotus lividus and Arbacia lixula [J]. Archives of Environmental Contamination and Toxicology, 2012, 63(2): 249-261 Garr A L. Toxicity and availability of copper and zinc to queen conch: Implications for larval recruitment in the Florida Keys [D]. Boca Raton, FL: Florida Atlantic University, 2012: 31-35 Debelius B, Forja J M, DelValls A, et al. Toxicity and bioaccumulation of copper and lead in five marine microalgae [J]. Ecotoxicology and Environmental Safety, 2009, 72(5): 1503-1513 Al-Subiai S N, Moody A J, Mustafa S A, et al. A multiple biomarker approach to investigate the effects of copper on the marine bivalve mollusc, Mytilus edulis [J]. Ecotoxicology and Environmental Safety, 2011, 74(7): 1913-1920 郭娟, 袁东星, 陈进生, 等. 燃煤电厂海水脱硫工艺的排水对海域环境的影响[J]. 环境工程学报, 2008, 2(5): 707-711 Guo J, Yuan D X, Chen J S, et al. Impact of discharge water from seawater flue gas desulfurization system of coal-fired power plant on the environment of surrounding sea area [J]. Chinese Journal of Environmental Engineering, 2008, 2(5): 707-711 (in Chinese)
Álvarez-Ayuso E, Querol X, Tomás A. Environmental impact of a coal combustion-desulphurisation plant: Abatement capacity of desulphurisation process and environmental characterisation of combustion by-products [J]. Chemosphere, 2006, 65(11): 2009-2017 Chen Y W, Liu G J, Wang L, et al. Occurrence and fate of some trace elements during pyrolysis of Yima coal, China [J]. Energy & Fuels, 2008, 22(6): 3877-3882 Liu B L, Hu K, Jiang Z L, et al. Distribution and enrichment of heavy metals in a sediment core from the Pearl River Estuary [J]. Environmental Earth Sciences, 2011, 62(2): 265-275 Sun L M, Feng L F, Yuan D X, et al. The extent of the influence and flux estimation of volatile mercury from the aeration pool in a typical coal-fired power plant equipped with a seawater flue gas desulfurization system [J]. The Science of the Total Environment, 2013, 444: 559-564 Gaur V K, Gupta S K, Pandey S D, et al. Distribution of heavy metals in sediment and water of River Gomti [J]. Environmental Monitoring and Assessment, 2005, 102(1-3): 419-433 Kowalska J B, Mazurek R, Gąsiorek M, et al. Pollution indices as useful tools for the comprehensive evaluation of the degree of soil contamination-A review [J]. Environmental Geochemistry and Health, 2018, 40(6): 2395-2420 Long E R, MacDonald D D, Smith S L, et al. Incidence of adverse biological effects within ranges of chemical concentrations in marine and estuarine sediments [J]. Environmental Management, 1995, 19(1): 81-97 MacDonald D D, Carr R S, Calder F D, et al. Development and evaluation of sediment quality guidelines for Florida coastal waters [J]. Ecotoxicology, 1996, 5(4): 253-278 Hakanson L. An ecological risk index for aquatic pollution control. A sedimentological approach [J]. Water Research, 1980, 14(8): 975-1001 Li D P, Yu R D, Chen J, et al. Ecological risk of heavy metals in lake sediments of China: A national-scale integrated analysis [J]. Journal of Cleaner Production, 2022, 334: 130206 孔令晖, 罗明科, 余辉, 等. 长江中游湖南段湖泊重金属时空累积因素研究[J]. 中国环境科学, 2023, 43(4): 1812-1823 Kong L H, Luo M K, Yu H, et al. Spatial-temporal accumulation factors of heavy metals in Hunan Lakes along the middle reach of the Yangtze River [J]. China Environmental Science, 2023, 43(4): 1812-1823 (in Chinese)
Su L Y, Liu J L, Christensen P. Spatial distribution and ecological risk assessment of metals in sediments of Baiyangdian wetland ecosystem [J]. Ecotoxicology, 2011, 20(5): 1107-1116 Pejman A, Nabi Bidhendi G, Ardestani M, et al. A new index for assessing heavy metals contamination in sediments: A case study [J]. Ecological Indicators, 2015, 58: 365-373 Bai J H, Cui B S, Chen B, et al. Spatial distribution and ecological risk assessment of heavy metals in surface sediments from a typical plateau lake wetland, China [J]. Ecological Modelling, 2011, 222(2): 301-306 National Research Council (NRC). Science and judgment in risk assessment [R]. Washington DC: National Academy Press, 1994 United States Environmental Protection Agency (US EPA). Guiding principles for Monte Carlo analysis [R]. Washington DC: US EPA, 1997 Taylor M R G, Heaton R, Baty R. The impact of flue-gas desulphurization on the water environment [J]. Water and Environment Journal, 1989, 3(3): 227-234 王云鹏, 纪良, 时国梁, 等. 脱硫海水排放对附近海域的生态环境影响初步研究[J]. 