蜂蜜中9种杀虫剂的UPLC-MS/MS检测方法

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

李菊颖, 何健, 吴文铸, 孔德洋, 单正军, 陈全博. 蜂蜜中9种杀虫剂的UPLC-MS/MS检测方法[J]. 环境化学, 2016, 35(9): 1921-1927. doi: 10.7524/j.issn.0254-6108.2016.09.2016033101
引用本文: 李菊颖, 何健, 吴文铸, 孔德洋, 单正军, 陈全博. 蜂蜜中9种杀虫剂的UPLC-MS/MS检测方法[J]. 环境化学, 2016, 35(9): 1921-1927. doi: 10.7524/j.issn.0254-6108.2016.09.2016033101
shu
LI Juying, HE Jian, WU Wenzhu, KONG Deyang, SHAN Zhengjun, CHEN Quanbo. UPLC-MS/MS detection of 9 insecticides in honey[J]. Environmental Chemistry, 2016, 35(9): 1921-1927. doi: 10.7524/j.issn.0254-6108.2016.09.2016033101
Citation: LI Juying, HE Jian, WU Wenzhu, KONG Deyang, SHAN Zhengjun, CHEN Quanbo. UPLC-MS/MS detection of 9 insecticides in honey[J]. Environmental Chemistry, 2016, 35(9): 1921-1927. doi: 10.7524/j.issn.0254-6108.2016.09.2016033101
shu

蜂蜜中9种杀虫剂的UPLC-MS/MS检测方法

  • 1.

    环境保护部南京环境科学研究所国家环境保护农药环境评价与污染控制重点实验室, 南京, 210042

  • 基金项目:

    中央级公益性科研院所基本科研业务专项（农药生态影响再评估技术研究2014-002），2013年环保公益行业项目资助项目（2013467026）资助.

UPLC-MS/MS detection of 9 insecticides in honey

  • 1.

    Nanjing Institute of Environmental Science, Key Laboratory of Pesticide Environmental Assessment and Pollution Control, Ministry of Environmental Protection of the People's Republic of China, Nanjing, 210042, China

  • Fund Project: Supportd by the Central Level, Scientific Research Institutes for Basic R & D Special Fund Business(Study on the Technology of Ecological Impact Assessment of Pesticide 2014-002), Special Fund for Environmental Protection Research in the Public Interest(2013467026).

  • 摘要: 针对吡虫啉、啶虫脒、噻虫嗪、噻虫胺、噻虫啉、呋虫胺等6种新烟碱类和乐果、敌敌畏、毒死蜱等3种有机磷类杀虫剂建立了蜂蜜中分散固相萃取法-超高效液相色谱-串联质谱的残留分析方法.前处理方法利用乙腈为提取剂，N-丙基乙二胺（PSA）为分散净化剂的QuEChERS方法，并利用超高效液相色谱-串联质谱在多反应离子监测模式（MRM）下进行检测，外标法定量.结果表明，9种杀虫剂在5-800 μg·L-1浓度范围内均具有良好的线性关系（R≥0.994）；在0.005-0.200 mg·kg-1添加，水平范围内平均回收率在80.4%-107.5%之间，相对标准偏差在1.2%-6.8%之间；方法检出限（LOD）在0.1-1.5 μg·kg-1范围内；定量限（LOQ）在0.3-4.5 μg·kg-1范围内.该方法分析速度快、灵敏度高、重现性好，适用于蜂蜜中多种农药残留的快速检测和确证.
    Abstract: A method was developed for the simultaneous determination of 6 neonicotinoid insecticides and 3 organophosphorus insecticides including imidacloprid, acetamiprid, thiamethoxam, clothianidin, thiacloprid, dinotefuran, dimethoate, DDVP and chlorpyrifos in honey. The residues were extracted from the samples with acetonitrile and cleaned up with dispersive method on PSA, then detected by ultra liquid chromatography-mass spectrometry under multiple reaction monitoring mode, and quantified by matrix-match standard solution. The results showed the method had good linearity (R≥0.994) from 5-800 μg·L-1. Average fortified recoveries in samples were in the range of 80.4%-107.5% at three fortified levels from 0.005-0.200 mg·kg-1, with relative standard deviations of 1.2%-6.8% (n=5). The limits of detection (LOD) of these 9 insecticides were in the range of 0.1-1.5 μg·kg-1, while limits of quantification (LOQ) were in the range of 0.3-4.5 μg·kg-1. The method is rapid and simple with high sensitivity and good reproducibility, and suitable for determination of different insecticides in honey.
  • 加载中
  • [1] 李志勇,刘楠楠,牛庆生,等.蜜蜂与化学农药[J].蜜蜂杂志,2014,34(2):29-32.

    LI Z Y,LIU N N,NIU X S,et al.Bees and chemical pesticides[J].Journal of Bee,2014,2:29-32(in Chinese).

