脂肪胺-硅胶的制备与其吸附Pb（Ⅱ）性能

,  ,

downloadPDF

上一篇

下一篇

钱翌, 李少权, 武洋. 脂肪胺-硅胶的制备与其吸附Pb（Ⅱ）性能[J]. 环境化学, 2017, 36(5): 1140-1147. doi: 10.7524/j.issn.0254-6108.2017.05.2016090501
引用本文: 钱翌, 李少权, 武洋. 脂肪胺-硅胶的制备与其吸附Pb（Ⅱ）性能[J]. 环境化学, 2017, 36(5): 1140-1147. doi: 10.7524/j.issn.0254-6108.2017.05.2016090501
shu
QIAN Yi, LI Shaoquan, WU Yang. Synthesis of silica modified with aliphatic amine and its adsorption for Pb(Ⅱ)[J]. Environmental Chemistry, 2017, 36(5): 1140-1147. doi: 10.7524/j.issn.0254-6108.2017.05.2016090501
Citation: QIAN Yi, LI Shaoquan, WU Yang. Synthesis of silica modified with aliphatic amine and its adsorption for Pb(Ⅱ)[J]. Environmental Chemistry, 2017, 36(5): 1140-1147. doi: 10.7524/j.issn.0254-6108.2017.05.2016090501
shu

脂肪胺-硅胶的制备与其吸附Pb（Ⅱ）性能

  • 1.

    青岛科技大学, 环境与安全工程学院, 青岛, 266042

  • 基金项目:

    国家自然科学基金（51372129，51572138），山东省自然科学基金（ZR2013DQ002）和青岛市民生科技计划（14-2-3-70-nsh）资助

Synthesis of silica modified with aliphatic amine and its adsorption for Pb(Ⅱ)

  • 1.

    College of Environment and Safety Engineering, Qingdao University of Science and Technology, Qingdao, 266042, China

  • Fund Project: Supported by the National Natural Science Foundation of China(51372129, 51572138), the Natural Science Foundation of Shandong Province of China(ZR2013DQ002)and the Science and Technology Program of Qingdao, China(14-2-3-70-nsh)

  • 摘要: 该研究以二氧化硅、γ-氨丙基三乙氧基硅烷、甲基丙烯酸甲酯和乙二胺为原料合成了脂肪胺-硅胶树脂，并利用FTIR、TG对其结构及官能团接枝率进行分析；利用所制备的脂肪胺-硅胶材料进行了重金属离子Pb（Ⅱ）的吸附研究，考察了吸附时间、温度、pH值及重金属离子对吸附的影响，并利用Langmuir和Freundlich吸附等温方程进行拟合.结果表明，该材料对Pb（Ⅱ）的吸附量达到1.67 mmol·g-1；合成树脂对Pb（Ⅱ）的吸附过程可用Langmuir吸附等温方程进行拟合，根据G.E.Boyd方程可知，吸附过程符合液膜扩散控制机理.
    Abstract: Silica modified with aliphatic amine was prepared using silica gel, (3-aminopropyl)triethyloxysilane, ethylenediamine and methyl methacrylate as raw materials. Its structure and grafting ratio of functional groups were characterized by Fourier-transform infrared spectra (FTIR) and thermogravimetry (TG). The adsorption properties of the modified silica gel for Pb(Ⅱ) was investigated, and the effects of the adsorption time, pH, temperature and initial concentration on the adsorption were studied by the single factor experiments. Furthermore, Langmuir and Freundlich isotherm models were applied to analyze the experimental data. The result exhibited that the maximum adsorption capacity for Pb(Ⅱ) was 1.67 mmol·g-1. The adsorption isotherms were obtained and were fitted to Langmuir equation. In addition, the adsorption process conformed to G.E.Boyd equation, showing that the process followed liquid membrane diffusion mechanism.
  • 加载中
  • [1] 黄艳超, 武雪芳, 周羽化,等. 水环境中锑污染及其修复技术研究进展[J]. 南京师大学报:自然科学版, 2015, 38(4):122-128.

    HUANG Y C, WU X F, ZHOU Y H, et al. Research Progress of antimony contamination in water environment and remediation techniques[J].Journal of Nanjing Normal University(Natural Science Edition), 2015, 38(4):122-128(in Chinese).

    [2] 李义久,相波,王作华,等.高天然淀粉改性水处理剂的研制及其对重金属、染料的吸附[J].化学试剂,2012,34(5):385-387

    ,448. LI Y J, XIANG B, WANG Z H, et al. Preparaion of modified starch and its adsorption properties for heavy metal ions and dyestuffs[J]. Chemical Reagents, 2012,34(5):385-387,448(in Chinese).

    [3] 安增莉, 侯艳伟, 蔡超,等. 水稻秸秆生物炭对Pb(Ⅱ)的吸附特性[J]. 环境化学, 2011, 30(11):1851-1857.

    AN Z L, HOU Y W, CAI C, et al. Lead (Ⅱ) adsorption characteristics on different biochars derived from rice straw[J]. Environmental Chemistry, 2011, 30(11):1851-1857(in Chinese).

    [4] 高宝玉. 水和废水处理用复合高分子絮凝剂的研究进展[J]. 环境化学, 2011, 30(1):337-345.

    GAO B Y. Progress in the research of composite polymeric flocculants for water ans waste treatment[J]. Environmental Chemistry, 2011, 30(1):337-345(in Chinese).