中国海洋大学学报(自然科学版), 2014, 44(5): 61-68 Wang Y P, Ji L, Shi G L, et al. A preliminary study of the impact of discharge water from seawater flue gas desulphurization on the ecological environment of surrounding sea area [J]. Periodical of Ocean University of China, 2014, 44(5): 61-68 (in Chinese) McCready S, Birch G F, Long E R. Metallic and organic contaminants in sediments of Sydney Harbour, Australia and vicinity—A chemical dataset for evaluating sediment quality guidelines [J]. Environment International, 2006, 32(4): 455-465 Christophoridis C, Dedepsidis D, Fytianos K. Occurrence and distribution of selected heavy metals in the surface sediments of Thermaikos Gulf, N. Greece. Assessment using pollution indicators [J]. Journal of Hazardous Materials, 2009, 168(2-3): 1082-1091 Qu C S, Li B, Wu H S, et al. Probabilistic ecological risk assessment of heavy metals in sediments from China’s major aquatic bodies [J]. Stochastic Environmental Research and Risk Assessment, 2016, 30(1): 271-282 Li X, Chi W Q, Tian H, et al. Probabilistic ecological risk assessment of heavy metals in western Laizhou Bay, Shandong Province, China [J]. PLoS One, 2019, 14(3): e0213011 Wang X C, Feng H, Ma H Q. Assessment of metal contamination in surface sediments of Jiaozhou Bay, Qingdao, China [J]. CLEAN - Soil, Air, Water, 2007, 35(1): 62-70 张珂, 王朝晖, 冯杰, 等. 胶州湾表层沉积物重金属分布特征及污染评价[J]. 分析测试学报, 2011, 30(12): 1406-1411 Zhang K, Wang Z H, Feng J, et al. Distribution and pollution assessment of heavy metals in surface sediments of Jiaozhou Bay [J]. Journal of Instrumental Analysis, 2011, 30(12): 1406-1411 (in Chinese)
郭军辉, 殷月芬, 陈发荣, 等. 胶州湾表层沉积物重金属污染分布特征及其生态风险评价[J]. 环境污染与防治, 2012, 34(3): 13-21 Guo J H, Yin Y F, Chen F R, et al. The distribution characteristics of heavy metals in sediments of Jiaozhou Bay and its potential ecological risk evaluation [J]. Environmental Pollution & Control, 2012, 34(3): 13-21 (in Chinese)
李玉, 俞志明, 曹西华, 等. 重金属在胶州湾表层沉积物中的分布与富集[J]. 海洋与湖沼, 2005, 36(6): 580-589 Li Y, Yu Z M, Cao X H, et al. Distribution and enrichment of heavy metals in surface sediments of Jiaozhou Bay [J]. Oceanologia et Limnologia Sinica, 2005, 36(6): 580-589 (in Chinese)
魏璟弢, 张焕玲, 李铁, 等. 胶州湾及青岛近海表层沉积物重金属赋存形态研究[J]. 中国海洋大学学报(自然科学版), 2012, 42(S1): 157-164 Wei J T, Zhang H L, Li T, et al. Study of the geochemical forms of heavy metals in surface sediments of Jiaozhou Bay and Qingdao inshore areas [J]. Periodical of Ocean University of China, 2012, 42(S1): 157-164 (in Chinese) Feng Y L, Chen Y Z, Wang J, et al. Ecological risk assessment of heavy metals in surface seawater and sediment near the outlet of a zinc factory in Huludao City, Liaoning Province, China [J]. Chinese Journal of Oceanology and Limnology, 2016, 34(6): 1320-1331 Yu R L, Yuan X, Zhao Y H, et al. Heavy metal pollution in intertidal sediments from Quanzhou Bay, China [J]. Journal of Environmental Sciences (China), 2008, 20(6): 664-669 Liang Y, Liu X Y, Yuan D X, et al. Mercury species in seawater and sediment of Xiamen western sea area adjacent to a coal-fired power plant [J]. Water Environment Research: A Research Publication of the Water Environment Federation, 2010, 82(4): 335-341 迟清华, 鄢明才. 应用地球化学元素丰度数据手册[M]. 北京: 地质出版社, 2007: 67-75 Sawe S F, Shilla D A, Machiwa J F. Assessment of ecological risk of heavy metals using probabilistic risk assessment model (AQUARISK) in surface sediments from Wami Estuary, Tanzania [J]. BioMed Research International, 2021, 2021: 6635903 周林军, 冯洁, 刘济宁, 等. 污水处理厂中化学品暴露预测模型研究进展[J]. 环境科学与技术, 2015, 38(8): 68-74 Zhou L J, Feng J, Liu J N, et al. Models of exposure prediction for chemicals in the sewage treatment plant: A review [J]. Environmental Science & Technology, 2015, 38(8): 68-74 (in Chinese)
Chen C W, Kao C M, Chen C F, et al. Distribution and accumulation of heavy metals in the sediments of Kaohsiung Harbor, Taiwan [J]. Chemosphere, 2007, 66(8): 1431-1440 Zhou F, Guo H C, Hao Z J. Spatial distribution of heavy metals in Hong Kong’s marine sediments and their human impacts: A GIS-based chemometric approach [J]. Marine Pollution Bulletin, 2007, 54(9): 1372-1384 Romano E, Ausili A, Zharova N, et al. Marine sediment contamination of an industrial site at Port of Bagnoli, Gulf of Naples, Southern Italy [J]. Marine Pollution Bulletin, 2004, 49(5-6): 487-495 de Carvalho Gomes F, Godoy J M, Godoy M L, et al. Metal concentrations, fluxes, inventories and chronologies in sediments from Sepetiba and Ribeira Bays: A comparative study [J]. Marine Pollution Bulletin, 2009, 59(4-7): 123-133 -
