Pt/BiVO4光催化剂的制备及其光催化降解性能

,  ,  ,  ,

downloadPDF

上一篇

下一篇

张中杰, 关卫省, 孙绍芳, 吴亚帆, 卢昶雨. Pt/BiVO4光催化剂的制备及其光催化降解性能[J]. 环境化学, 2014, 33(6): 1003-1009. doi: 10.7524/j.issn.0254-6108.2014.06.003
引用本文: 张中杰, 关卫省, 孙绍芳, 吴亚帆, 卢昶雨. Pt/BiVO4光催化剂的制备及其光催化降解性能[J]. 环境化学, 2014, 33(6): 1003-1009. doi: 10.7524/j.issn.0254-6108.2014.06.003
shu
ZHANG Zhongjie, GUAN Weisheng, SUN Shaofang, WU Yafan, LU Changyu. Preparation of Pt/BiVO4 and its photocatalytic activity for the degradation of tetracycline[J]. Environmental Chemistry, 2014, 33(6): 1003-1009. doi: 10.7524/j.issn.0254-6108.2014.06.003
Citation: ZHANG Zhongjie, GUAN Weisheng, SUN Shaofang, WU Yafan, LU Changyu. Preparation of Pt/BiVO4 and its photocatalytic activity for the degradation of tetracycline[J]. Environmental Chemistry, 2014, 33(6): 1003-1009. doi: 10.7524/j.issn.0254-6108.2014.06.003
shu

Pt/BiVO4光催化剂的制备及其光催化降解性能

  • 1.

    长安大学环境科学与工程学院, 西安, 710054

  • 基金项目:

    高等学校博士学科点专项科研基金（20110205110014）；中央高校基本科研业务费专项资金项目.

Preparation of Pt/BiVO4 and its photocatalytic activity for the degradation of tetracycline

  • 1.

    School of Environmental Science and Engineering, Chang'an University, Xi'an, 710054, China

  • Fund Project:

