典型pH条件下水中离子对腐殖酸絮凝体构造的影响

,  ,

downloadPDF

上一篇

下一篇

冯永宁, 金鹏康, 王晓昌. 典型pH条件下水中离子对腐殖酸絮凝体构造的影响[J]. 环境化学, 2013, 32(6): 1088-1093. doi: 10.7524/j.issn.0254-6108.2013.06.026
引用本文: 冯永宁, 金鹏康, 王晓昌. 典型pH条件下水中离子对腐殖酸絮凝体构造的影响[J]. 环境化学, 2013, 32(6): 1088-1093. doi: 10.7524/j.issn.0254-6108.2013.06.026
shu
FENG Yongning, JIN Pengkang, WANG Xiaochang. Effects of ion in water on humic acid floc structure under typical pH conditions[J]. Environmental Chemistry, 2013, 32(6): 1088-1093. doi: 10.7524/j.issn.0254-6108.2013.06.026
Citation: FENG Yongning, JIN Pengkang, WANG Xiaochang. Effects of ion in water on humic acid floc structure under typical pH conditions[J]. Environmental Chemistry, 2013, 32(6): 1088-1093. doi: 10.7524/j.issn.0254-6108.2013.06.026
shu

典型pH条件下水中离子对腐殖酸絮凝体构造的影响

  • 1.

    西安建筑科技大学环境与市政工程学院, 710055, 西安

  • 基金项目:

    国家自然科学基金项目(50978211)资助.

Effects of ion in water on humic acid floc structure under typical pH conditions

  • 1.

    School of Environmental & Municipal Engineering, Xi'an University of Architecture & Technology, Xi'an, 710055, China

  • Fund Project:

  • 摘要: 分析评价了几种典型化学条件对腐殖酸絮凝体构造的影响.研究结果表明,在pH=5.0低投药量下以共聚络合为主要混凝机理所形成的絮凝体结构密实,粒径分布均匀,强度大.而pH=5高投药量以及pH=7.0两种情况下的混凝机理都是以吸附和网扫絮凝为主,此时形成的絮凝体构造特征相似,尽管尺寸较大,但是结构松散,强度较小.针对水中常见的主量阴阳离子,分析探讨了典型离子对絮凝体构造特征的影响.研究表明,Cl-在腐殖酸水样中的存在对絮凝体构造基本没有影响,而SO42-和SiO32-在水样中的存在可使腐殖酸絮凝体尺寸增加0.05-0.13 mm左右,但结构比较开放松散,同时絮凝体的黏结力(即抗剪切力)大大削弱,降低了约0.018-0.047 N·m-2,并且SO42-对腐殖酸絮体构造的影响大于SiO32-对其的影响.然而,引入阳离子会对絮凝体的构造起到不同程度的改善作用.其中以Ca2+、Mg2+为代表的高价阳离子对絮凝体构造影响较大,形成的絮凝体结构密实,尺寸较大,抗剪切能力强.高价阳离子的存在会使絮凝体的粒径增加0.08-0.15 mm,抗剪切力增加0.002-0.013 N·m-2,而以K+、Na+为代表的低价阳离子对絮凝体构造的影响较小.
    Abstract: The influence of several typical chemical conditions on the structure characteristics of humic acid flocs was evaluated in this paper. The results indicate that flocs formed by co-precipitation at pH 5 with low dosage had a compact structure, high strength and uniform particle distribution. Flocs formed by adsorption and sweep flocculation at pH 5 with high dosage and pH 7 showed similar structure characteristics, with a large size, loose structure and lower strength. The effect of typical ions on floc structure was also analyzed and discussed. The results show that Cl- had little effect on floc structure, whereas SO42- and SiO32- existing in humic acid water samples lead to increased flocs size by 0.05-0.13 mm and a looser structure. Moreover, the bonding force of flocs was greatly weakened, and reduce by about 0.018-0.047 N·m-2. The influence of SO42- on floc structure was greater than that of SiO32-. However, dosing cations improvd floc structure to varying degrees. High valence cations such as Ca2+,Mg2+ had a notable effect on the floc structure. Flocs formed after dosing Ca2++Mg2+ were compact and large with a strong shearing resisting ability. They lead to increase of floc size and strength by 0.08-0.15mm and 0.002-0.013 N·m-2 respectively. The influence of low valence cations K+ +Na+ on floc structure was less.
  • 加载中
  • [1] 金鹏康,王晓昌. 腐殖酸絮凝体的形态学特征和混凝化学条件[J]. 环境科学学报, 2001, 21(增刊): 23-29
    [2] 王晓昌,丹保宪仁. 絮凝体形态学和密度的探讨-(Ⅰ)从絮凝体分形构造谈起[J]. 环境科学学报, 2000, 20(3):257-262
    [3] Spicer P T, Pratsinis S E, Raper J, et al. Effect of shear schedule on particle size, density, and structure during flocculation in stirred tanks [J]. Powder technology, 1998, 97(1): 26-34
    [4] Logan B E, Kilps J R. Fractal dimensions of aggregates formed in different fluid mechanical environments [J]. Water Research, 1995, 29(2): 443-453
    [5] Jiang Q, Logan B E. Fractal dimensions of aggregates from shear devices [J]. Journal-American Water Works Association, 1996, 88(2): 100-113
    [6] Gregory D, Carlson K. Relationship of pH and floc formation kinetics to granular media filtration performance [J]. Environmental Science Technology, 2003, 37(7): 1398-1403
    [7] 武若冰, 王东升, 李涛. 絮体性能及其工艺调控的研究与进展[J]. 环境科学学报, 2008, 28(4): 593-598
    [8] 张利田,陈静生. 我国河水主要离子组成与区域自然条件的关系[J]. 地理科学, 2000, 20(3): 236-240
    [9] 王亚军,王岚,许春雪,等.长江水系水文地球化学特征及主要离子的化学成因[J]. 地质通报, 2010, 29(2/3): 446

