太原市城区臭氧变化特征及影响因素
Variation and the influence factors of ozone in urban area in Taiyuan
-
摘要: 通过对太原城区环境空气质量监测站2014年全年臭氧的连续观测，分析了其浓度变化特征，并结合二氧化氮的浓度以及气象数据研究了臭氧变化的影响因素.数据分析显示：太原市城区环境空气中臭氧的小时平均值为32.1 μg·m-3，日变化总体呈现日间高（44.7 μg·m-3）于夜间（18.0 μg·m-3）的特点，季节变化呈夏季（67.7 μg·m-3）高于冬季（11.1 μg·m-3）的特征；夏季和冬季的臭氧浓度与二氧化氮、环境温度、相对湿度、能见度的相关系数分别是-0.50、0.75、-0.53、0.14和-0.38、0.32、-0.34、0.25；全年节假日的臭氧浓度比工作日高4.37%.研究结果表明，日间太阳辐射的增强和臭氧前驱物浓度的上升，臭氧浓度在15时达到峰值，此后随着太阳辐射的降低和大气化学反应消耗从而导致臭氧浓度不断降低；人为活动排放的二氧化氮是环境空气中的臭氧生成的重要前体物；温度的增加会加快臭氧的生成，相对湿度的增加有利于前驱物和大气中自由基的累积从而影响臭氧浓度，能见度的增加导致的太阳辐射能力增强会一定程度上增加臭氧的浓度，风速的增加会使臭氧出现先升后降的变化，在西南风和南风情况下臭氧的浓度最高；臭氧浓度具有一定的节假日效应.总之影响太原市城区臭氧浓度变化的主要因素是臭氧前驱物（NO2等）和气象条件（太阳辐射、温度等）的变化，控制NO2等臭氧前驱物的排放是控制臭氧污染的主要途径.Abstract: Annual continuous monitoring of ozone (O3) was performed in 2014 at the environmental monitor station in urban area of Taiyuan to investigate the variation and influence factors of O3. The data showed that hourly average concentration of O3 was 32.1 μg·m-3 in urban area of Taiyuan, with the diurnal variation pattern of higher O3 in daytime (44.7 μg·m-3) and lower O3 in nighttime (18.0 μg·m-3), and the seasonal variation of higher concentrations in summer (67.7 μg·m-3) and lower concentrations in winter (11.1 μg·m-3). The correlation coefficients between O3 concentration and nitrogen dioxide, temperature, relative humidity, visibility were -0.50,0.75,-0.53,0.14 in summer and -0.38,0.32,-0.34,0.25 in winter, respectively. The concentration of O3 in holidays was 4.37% higher than workday. The results showed that with the enhancement of solar radiation and precursors emission, the level of O3reached the peak at 15 o'clock, and then descended with the weakening of solar radiation and consumption of chemical reactions. Nitrogen dioxide, emitted from anthropogenic source, was an important precursor during ozone generation. The increase of temperature accelerated the formation of O3, and the increase of relative humidity affected the O3 concentration due to ascending precursors and atmospheric radical. The increase of visibility lead to enhanced solar radiation, which promoted the reaction of O3 production. The increase of wind first lead to increase level of O3, and then a dease Southwest and South wind resulted in the accumulation of O3. The "holiday effect" of O3 was observed in Taiyuan. In conclusion, the main influence factors of O3 variation are the variation of ozone precursors (such as nitrogen dioxide) and meteorological conditions (such as solar radiation, temperature, etc.). Controlling the emissions of ozone precursors might be the main regulatory measure of O3 pollution prevention.
-
Key words:
- Taiyuan /
- ozone /
- variation characteristics /
- meteorological factors /
- holiday effect
-
-
[1] WATSON R, MEIRAFILHO L, SANHUEZA E, et al. Greenhouse gases:Sources and sinks[J]. Climate Change, 1992:25-46. [2] 王明星. 大气化学[M]. 北京:气象出版社, 1999. WANG M X. Atmospheric chemistry[M]. Beijing:China Meteorological Press,1999(in Chinese). [3] AZUCHI F, KINOSE Y, MATSUMURA T, et al. Modeling stomatal conductance and ozone uptake of Fagus crenata grown under different nitrogen loads[J]. Environmental Pollution, 2014, 184:481-487. [4] LOMBARDOZZI D, SPARKS J, BONAN G. Integrating O3 influences on terrestrial processes:Photosynthetic and stomatal response data available for regional and global modeling[J]. Biogeosciences, 2013, 10(11):6815-6831. [5] 崔蕾, 倪长健, 王超,等. 成都市O3浓度的时间变化特征及相关因子分析[J]. 中国环境监测, 2015, 31(6):42-46. CUI L, NI C J, WANG C, et al. Temporal variation of ozone concentration and impact factors in Chengdu[J]. Environmental Monitoring in China, 2015, 31(6):42-46(in Chinese).
[6] 严茹莎, 陈敏东, 高庆先,等. 北京夏季典型臭氧污染分布特征及影响因子[J]. 环境科学研究, 2013, 26(1):43-49. YAN RS, CHEN M D, GAO Q X, et al. Characteristics of typical ozone pollution distribution and impact factors in Beijing in summer[J]. Research of Environmental Sciences, 2013, 26(1):43-49(in Chinese).