  • 摘要: 采用微波法和光还原沉积法制备了一系列不同Pt含量的Pt/BiVO4光催化剂.采用X射线衍射仪（XRD）、X射线能谱仪（EDS）、透射电子显微镜（TEM）、X射线光电子能谱（XPS）和紫外可见漫反射（UV-vis）对样品进行表征，并以氙灯为光源，四环素为目标污染物，对该光催化剂在可见光（λ>420 nm）下的光催化降解活性进行了评价.实验结果表明，当Pt含量为2wt%时，Pt/BiVO4光催化剂在可见光照射60min条件下对四环素的降解效率达到了87.5%，明显高于纯BiVO4 22.7%的降解效率.沉积适量的Pt，能显著抑制光生电子与空穴的复合，提高光催化活性.
    Abstract: A series of novel Pt/BiVO4 photocatalysts were synthetized by microwave method and photoreduction deposition process. The prepared photocatalysts were characterized by XRD, EDS, TEM, XPS and UV-vis absorption spectroscopy. The photocatalytic activity of the synthesized products was evaluated by the degradation of tetracycline(TC) under a Xenon lamp irradiation(cut off λ≤420 nm light through an optical filter).Compared with pure BiVO4, Pt/BiVO4 photocatalysts showed enhanced photocatalytic degradation activities for TC under visible-light irradiation. Particularly, when Rw(Pt/BiVO4) was 2%, the products exhibited the highest TC degradation ratio of 87.5% in 60 min. The degradation ratio of 2wt% Pt/BiVO4 was higher than the single-phase BiVO4 (22.7%).The enhanced photocatalytic activity was mainly attributed to the presence of Pt nanoparticles, which suppressed the recombination of photogenerated electrons and holes, and promoted the efficiency of electron-hole separation.
  • 加载中
  • [1] Navarro Yerga R M, Álvarez Galván M C, Del Valle F, et al. Water splitting on semiconductor catalysts under visible-light irradiation[J]. Chemsuschem, 2009, 2(6):471-485
    [2] Hoffmann M R, Martin S T, Choi W, et al. Environmental applications of semiconductor photocatalysis[J]. Chemical Reviews, 1995, 95(1):69-96
    [3] Beydoun D, Amal R, Low G, et al. Role of nanoparticles in photocatalysis[J]. Journal of Nanoparticle Research, 1999, 1 (4):439-458
    [4] Paul T, Dodd M C, Strathmann T J. Photolytic and photocatalytic decomposition of aqueous ciprofloxacin: Transformation products and residual antibacterial activity[J]. Water Research, 2010, 44(10):3121-3132
    [5] Yan Y, Liu X L, Fan W Q, et al. InVO4 microspheres: Preparation, characterization and visible-light-driven photocatalytic activities[J]. Chemical Engineering Journal, 2012, 200:310-316
    [6] Zhang X F, Gong Y, Dong X L, et al. Fabrication and efficient visible light-induced photocatalytic activity of Bi2WO6/BiVO4 heterojunction[J]. Materials Chemistry and Physics, 2012, 136(2/3):472-476
    [7] Kohtani S, Koshiko M, Kudo A, et al. Photodegradation of 4-alkylphenols using BiVO4 photocatalyst under irradiation with visible light from a solar simulator[J]. Applied Catalysis B-Environmental, 2003, 46(3):573-586
    [8] Castillo N C, Ding L, Heel A, et al. On the photocatalytic degradation of phenol and dichloroacetate by BiVO4: The need of a sacrificial electron acceptor[J]. Journal of Photochemistry and Photobiology A: Chemistry, 2010, 216(2):221-227
    [9] Xie B P, Zhang H X, Cai P X, et al. Simultaneous photocatalytic reduction of Cr(Ⅵ) and oxidation of phenol over monoclinic BiVO4 under visible light irradiation[J]. Chemosphere, 2006, 63(6): 956-963
    [10] Kohtani S, Hiro J, Yamamoto N, et al. Adsorptive and photocatalytic properties of Ag-loaded BiVO4on the degradation of 4-n-alkylphenols under visible light irradiation[J]. Catalysis Communications, 2005, 6 (3):185-189
    [11] Gao X M, Fu F, Li W H. Photocatalytic degradation of phenol over Cu loading BiVO4 metal composite oxides under visible light irradiation[J]. Physica B-Condensed Matter, 2013, 412:26-31
    [12] Liu K J, Chang Z D, Li W J, et al. Preparation, characterization of Mo, Ag-loaded BiVO4 and comparison of their degradation of methylene blue[J]. Science China-Chemistry, 2012, 55(9):1770-1775