    -456

    [10] 李思悦, 谭香, 徐志方, 等. 湖北丹江口水库主要离子化学季节变化及离子来源分析[J]. 环境科学, 2008, 29(12):3353-3359
    [11] 夏学齐, 杨忠芳, 王亚平, 等. 长江水系河水主要离子化学特征[J]. 地学前缘, 2008, 15:194-202
    [12] 王晓昌, 金鹏康, 周兰. 水中天然有机物的光学在线监测及控制[J]. 环境科学学报, 2002, 22(1): 6-11
    [13] 金鹏康, 王晓昌. 腐殖酸混凝过程FI曲线的特征参数分析[J]. 环境科学学报, 2002, 22(4): 423-427
    [14] 金鹏康, 佘静静, 刘岚, 等. 典型pH 条件下腐殖酸混凝特性研究[J]. 西安建筑科技大学学报, 2011, 43(2): 215-219
    [15] Wang X C, Jin P K, Gregory J. Structure of Al-humic flocs and their removal at slightly acidic and neutral pH[J]. Water Science and Technology: Water Supply 2002, 2(2): 99-106
    [16] Chakraborti R K, Gardner K H, Atkinson J F, et al. Changes in fractal dimension during aggregation [J]. Water Research, 2003, 37(4): 873-883
    [17] Li T, Zhu Z, Wang D S, et al. Characterization of floc size, strength and structure under various coagulation mechanisms [J]. Powder Technology, 2006, 168(2): 104-110
    [18] Jin P K, Wang X C, Chai H X. Evaluation of floc strength by morphological analysis and PDA online monitoring [J]. Water Science and Technology, 2007, 56(10): 117-124
    [19] 金鹏康, 冯永宁, 王宝宝, 等. 基于光学在线监测及形态学研究的絮凝体强度分析方法[J]. 环境科学, 2013, 34(5): 164-169
    [20] Benschoten J E, Edzwald J K. Chemical aspects of coagultion using aluminum salts-I. Hydrolytic reactions of alum and polyaluminum chloride[J]. Water Research, 1990, 24(12): 1519-1526
    [21] Benschoten J E, Edwards J K. Chemical aspects of coagulation using aluminum salts-Ⅱ. Coagulation of fulvic acid using alum and polyaluminum chloride[J]. Water Research, 1990, 24(12): 1527-1535
    [22] Jin P K, Zhang K, Wang X C. Fractal characteristics of Al-humic flocs[J]. Desalination & Water Treatment, 2012, 42(2012): 309-316
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1456
  • HTML全文浏览数:  1430
  • PDF下载数:  514
  • 施引文献:  0
出版历程
  • 收稿日期:  2012-08-22
冯永宁, 金鹏康, 王晓昌. 典型pH条件下水中离子对腐殖酸絮凝体构造的影响[J]. 环境化学, 2013, 32(6): 1088-1093. doi: 10.7524/j.issn.0254-6108.2013.06.026
引用本文: 冯永宁, 金鹏康, 王晓昌. 典型pH条件下水中离子对腐殖酸絮凝体构造的影响[J]. 环境化学, 2013, 32(6): 1088-1093. doi: 10.7524/j.issn.0254-6108.2013.06.026
shu
FENG Yongning, JIN Pengkang, WANG Xiaochang. Effects of ion in water on humic acid floc structure under typical pH conditions[J]. Environmental Chemistry, 2013, 32(6): 1088-1093. doi: 10.7524/j.issn.0254-6108.2013.06.026
Citation: FENG Yongning, JIN Pengkang, WANG Xiaochang. Effects of ion in water on humic acid floc structure under typical pH conditions[J]. Environmental Chemistry, 2013, 32(6): 1088-1093. doi: 10.7524/j.issn.0254-6108.2013.06.026
shu

典型pH条件下水中离子对腐殖酸絮凝体构造的影响

  • 1. 西安建筑科技大学环境与市政工程学院, 710055, 西安
  • 收稿日期:  2012-08-22
基金项目:

国家自然科学基金项目(50978211)资助.

摘要: 分析评价了几种典型化学条件对腐殖酸絮凝体构造的影响.研究结果表明,在pH=5.0低投药量下以共聚络合为主要混凝机理所形成的絮凝体结构密实,粒径分布均匀,强度大.而pH=5高投药量以及pH=7.0两种情况下的混凝机理都是以吸附和网扫絮凝为主,此时形成的絮凝体构造特征相似,尽管尺寸较大,但是结构松散,强度较小.针对水中常见的主量阴阳离子,分析探讨了典型离子对絮凝体构造特征的影响.研究表明,Cl-在腐殖酸水样中的存在对絮凝体构造基本没有影响,而SO42-和SiO32-在水样中的存在可使腐殖酸絮凝体尺寸增加0.05-0.13 mm左右,但结构比较开放松散,同时絮凝体的黏结力(即抗剪切力)大大削弱,降低了约0.018-0.047 N·m-2,并且SO42-对腐殖酸絮体构造的影响大于SiO32-对其的影响.然而,引入阳离子会对絮凝体的构造起到不同程度的改善作用.其中以Ca2+、Mg2+为代表的高价阳离子对絮凝体构造影响较大,形成的絮凝体结构密实,尺寸较大,抗剪切能力强.高价阳离子的存在会使絮凝体的粒径增加0.08-0.15 mm,抗剪切力增加0.002-0.013 N·m-2,而以K+、Na+为代表的低价阳离子对絮凝体构造的影响较小.