[7] 岳婷婷, 柴发合, 张新民,等. 天津武清地区夏季臭氧光化学研究[J]. 环境科学研究, 2009, 22(1):23-27. YUE T T, CHAI F H, ZHANG X M, et al. Ozone photochemistry in summer in Wuqing, Tianjin[J]. Research of Environmental Sciences, 2009, 22(1):23-27(in Chinese).
[8] 易睿, 王亚林, 张殷俊,等. 长江三角洲地区城市臭氧污染特征与影响因素分析[J]. 环境科学学报, 2015, 35(8):2370-2377. YI R, WANG Y L, ZHANG Y J, et al. Pollution characteristics and influence factors of ozone in Yangtze River Delta[J]. Acta Scientiae Circumstantiae, 2015, 35(8):2370-2377(in Chinese).
[9] 闫雨龙, 何秋生, 钱天伟. 太原市大气污染现状及监测站点优化[J]. 太原科技大学学报, 2010, 31(5):427-431. YAN Y L, HE Q S, QIAN T W. Status of atmospheric pollution and optimization of monitoring sites in urban area of Taiyuan[J]. Journal of Taiyuan University of Science and Technology, 2010, 31(5):427-431(in Chinese).
[10] 刘珊, 彭林, 温彦平,等. 太原市PM2.5 中有机碳和元素碳的污染特征[J]. 环境科学, 2015,36(2):396-401. LIU S, PENG L, WEN Y P, et al. Pollution characteristics of organic and elemental carbon in PM2.5 in Taiyuan[J]. Environmental Science, 2015, 36(2):396-401(in Chinese).
[11] 袁进, 彭林, 李凡,等. 太原城区空气颗粒物中多环芳烃的碳同位素组成研究[J]. 太原理工大学学报, 2007, 38(6):503-506. YUAN J, PENG L, LI F, et al. Study on stable carbon isotope characteristics of atmospheric polycyclic aromatic hydrocarbons in urban area of Taiyuan, China[J]. Journal of Taiyuan University of Technology, 2007, 38(6):503-506(in Chinese).
[12] 孟晓艳, 王瑞斌, 杜丽,等. 试点城市O3浓度特征分析[J]. 中国环境监测, 2013, 29(1):64-70. MENG X Y, WANG R B, DU L, et al. The characters of variation of ozone in experimental cities[J]. Environmental Monitoring in China, 2013, 29(1):64-70(in Chinese).
[13] 耿福海, 刘琼, 陈勇航. 近地面臭氧研究进展[J]. 沙漠与绿洲气象, 2012, 6(6):8-14. GENG F H, LIU Q, CHEN Y H. Discussion on the research of surface ozone[J]. Desert and Oasis Meteorology, 2012, 6(6):8-14(in Chinese).
[14] COLEMAN L, MARTIN D, Varghese S, et al. Assessment of changing meteorology and emissions on air quality using a regional climate model:Impact on ozone[J]. Atmospheric Environment, 2013, 69:198-210. [15] WANG T, LAM K, LEE A S, et al. Meteorological and chemical characteristics of the photochemical ozone episodes observed at Cape D'Aguilar in Hong Kong[J]. Journal of applied Meteorology, 1998, 37(10):1167-1178. [16] 姚青, 孙玫玲, 刘爱霞. 天津臭氧浓度与气象因素的相关性及其预测方法[J]. 生态环境学报, 2009, 18(6):2206-2210. YAO Q, SUN M L, LIU A X. Analysis and prediction of surface ozone concentration and related meteorological factors in summer in Tianjin[J]. Ecology and Environment, 2009, 18(6):2206-2210(in Chinese).
[17] 王涛, 陈梦平, 周梦翩,等. 无锡市区大气污染物污染特征及影响因素研究[J]. 环境污染与防治, 2015, 37(12):74-78. WANG T, CHEN M P, ZHOU M P, et al. Pollution characteristics and influence factors of air pollutants in Wuxi City[J]. Environmental Pollution and Control, 2015, 37(12):74-78(in Chinese).
[18] 马文静, 张承中, 韩德明,等. 西安城区夏季地面臭氧浓度变化特征分析[J]. 环境工程, 2015, 33(10):47-49. MA W J, ZHANG C Z, HAN D M, et al. Analysis on variation characteristics of surface ozone concentration in urban area of Xi'an in Summer[J]. Environmental Engineering, 2015, 33(10):47-49(in Chinese).
[19] 雷瑜, 张小玲, 唐宜西,等. 北京城区PM2.5及主要污染气体"周末效应" 和"假日效应" 研究[J]. 环境科学学报, 2015, 35(5):1520-1528. LEI Y, ZHANG X L, TANG Y X, et al. Holiday effects on PM2.5 and other major pollutants in Beijing[J]. Acta Scientiae Circumstantiae,2015, 35(5):1520-1528(in Chinese).
[20] 姚青, 孙玫玲, 蔡子颖, 等. 2009年天津城区地面O3和NOx的季节变化与相关性分析[J]. 环境化学, 2011, 30(9):1650-1656. YAO Q, SUN M L, CAI Z Y, et al. Seasonal variation and analysis of the relationship between NO, NO2 and O3 concentrations in tianjin in 2009[J]. Environmental Chemistry, 2011, 30(9):1650-1656(in Chinese).
-
