初期采煤沉陷积水区底泥及周边土壤覆水条件下营养盐释放潜能
Nutrient release potential of sediment and its adjacent inundated soils in the initial-stage of coal Mine subsidence waters
-
摘要: 选择淮南矿区典型采煤沉陷积水区作为研究对象，以周边农田土壤作为对比，采用静态培养柱进行了底泥营养盐的释放潜能实验，设定好氧、缺氧两种条件，通过测定在240 h内上覆水中pH、氧化还原电位（ORP）、溶解氧（DO）、NH4+、NO2-、NO3-、PO43-和总有机碳（TOC）的浓度值，研究了沉陷积水区底泥及周边土壤中营养盐向上覆水的释放潜能.结果表明，在积水初期，上覆水pH、ORP、DO等对底泥中氮、磷及有机物的富集与释放起着重要的作用，底泥会释放以NH4+为主的无机氮，厌氧条件下氨化作用更强烈，而好氧、厌氧两种条件土壤培养柱中无机氮和总氮均是从上覆水向土壤富集.采煤沉陷积水区底泥向上覆水释磷，而土壤淹水后好氧、厌氧两种条件下均不释放磷.综合来看，积水初期沉陷积水区低水位（2-5 m）条件下的好氧环境有利于上覆水中的有机物、氮、磷元素向底泥富集，内源负荷潜能较低.Abstract: A typical subsidence water area was chosen to evaluate its nutrient release potential of sediment during the initial-stage of coal mine subsidence processes in Huainan Coal Mine areas. Sediment samples were collected to conduct simulation experiments for nutrient release in contrast with surrounding soils in agriculture. Water parameters in the overlying water, including pH、ORP、DO、NH4+、NO2-、NO3-、PO43- and TOC, were monitored during a period of 240 hours. It was found that the parameters of pH, ORP and DO in the overlying water played important roles in controlling the release of nitrogen, phosphorus and organic matters. Sediments released nitrogen in the form of ammonia, especially under anaerobic conditions. On the contrary, sediment enriched nitrogen from the overlying water under both anaerobic and aerobic conditions. Sediments showed phosphorus release potential while inundated soils didn't. During the initial stage in the waters of subsidence processes, low water depth (2-5 m) and intensive mixing aerobic environments would promote concentration of organic matters, nitrogen, phosphorus from overlying water to sediment, resulting in less risk of nutrient internal loading.
-
Key words:
- subsidence water area of coal mine /
- sediment /
- soil /
- nutrient /
- release possibility
-
-
[1] 王振龙,章启兵,李瑞.采煤沉陷区雨洪利用与生态修复技术研究[J].自然资源学报,2009,24(7):1155-1162. WANG Z L,ZHANG Q B,LI R.Study on rain-flood resources comprehensive utilization and ecological restoration technology of coal mining depressed area[J].Journal of Natural Resources,2009,24(7):1155-1162(in Chinese).
[2] 方创琳,毛汉英.兖腾两淮地区采煤塌陷地的动态演变规律与综合整治[J].地理学报,1998,53(1):24-31. FANG C L,MAO H Y.The negative effects,evolutionary patterns and comprehensive management of coal mining areas in Yanteng Lianghuai region[J].Acta Geographica Sinica,1998,53(1):419-422(in Chinese).
[3] FAN T Y,YAN J P,WANG S,et al.Water quality variation of mining-subsidence lake during the initial stage-case of Zhangji and Guqiao Mine[J].Journal of Coal Science&Engineering,2012,18(3):297-301. [4] 范廷玉,严家平,王顺,等.采煤沉陷水域底泥及周边土壤性质差异分析及其环境意义[J].煤炭学报,2014,39(10):2075-2082. FAN T Y,YAN J P,WANG S,et al.Difference between sediment samples from coal mine subsidence water and soil samples around it and its environment significance[J].Journal of China Coal Society,2014,39(10):2075-2082(in Chinese).