    [2] 卜元卿,单正军,周军英,等.农药对蜜蜂生物毒性及安全性评价研究[J].农药,2009,48(6):399-401.

    BU Y Q,SHAN Z J,ZHOU J Y.Research review on biological toxicity and safety assessment of pesticides to honeybee[J].Agrochemicals,2009,48(6):399-401(in Chinese).

    [3] CHAUZAT J M.Preliminary results of mulitifactorial field survey of pathogens and toxicants in Apis melifera colonies Apiaries in France[C].Udine:first Eurpoean Confercence of Apidology,2004.
    [4] 李庆凤,袁建忠.新烟碱类杀虫剂是否影响欧洲蜜蜂健康[J].世界农药,2014,36(1):27-30.

    LI X F,YUAN J Z.Whether the neonicotinoid pesticides affected the health of European honey bees[J].World Pesticides,2014,36(1):27-30(in Chinese).

    [5] AlAA K,AMAD A G.Determination of acaricide residues in Saudi ambian honey and beeswax using solid phase extraction and gas chromatography[J].Journal of Environmental Science and Health,part B,2006,41(2):159-165.
    [6] 林国斌,倪蕾,林升清,等.气相色谱法测定蜂蜜中10种拟除虫菊酯类农药残留[J].中国食品卫生杂志,2012,24(2):116-119.

    LIN G B,NI L,LIN S Q,et al.Determination of pyrethroid pesticide residues in honey by gas chromatography[J].Chinese Journal of food Hygiene,2012,24(2):116-119(in Chinese).

    [7] 王吉祥,王亚琴,赵昱,等.气相色谱法检测蜂蜜中蝇毒磷及氟胺氰菊酯残留[J].食品研究与开发,2013,34(15):71-74.

    WANG J X,WANG Y Q,ZHAO Y,et al.Gas Chromatography method for simultaneous determination of coumaphos and fluvalinate residues in honey[J].Food Research and Development,2013,34(15):71-74(in Chinese).

    [8] YELKOR C,GUILLERMINA F,JORDI M,et al.Determination of mycotoxins in bee pollen by gas chromatography-tandem mass spectrometry[J].Journal of Agricultural and Food Chemistry,2013,61(8):1999-2005.
    [9] 王东,侯传金,赵尔成,等.分散液液微萃取/气相色谱-质谱法测定蜂蜜中六六六和滴滴涕类农药残留[J].色谱,2015,33(1):40-45.

    WANG D,HOU C J,ZHAO E C,et al.Determination of hexachlorocyclohexane and dichlorodiphenyltrichloroethane residues in honey by gas chromatography-mass spectrometry combined with dispersive liquid-liquid microextraction[J].Chinese Journal of Chromatography,2015,33(1):40-45(in Chinese).

    [10] 夏广辉,沈伟健,余可垚,等.气相色谱-负化学源质谱法测定蜂蜜和王浆中4种杀虫剂的残留[J].色谱,2014,33(7):741-745.

    XIA G H,SHEN W J,YU K Y.Determination of four insecticide residues in honey and royal jelly by gas chromatography-negative chemical ionization mass spectrometry[J].Chinese Journal of Chromatography,2014,33(7):741-745(in Chinese).

    [11] GINA T,CHRISTOPH C.LC-MS/MS analysis of neonicotinoid insecticides in honey:Methodology and residue findings in austrian honeys[J].Journal of agricultural and food chemistry,2011,59(23):12271-12277.
    [12] PAVLE J,VALERIA G,MLADEN F,et al.Development of multiresidue DLLME and QuEChERS based LC-MS/MS method for determination of selected neonicotinoid insecticides in honey liqueur[J].Food Research International,2014,55:11-19.
    [13] 粟有志,李芳,齐鑫,等.QuEChERS-高效液相色谱/串联质谱法同时测定蜂蜜中9种新烟碱类杀虫剂残留[J].分析科学学报,2015,31(2),203-207.

    SU Y Z,LI F,QI X,et al.Determination of nine neonicotinoid insecticides in honey by QuEChERS-HPLC-tandem mass spectrometry[J].Journal of Analytical Science,2015,31(2),203-207(in Chinese).

    [14] YAHVA A N,GARRY C,ANJA V,et al.Organophosphorus insecticides in honey,pollen and bees (Apis mellifera L.) and their potential hazard to bee colonies in Egypt[J].Ecotoxicology and Environmental Safety,2015,114:1-8.
    [15] 中华人民共和国国家质量监督检验检疫总局.GB/T 20771-2008蜂蜜中486种农药及相关化学品残留量的测定:液相色谱-串联质谱法[S].北京:中国标准出版社,2009.General Administration of Quality Supervision,Inspection and Quarantine of P.R.C.GB/T 20771-2008 Determination of 486

    pesticides and related chemicals residues in honey-LC-MS-MS method[S].Beijing:Standards Press of China,2009(in Chinese).