    [13] 戈磊.新型Pt/BiVO4可见光活性光催化剂的制备和表征[J].无机材料学报, 2008, 23(2):449-453
    [14] Teoh W Y, Mdler L, Amal R. Inter-relationship between Pt oxidation states on TiO2 and the photocatalytic mineralisation of organic matters[J].Journal of Catalysis, 2007, 251(2):271-280
    [15] Zheng X J, Wei L F, Zhang Z H, et al. Research on photocatalytic H2 production from acetic acid solution by Pt/TiO2 nanoparticles under UV irradiation[J]. International Journal of Hydrogen Energy, 2009, 34(22): 9033-9041
    [16] Zhao Q, Li M, Chu J Y, et al. Preparation, characterization of Au (or Pt)-loaded titania nanotubes and their photocatalytic activities for degradation of methyl orange[J]. Applied Surface Science, 2009, 255(6):3773-3778
    [17] Buttler M A. Photoelectrolysis and physical properties of the semiconducting electrode WO2[J]. Journal of Applied Physics, 1977, 48(5):1914-1920
    [18] Yu J Q, Kudo A. Effects of structural variation on the photocatalytic performance of hydrothermally synthesized BiVO4[J]. Advanced Functional Materials, 2006, 16(16):2163-2169
    [19] Zhao W R, Wang Y, Yang Y, et al. Carbon spheres supported visible-light-driven CuO-BiVO4 heterojunction: Preparation, characterization, and photocatalytic properties[J]. Applied Catalysis B-Environmental, 2012, 115:90-99
    [20] 余长林, 陈建钗, 操芳芳, 等.Pt/BiOCl 纳米片的制备、表征及其光催化性能[J].催化学报, 2013, 34(2):385-390
    [21] Yan X, Sun S F, Hu B, et al. Enhanced photocatalytic activity induced by surface plasmon resonance on Ag-loaded strontium titanate nanoparticles[J]. Micro & Nano Letters, 2013, 8(9):504-507
    [22] Yu J G, Ma T T, Liu S W. Enhanced photocatalytic activity of mesoporous TiO2 aggregates by embedding carbon nanotubes as electron-transfer channel[J]. Physical Chemistry Chemical Physics, 2011, 13(8):3491-3501
    [23] Buxton G V, Greenstock C L, Helman W P, et al. Critical review of rate constants for reactions of hydrated electrons, hydrogen atoms and hydroxyl radicals (·OH/·O-) in aqueous solution[J]. Journal of Physical and Chemical Reference Data, 1988, 17(2):514-886
    [24] 汪宁改, 李国亭, 刘秉涛, 等, 紫外光照射下铁锰物种对酸性橙Ⅱ的脱色研究[J].环境化学, 2009, 28(2):242-246
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1061
  • HTML全文浏览数:  1061
  • PDF下载数:  554
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-09-12
张中杰, 关卫省, 孙绍芳, 吴亚帆, 卢昶雨. Pt/BiVO4光催化剂的制备及其光催化降解性能[J]. 环境化学, 2014, 33(6): 1003-1009. doi: 10.7524/j.issn.0254-6108.2014.06.003
引用本文: 张中杰, 关卫省, 孙绍芳, 吴亚帆, 卢昶雨. Pt/BiVO4光催化剂的制备及其光催化降解性能[J]. 环境化学, 2014, 33(6): 1003-1009. doi: 10.7524/j.issn.0254-6108.2014.06.003
shu
ZHANG Zhongjie, GUAN Weisheng, SUN Shaofang, WU Yafan, LU Changyu. Preparation of Pt/BiVO4 and its photocatalytic activity for the degradation of tetracycline[J]. Environmental Chemistry, 2014, 33(6): 1003-1009. doi: 10.7524/j.issn.0254-6108.2014.06.003
Citation: ZHANG Zhongjie, GUAN Weisheng, SUN Shaofang, WU Yafan, LU Changyu. Preparation of Pt/BiVO4 and its photocatalytic activity for the degradation of tetracycline[J]. Environmental Chemistry, 2014, 33(6): 1003-1009. doi: 10.7524/j.issn.0254-6108.2014.06.003
shu

Pt/BiVO4光催化剂的制备及其光催化降解性能

  • 1. 长安大学环境科学与工程学院, 西安, 710054
  • 收稿日期:  2013-09-12
基金项目:

高等学校博士学科点专项科研基金（20110205110014）；中央高校基本科研业务费专项资金项目.

摘要: 采用微波法和光还原沉积法制备了一系列不同Pt含量的Pt/BiVO4光催化剂.采用X射线衍射仪（XRD）、X射线能谱仪（EDS）、透射电子显微镜（TEM）、X射线光电子能谱（XPS）和紫外可见漫反射（UV-vis）对样品进行表征，并以氙灯为光源，四环素为目标污染物，对该光催化剂在可见光（λ>420 nm）下的光催化降解活性进行了评价.实验结果表明，当Pt含量为2wt%时，Pt/BiVO4光催化剂在可见光照射60min条件下对四环素的降解效率达到了87.5%，明显高于纯BiVO4 22.7%的降解效率.沉积适量的Pt，能显著抑制光生电子与空穴的复合，提高光催化活性.