[5] XIE K,Zhang Y Q,YI Q T et al.Optimal resource utilization and ecological restoration of aquatic zones in the coal mining subsidence areas of the Huaibei Plain in Anhui Province,China[J].Desalination and Water Treatment,2013,51(19/20):4019-4027. [6] YANG J L,ZHANG,G L,SHI X Z,et al.Dynamic changes of nitrogen and phosphorus losses in ephemeral runoff processes by typical storm events in Sichuan Basin,Southwest China[J].Soil and Tillage Research,2009,105(2):292-299. [7] COLLOFF M J,WAKELIN S A,GOMEZ D,et al.Detection of nitrogen cycle genes in soils for measuring the effects of changes in land use and management[J].Soil Biology and Biochemistry,2008,40(7):1637-1645. [8] DOSSA E L,KHOUMA M,DIEDHIOU,et al.Carbon,nitrogen and phosphorus mineralization potential of semiarid Sahelian soils amended with native shrub residues[J].Geoderma,2009,148(3-4):251-260. [9] HOUSMAN D C,POWERS H H,COLLINS A D,et al.Carbon and nitrogen fixation differ between successional stages of biological soil crusts in the Colorado Plateau and Chihuahuan Desert[J].Journal of Arid Environments,2006,66(4):620-634. [10] 秦伯强,范成新.大型浅水湖泊内源营养盐释放的概念性模式探讨[J].中国环境科学,2002,22(12):1150-1153. QIN B Q,FAN C X.Exploration of conceptual model of nutrient release from inner source in large shallow lake[J].China Environmental Science,2002,22(12):1150-1153(in Chinese).
[11] 夏勇锋,何少华,凌静,等.底泥氮磷释放的影响因素及控制方法[J].水科学与工程技术,2012,175(6):46-48. XIA Y F,HE S H,LING J,et al.Influencing factors and controlling methods of nitrogen and phosphorus release from sediments[J].Water Sciences and Engineering Technology,2012,175(6):46-48(in Chinese).
[12] 田娟,刘凌,董贵明,等.淹水土壤磷释放机理研究进展[J].土壤通报,2008,39(2):426-430. TIAN J,LIU L,DONG G M,et al.Study progress of phosphorus release mechanics in flooded soils[J].Chinese Journal of Soil Science,2008,39(2):426-430(in Chinese).
[13] 陈晓晴,高良敏,卓利玲.谢桥采煤塌陷水域氮、磷时空分布特征[J].环境化学.2013,32(3):446-450. CHEN X Q,GAO L M,ZHUO L L.Temporal and spatial distribution of nitrogen and phosphorus of Xieqiao coal mining subsided water area[J].Environmental Chemistry,2013,32(3):446-450(in Chinese).
[14] 邓道贵,孟小丽,雷娟.等.淮北采煤塌陷区小型湖泊浮游植物群落结构和季节动态[J].生态科学,2012,29(6):499-506. DENG D G,MENG X L,LEI J,et al.Community structure and seasonal dynamics of phytoplankton in small lakes of Huaibei excavating coal subsidence region[J].Ecological Science,2012,29(6):499-506(in Chinese).
[15] [16] 吕贻忠,李保国.土壤学实验[M].北京:中国农业出版社,2010.41-43.LV Y Z,Li B G.Experiment of Pedolgy[M].Beijing:China Agriculture Press,2010.41 -43(in Chinese).
[17] 戴纪翠,宋金明,郑国侠,等.胶州湾沉积物氮的环境生物地球化学意义[J].环境科学,2007,28(9):1924-1929. DAI J C,SONG J M,ZHENG G X,et al.Environmental biogeochemical significance of nitrogen in Jiaozhou Bay sediments[J].Environmental Science,2007,28(9):1924-1929(in Chinese).