    [16] 中华人民共和国国家质量监督检验检疫总局.GB/T 19426-2006蜂蜜中497种农药及相关化学品残留量的测定:气相色谱-质谱法[S].北京:中国标准出版社,2007.General Administration of Quality Supervision,Inspection and Quarantine of P.R.C.GB/T 19426-2006 Method for the determination of 497

    pesticides and related chemicals residues in honey,fruit juice and wine-GC-MS method[S].Beijing:Standards Press of China,2007(in Chinese).

    [17] 梅梅,杜振霞,陈芸.QuEChERS-超高效液相色谱串联质谱法同时测定土壤中5种常用除草剂[J].分析化学,2011,39(11):1659-1664.

    MEI M,DU Z X,CHEN Y.QuEChERS-ultra performance liquid chromatography-tandem mass spectrometry for determination of currently used herbicides[J].Chinese Journal of Analytical Chemistry,2011,39(11):1659-1664(in Chinese).

    [18] 中华人民共和国卫生部.GB/T 14963-2011食品安全国家标准蜂蜜[S].北京,中国标准出版社,2011.The Minister of Health of the People's Republic of China.GB/T 14963-2011 National food safety standard honey[S].Beijing,Standards Press of China,2011

    (in Chinese).

    [19] 中华人民共和国国家卫生和计划生育委员会.GB/T 2763-2014食品中农药最大残留限量[S].北京,中国标准出版社,2014.The people's Republic of China National Health and Family Planning Commission.National food safety standard-Maximum residue limits for pesticides in food[S].Beijing,Standards Press of China,2014(in Chinese).
    [20] The European Food Safety Authority.Regulation (EC) No 396/2005 of the European Parliament and of the council of 23 February 2005 on maximum residue levels of pesticides in or on food and feed of plant and animal origin and amending Council Directive 91/414/EEC[S].European Union,Official Journal of the European Union.
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  950
  • HTML全文浏览数:  900
  • PDF下载数:  455
  • 施引文献:  0
出版历程
  • 收稿日期:  2016-03-31
  • 刊出日期:  2016-09-15
李菊颖, 何健, 吴文铸, 孔德洋, 单正军, 陈全博. 蜂蜜中9种杀虫剂的UPLC-MS/MS检测方法[J]. 环境化学, 2016, 35(9): 1921-1927. doi: 10.7524/j.issn.0254-6108.2016.09.2016033101
引用本文: 李菊颖, 何健, 吴文铸, 孔德洋, 单正军, 陈全博. 蜂蜜中9种杀虫剂的UPLC-MS/MS检测方法[J]. 环境化学, 2016, 35(9): 1921-1927. doi: 10.7524/j.issn.0254-6108.2016.09.2016033101
shu
LI Juying, HE Jian, WU Wenzhu, KONG Deyang, SHAN Zhengjun, CHEN Quanbo. UPLC-MS/MS detection of 9 insecticides in honey[J]. Environmental Chemistry, 2016, 35(9): 1921-1927. doi: 10.7524/j.issn.0254-6108.2016.09.2016033101
Citation: LI Juying, HE Jian, WU Wenzhu, KONG Deyang, SHAN Zhengjun, CHEN Quanbo. UPLC-MS/MS detection of 9 insecticides in honey[J]. Environmental Chemistry, 2016, 35(9): 1921-1927. doi: 10.7524/j.issn.0254-6108.2016.09.2016033101
shu

蜂蜜中9种杀虫剂的UPLC-MS/MS检测方法

  • 1. 环境保护部南京环境科学研究所国家环境保护农药环境评价与污染控制重点实验室, 南京, 210042
  • 收稿日期:  2016-03-31
基金项目:

中央级公益性科研院所基本科研业务专项（农药生态影响再评估技术研究2014-002），2013年环保公益行业项目资助项目（2013467026）资助.

摘要: 针对吡虫啉、啶虫脒、噻虫嗪、噻虫胺、噻虫啉、呋虫胺等6种新烟碱类和乐果、敌敌畏、毒死蜱等3种有机磷类杀虫剂建立了蜂蜜中分散固相萃取法-超高效液相色谱-串联质谱的残留分析方法.前处理方法利用乙腈为提取剂，N-丙基乙二胺（PSA）为分散净化剂的QuEChERS方法，并利用超高效液相色谱-串联质谱在多反应离子监测模式（MRM）下进行检测，外标法定量.结果表明，9种杀虫剂在5-800 μg·L-1浓度范围内均具有良好的线性关系（R≥0.994）；在0.005-0.200 mg·kg-1添加，水平范围内平均回收率在80.4%-107.5%之间，相对标准偏差在1.2%-6.8%之间；方法检出限（LOD）在0.1-1.5 μg·kg-1范围内；定量限（LOQ）在0.3-4.5 μg·kg-1范围内.该方法分析速度快、灵敏度高、重现性好，适用于蜂蜜中多种农药残留的快速检测和确证.
