平衡渗析-多种光谱法研究太湖不同分子量溶解性有机质及其与铜的相互作用
Determination of Cu complexed with individual molecular size fractions of dissolved organic matter from the Taihu Lake, China by equilibrium dialysis and multiple spectroscopic methods
-
摘要: 采用平衡渗析技术将太湖沉积物溶解性有机质（DOM）按分子量分成不同的组分.利用光谱技术和离子选择电极（ISE）分析了不同分子量溶解性有机质的光谱特征及对Cu的结合，进一步探讨分子量对DOM特性和对金属结合能力的影响.结果表明，南太湖DOM分子量以高于10000 Da为主，然而北太湖分子量以低于3500 Da为主.三维荧光光谱（3DEEM）表明太湖沉积物DOM呈现出4种特征荧光峰.类富里酸荧光峰的荧光强度随着DOM分子量的增加而增强，然而类蛋白质荧光峰的荧光强度随着DOM分子量的增加而降低.南太湖DOM碳氮比（C/N）（20.30）显著高于北太湖（7.58），表明了DOM不同的来源.对于南北湖区，DOM-Cu浓度最大值都是在DOM分子量低于1000 Da组分，大约50%的DOM-Cu在分子量低于3500 Da的组分中.结合容量表明南太湖DOM分子量低于3500 Da的组分和北太湖分子量在1000-3500 Da的组分对于Cu结合起主要的作用，表明低分子量DOM对于结合重金属的重要性.Abstract: Dissolved organic matter (DOM) from Taihu Lake sediment was separated into different molecular weight fractions with equilibrium dialysis. Spectroscopic methods and ion selective electrode (ISE) were employed to analyze spectral characteristics of different molecular weight DOM and the interaction with Cu, and to further examine metal-binding abilities and fluorescence signals in connection with molecular weight. The results indicated that in South Lake DOM was dominated with molecular weight higher than 10000 Da, while in the North Lake DOM was dominated with molecular weight lower than 3500 Da. Three-dimensional fluorescence excitation-emission matrix (3DEEM) showed that DOM from Taihu sediment displayed four distinct fluorophores peaks. Fluorescence intensity of humic-like fluorescence peak increased with the DOM molecular weight, while the fluorescence intensity of protein-like fluorescence peak decreased with the molecular weight. C/N of DOM in South Lake (20.30) was significantly higher than that in North Lake (7.58), indicating their different source. DOM-Cu complex concentration was maximal in the fractions with molecular weight lower than 1000 Da in both South Lake and North Lake, and around 50% of the total DOM-Cu in the fractions with molecular weight lower than 3500 Da. Complexing capacity showed that DOM with molecular weight lower than 3500 Da in the South Lake and molecular weight between 1000 and 3500 Da in the North Lake were largely responsible for Cu complexing, indicating the importance of low molecular weight fractions in heavy metal binding.
-
Key words:
- molecular weight /
- dissolved organic matter /
- equilibrium dialysis /
- Taihu Lake
-
-
[1] 利锋, 张学先,戴睿志. 重金属有效态与土壤环境质量标准制订[J]. 广东微量元素科学,2008,15(1):7-10. LI F, ZHANG X X, DAI R Z. The bioavailability of heavy metal and environmental quality standard for soil[J]. Guangdong Trace Elements Science, 2008,15(1):7-10(in Chinese).
[2] 冯精兰,胡鹏抟,刘群,等.黄河中下游干流沉积物中重金属的赋存形态及其生态风险[J]. 环境化学,2015,34(1):178-185. FENG J L, HU P T, LIU Q, et al. Chemical speciation and risk assessment of heavy metals in the sediments from the mainstream of middle and lower reaches of Yellow River[J]. Environmental Chemistry, 2015,34(1):178-185(in Chinese).
[3] 曾希柏,杨佳波,李莲芳,等.溶解性有机物对土壤中铜生物有效性的影响[J].农业环境科学学报,2009,28(5):883-889. ZENG X, YANG J B, LI L F, et al. Influence of dissolved organic matter (DOM) on bioavailability of copper in soils[J]. Journal of Agro-Environment Science,2009,28(5):883-889(in Chinese).