[18] 王圣瑞,赵海超,周小宁,等.五里湖与贡湖不同粒径沉积物中有机质、总氮和磷形态分布研究[J].环境科学研究,2004,17(增刊):11-14.WANG S R,ZHAO H C,ZHOU X N,et al.Study on the organic matter,total nitrogen and phosphorus form distribution of different particle size fractions in the sediments from Wuli Lake and Gonghu Lake[J].Research of Environmental Science,2004 ,17(supplement):11-14(in Chinese).
[19] 刘巧梅,刘敏,许世远,等.上海滨岸潮滩不同粒径沉积物中无机形态磷的分布特征[J].海洋环境科学,2002,21(3):29-33. LIU Q M,LIU M,XU S Y,et al.Distribution feature of inorganic phosphorous in tidal sediments at different grain sizes taken from Shanghai coastal zone[J].Marine Environmental Science,2002,21(3):29-33(in Chinese).
[20] 胡家竣,周群英.环境工程微生物学[M].上海:高等教育出版社,1987.132.HU J J,ZHOU Q Y.Microbiology of environmental engineering[M].Shanghai:Higher Education Press,1987.132(in Chinese). [21] SZILAS C P,BORGGARD O K,HANSEN H C B.Potential iron and phosphate mobilization during flooding of soil material[J].Water,Air and Soil Pollution.1998,106:97-109. [22] SHUKLA S S.SYERS J.WILLIAMS J D,et al.Sorption of inorganic phosphate by lake sediment[J].Soil Sei Sor Am,1971.35:244-249 [23] 徐晓锋,杨浩,吕俊杰.湖泊底泥氮营养释放特征研究[J].中国农学通报,2006,22(10):411-413. XU X F,YANG H,LV J J.Nitrogen release characteristic of dianchi lake sediment[J].Chinese Agricultural Science Bulletin,2006,22(10):411-413(in Chinese).
[24] SONDERGAARD M,KRISTENSEN P,JEPPESEN E.Phosphorus release from sediment in the shallow and wind-exposed Lake Arreso,Denmark[J].Hydrobiologia,1992,228:91-99 [25] REDDY K R,FISHER M M,IVANOFF D.Resuspension and diffusive flux of nitrogen and phosphorus in hypereutrophic lake[J].Journal of Environmental Quality,1996,25:363-371. [26] 张雷,秦延文,贾静,等.三峡入库河流澎溪河回水区消落带与岸边土壤磷形态及其分布特征研究[J].环境科学学报,2011,31(9):1999-2007. ZHANG L,QIN Y W,JIA J,et al.Phosphorus forms and its distribution characteristics in soils of water-level-fluctuating zone of the backwater reach of the Pengxi River,input river of the Three Gorges Reservoir[J].Acta Scientiae Circumstantiae,2011,31(9):1999-2007(in Chinese).
[27] 王圣瑞.湖泊沉积物-水界面过程氮磷生物地球化学[M].北京:科学出版社,2014.152-156.WANG S R.Sediment-water interface process of lakes nitrogen and phosphorus biogeochemistry[M].Beijing:China Science Publishing House,2014:152 -156(in Chinese).
[28] LUO L C,QIN B Q,ZHU G W,et al.Dynamics of sediment resuspension and the conceptual schema of nutrient release in the large shallow Lake Taihu,China[J].Chinese Science Bulletin,2004,49(1):54-64 [29] 曲瑛璇,盛彦清,丁超锋,等.海岸带表层沉积物中磷的地球化学特征[J].中国环境科学,2014,24(1):246-252. QU Y X,SHENG Y Q,DING C F,et al.Gochemistry characteristic of phosphorus in costal surface sediments[J].China Environmental Science,2014,24(1):246-252(in Chinese).
[30] 张路,范成新,王建军,等.长江中下游湖泊沉积物氮磷形态与释放风险关系[J].湖泊科学,2008,20(3):263-270. ZHANG L,FAN C X,WANG J J,et al.Nitrogen and phosphorus forms and release risks of lake sediments from the middle and lower reaches of the Yangtze River[J].Journal of Lake Sciences,2008,20(3):263-270(in Chinese).
[31] 王超,邹丽敏,王沛芳,等.典型城市浅水湖泊沉积物中磷与铁的形态分布及相关关系[J].环境科学,2008,29(12):3400-3404. WANG C,ZOU L M,WANG P F,et al.Distribution and correlation of p and fe fractions in sediments of typical urban shallow lakes[J].Environmental Science,2008,29(12):3400-3404(in Chinese).
[32] 金晓丹,吴昊,陈志明,等.长江河口水库沉积物磷形态、吸附和释放特性[J].环境科学,2015,36(2):448-456. JIN X D,WU H,CHEN Z M,etal.Phosphorus fractions,sorption characteristics and its release in the sediments of Yangtze Estuary Reservoir,China[J].Environmental Science,2015,36(2):448-456(in Chinese).
[33] 谢凯,徐鑫,张磊.淮南潘谢矿区沉陷积水区沉积物磷的赋存和迁移转化特征[J].生态与农村环境学报,2015,31(2):211-217. XIE K,XU X,ZHANG L.Fractions of phosphorus and migration in sediments in flooded sinkages around panxie coal mine in Huainan[J].Journal of Ecology and Rural Environment,2015,31(2):211-217(in Chinese).
[34] 宋晓梅,桂和荣,陈兆炎.安徽沿淮地区潮土理化性质及低养分机理研究[J].安徽地质,2004,14(2):131-135. SONG X M,GUI H R,CHEN Z Y,et al.Study of physicochemical nature and lower-nutrient mechanism of moistness soil distributing along the Huai-River in Anhui Province[J].Geology of Anhui,2004,14(2):131-135(in Chinese).
[35] 潘根兴.淮北土壤铁锰结核中过渡金属元素的富集及其环境地球化学意义[J].科学通报,1989,34(19):1505-1507. PAN G X,Concentration of transition-metaL in Soil Fe-Mn nodules in Huaibei District and its environmental geochemistry significance[J].Chinese Science Bulletin,1989,34(19):1505-1507(in Chinese).
[36] 袁东海,张孟群,高士祥,等.几种粘土矿物和粘粒土壤吸附净化磷素的性能和机理[J].环境化学,2005,24(1):7-11 YUAN D H,ZHANG M Q,GAO S X,et al.The ability and mechanisms of adsorption phosphorus in some clay minerals and soils[J].Environmental Chemistry,2005,24(1):7-11(in Chinese).
[37] 高超,张桃林,吴蔚东.氧化还原条件对土壤磷素固定与释放的影响[J].土壤学报,2002,39(4):542-549. GAO C,ZHANG T L,WU W D.Phosphorus sorption and releas of paddy soils:Effect of alternation of oxidized and reduced conditions[J].Acta Pedologica Sinica,2002,39(4),542-549(in Chinese).
[38] 袁文权,张锡辉,张丽萍.不同供氧方式对水库底泥氮磷释放影响[J].湖泊科学,2004,16(1):28-34. YUAN W Q,ZHANG X H,ZHANG L P.Effects of different oxygenation treatments on the release of nitrogen and phosphorus from reservoir sediments[J].Journal of Lake Science,2004,16(1):28-34(in Chinese).
[39] 郭劲松,黄轩民,张彬.等.三峡库区消落带土壤有机质和全氮含量特征分布[J].湖泊科学,2012,24(2):213-219. GUO J S,HUANG X M,ZHANG B,et al.Distribution characteristics of organic matter and total nitrogen in the soils of water-level-fluctuating zone of Three Gorges Reservoir area[J].Journal of Lake Sciences,2012,24(2):213-219(in Chinese).
[40] 龚春生,范成新.不同溶解氧水平下湖泊底泥-水界面磷交换影响因素分析[J].湖泊科学,2010,22(3):430-436. GONG C S,FAN C X.Effect factors analysis of phosphorous exchange across lake sediment-water interface under different dissolved oxygen concentration[J].Journal of Lake Sciences,2010,22(3):430-436(in Chinese).
-