[4] WANG X D, CHEN X N, LIU S, et al. Effect of molecular weight of dissolved organic matter on toxicity and bioavailability of copper to lettuce[J]. Journal of Environmental Sciences, 2010,22(12):1960-1965. [5] KNOTH DE Z K G, SCHOLER Y D. Fluorescence fingerprints and Cu2+-complexing ability of individual molecular size fractions in soil-and waste-borne DOM[J]. Chemosphere, 2007,69(4):540-548. [6] 岳兰秀,刘丛强,吴丰昌.水环境中天然溶解有机质分子量的研究现状及意义[J]. 环境科学与管理,2010,35(4):29-34. YUE L X, LIU C Q, WU F C. Development of studies on molecular weight of humic substances in natural environment[J]. Environmental Science and Management,2010,35(4):29-34(in Chinese).
[7] 乔春光,魏群山,王东升,等.典型南方水源溶解性有机物分子量分布变化及去除特性[J]. 环境科学学报, 2007,27(2):195-200. QIAO C G, WEI Q S, WANG D S, et al. Molecular weight distribution and removal characters of DOM in the typical source water in south of China[J]. Acta Scientiae Circumstantiae, 2007,27(2):195-200(in Chinese).
[8] RAMAMOORTHY S, KUSHNER D J. Heavy metal binding sites in river water[J]. Nature,1975,256:399-401. [9] SMITH R G. Evaluation of combined applications of ultrafiltration and complexation capacity techniques to natural waters[J]. Analytical Chemosphere,1976, 48:74-76. [10] 郭旭晶,席北斗,谢森,等.乌梁素海沉积物孔隙水中溶解有机质的荧光及紫外光谱研究[J]. 环境工程学报,2012,6(2):440-444. GUO X J,XI B D, XIE S, et al. Study on fluorescence spectra and UV-vis spectra of dissolved organic matter collected from sediment pore water inWuliangsuhai Lake[J]. Chinese Journal of Environmental Engineering, 2012,6(2):440-444(in Chinese).
[11] 张路,范成新,王建军.太湖草藻型湖区间隙水理化特性比较[J]. 中国环境科学,2004,24(5):556-560. ZHANG L, FAN C X, WANG J J. Comparison of physicochemical characters of pore water in grass/algae type zone in Lake Taihu[J]. China Environmental Science,2004,24(5):556-560(in Chinese).
[12] YU T, ZHANG Y, MENG W, et al. Characterization of heavy metals in water and sediments in Taihu Lake, China[J]. Environment Monitoring and Assessment, 2012,184:4367-4382. [13] KOELMANS A A, VANDERHEIJDE A, KNIJFF L M, et al. Integrated modelling of eutrophication and organic contaminant fate & effects in aquatic ecosystems:A review[J]. Water Research, 2001,35(15):3517-3536. [14] 石陶然,张远,于涛,等.滇池沉积物不同分子量溶解性有机质分布及其与Cu、Pb的相互作用[J].环境科学研究,2013,26(2):137-144. SHI T R, ZHANG Y, YU T, et al. Distribution of different molecular weight fractions of dissolved organic matters and their complexation with Cu and Pb in the sediment from Dianchi Lake, China[J].Research of Environmental Science,2013,26(2):137-144(in Chinese).
[15] 郑乐平,刘玉梅,钱显文,等.太湖、巢湖沉积物中重金属污染的总量特征及其区域性差异[J].环境化学, 2009,28(6):883-887. ZHENG L P, LIU Y M, QIAN X W, et al.The characteristics and regional differences of heavy metal contents in the sediments of Taihu Lake and Chaohu Lake[J]. Environmental Chemistry, 2009,28(6):883-887(in Chinese).
[16] 王钦,丁明玉,张志洁,等.太湖不同湖区沉积物重金属含量季节变化及其影响因素[J].生态环境,2008, 17(4):1362-1368. WANG Q, DING M Y, ZHANG Z J. Seasonal varieties and influential factors of heavy metals in sediments of Taihu Lake[J]. Ecology and Environment,2008, 17(4):1362-1368(in Chinese).
[17] CHEN Z R, CAI Y, SOLO-GABRIELE H G, et al. Interactions of arsenic and the dissolved substances derived from Turf Soils[J]. Environmental Science and Technology, 2006,40:4659-4665. [18] 袁和忠, 沈吉, 刘恩峰.太湖重金属和营养盐污染特征分析[J].环境科学,2011,32(3):649-657. YUAN H Z, SHEN J, LIU E F. Assessment and characterization of heavy metals and nutrients in sediments from Taihu Lake[J]. Environmental Science,2011,32(3):649-657(in Chinese).
[19] 曾宪成,成绍鑫.腐殖酸的主要类别[J].腐殖酸,2002,4(2):4-10. ZENG X C, CHENG S X. Category of humic acid[J].Humic Acid, 2002,4(2):4-10(in Chinese).
[20] 傅平青,吴丰昌,刘丛强,等.高原湖泊溶解有机质的三维荧光光谱特性初步研究[J]. 海洋与湖沼,2007,38(6):512-520. FU P Q, WU F C, LIU C Q, et al. Three-dimensional imensional excitation emission matrix fluorescence spectroscopy of dissolved organic matter from Chinese highland Lakes[J]. Akes, Oceanologia Et Limnologia Sinica, 2007,38(6):512-520(in Chinese).
[21] BAKER A. Fluorescence excitation-emission matrix characterization of some sewage-impacted rivers[J]. Environmental Science and Technology, 2001,35(5):948-953. [22] SALM C R, SAROS J E, FRITZ S C, et al. Phytoplankton productivity across prairie saline lakes of the Great Plains (USA):A step toward deciphering patterns through lake classification models[J]. Canadian Journal of Fisheries and Aquatic Sciences, 2009,66(9):1435-1448. [23] NOBUYASU I, SHU J T, MICHIO K. Distributions of polycyclic aromatic hydrocarbons in a sediment core from the north basin of Lake Biwa, Japan[J]. Organic Geochemistry,2010, 41(8):845-852. [24] ZHANG Y, ZHANGY, YU T, et al. Characterization and environmental significance of degradation of DOM from Taihu Lake under different conditions using multiple analytical techniques[J]. Fresenius Environmental Bulletin, 2012,21(5):1118-1126. [25] FU P Q, WU F C, LIU C Q, et al. Fluorescence characterization of dissolved organic matter in an urban river and its complexation with Hg(Ⅱ)[J]. Applied Geochemistry, 2007,22(8):1668-1679. [26] [27] VAN HEES P A W, LUNDSTROM U S, GIESLER R. Low molecular weight organic acids and their Al-complexes in soil solution-composition, distribution and seasonal variation in three podzolized soils[J]. Geoderma,2000,94:173-200. [28] WU L H, LUO Y M, CHRISTIE P, et al. Effects of EDTA and low molecular weight organic acids on soil solution properties of a heavy metal polluted soil[J]. Chemosphere, 2003,50:819-822. [29] NIEROP K G J, JANSEN B, VRUGT J A, et al. Copper complexation by dissolved organic matter and uncertainty assessment of their stability constants[J]. Chemosphere,2002,49:1191-1200. [30] CALACE N, LIBERATORI A, PETRONIO B M, et al. Characteristics of different molecular weight fractions of organic matter in landfill leachate and their role in soil sorption of heavy metals[J]. Environmental Pollution, 2001,113:331-339. [31] YAN M Q, KORSHIN G, WANG D S. Characterization of dissolved organic matter using high-performance liquid chromatography (HPLC)-size exclusion chromatography (SEC) with a multiple wavelength absorbance detector[J]. Chemosphere,2012, 87:879-885. [32] 范文宏,陈俊,王琼.胡敏酸对沉积物中重金属形态分布的影响[J]. 环境化学,2007,26(2):224-227. FAN W H, CHEN J, WANG Q. Influence of humic acid on species of heavy metals in sediments[J]. Environmental Chemistry, 2007,26(2):224-227(in Chinese).
-