    [5] WANG Q, GAO W, LIU Y, et al. Simultaneous adsorption of Cu(II) and SO2-4 ions by a novel silica gel functionalized with a ditopic zwitterionic Schiff base ligand[J]. Chemical Engineering Journal, 2014, 250(250):55-65.
    [6] 林建伟, 方巧, 詹艳慧. 镧-四氧化三铁-沸石复合材料制备及去除水中磷酸盐和铵[J]. 环境化学, 2015, 34(12):2287-2297.

    LIN J W, FANG Q, ZHAN Y H. Preparation of lanthanum/magnetite/zeolite composite and its application for phosphate and ammonium removal from aqueous solution[J]. Environmental Chemistry, 2015, 34(12):2287-2297(in Chinese).

    [7] 刘海波.生物制剂处理含重金属废水工艺研究[J].湖南有色金属,2012,28(5):53-57.

    LIU H B. Study of Heavy Metals Waste Water Treatment with Biological Agent[J]. Hunan Nonferrous Metals,2012,28(5):53-57(in Chinese).

    [8] 王洪,李志鹏,王超洋,等.水葫芦重金属吸附性能再利用研究[J].环境科学技术,2012,35(7):33-35

    ,121. WANG H, LI Z P, WANG C Y, et al.Heavy Metal Adsorption Properties of Eichhornia crassipes[J]. Environmental Science & Technology, 2012,35(7):33-35,121(in Chinese).

    [9] 钱春香,许燕波,胡黎明,等.一种微生物固结污染体系中Cu2+的研究[J].环境科学与技术,2011,34(12):33-36.

    QIAN C X, XU Y B, HU L M,, et al. Study on Cu2+ in contaminated system mineralized by bacteria[J]. Environmental Science & Technology, 2011,34(12):33-36(in Chinese).

    [10] 赵永明,蒙冕武,刘庆业,等.甘蔗渣活性炭的制备及其活化剂的回收利用[J].材料导报,2011,25(6):116-119.

    ZHAO Y M, MENG M W, LIU Qingye, et al. Preparation of Activated Carbon from Bagasse and Recycling of Activation Agent[J]. Materials Review, 2011,25(6):116-119(in Chinese).

    [11] 程珊珊,杨锡洪,章超桦,等.壳聚糖对Cd2+和Pb2+的吸附作用[J].水产学报,2011,3(35):410-416.

    CHEN S S, YANG X H, ZHANG C H, et al. Adsorption of Cd<sup>2+ and Pb2+ by chitosan. [J]. Journal of Fisheries of China, 2011,3(35):410-416(in Chinese).

    [12] 杨莉,谢宇,邱贤华,等.花生壳残渣制备活性炭及吸附性能测定[J].花生学报,2010,39(2):16-20.

    YANG L, XIE Y, QIU X H, et al. The Activated charcoal prepared by peanut shell residual and the determination of adsorption performance[J]. Journal of Peanut Science, 2010,39(2):16-20(in Chinese).

    [13] 张蕊,葛滢.稻壳基活性炭制备及其对重金属吸附研究[J].环境污染与防治,2011,33(1):41-45

    ,51. ZHANG R, GE Y. Preparation of rice husk-based activated carbon and its adsorption capacity for heavy metals[J]. Environmental Pollution & Control, 2011,33(1):41-45,51(in Chinese).

    [14] DING J, LI Z, LEFEBVRE J, et al. A hybrid enrichment process combining conjugated polymer extraction and silica gel adsorption for high purity semiconducting single-walled carbon nanotubes (SWCNT).[J]. Nanoscale, 2015, 38(7):15741-15747.
    [15] ALEXANDRE G S P, B'ARBARA S M, Luiz F Z. Adsorption and thermochemical data of divalent cations onto silica gel surface modified with humic acid at solid/liquid interface[J].Journal of Hazardous Materials, 2005,120(1-3):243-247.
    [16] ZHANG Y, QU R J, SUN C M. Comparison of synthesis of chelating resin silica-gel-supported diethylenetriamine and its removal properties for transition metal ions[J]. Journal of Hazardous Materials, 2009,163(1):127-135.
    [17] TIAN Y, YIN P, QU R J. Removal of transition metal ions from aqueous solutions by adsorption using a novel hybrid material silica gel chemically modified by triethylenetetraminomethylenephosphonic acid[J].Chemical Engineering Journal,2010,162(2):573-579.
    [18] JAL P K, PATEL S, MISHRA B K. Chemical modification of silica surface by immobilization of functional groups for extractive concentration of metal ions[J].Talanta,2004,62(5):1005-1028.
    [19] 王明华, 曲荣君, 纪春暖,等. 含酰胺结构的硅胶键载二乙烯三胺螯合微粒的合成及其吸附性能[J]. 离子交换与吸附, 2008, 24(5):408-417.

    WANG M H, QU R J, JI C N, et al. Syntheses and adsorption properties of mide-containing SiO2-supported diethylenetriamine chelating resin. [J]. Ion Exchange and Adsorption, 2008,24(5):408-417(in Chinese).

    [20] PEDROSA J, GAMELAS J A F, LOURENCO A F, et al. Surface properties of calcium carbonate modified with silica by sol-gel method[J]. Colloids & Surfaces A Physicochemical & Engineering Aspects, 2016,497:1-7.
    [21] NIU Y Z, QU R J, CHEN H, et.al. Synthesis of silica gel supported salicylaldehyde modified PAMAM dendrimers for the effective removal of Hg (II) from aqueous solution [J]. Journal of Hazardous Materials, 2014, 278: 267-278.
    [22] HERRERA M. U, ICHII T, MURASE K, et.al. Photochemical grafting of methyl groups on a Si (III) surface using a Grignard reagent [J]. Journal of Colloid and Interface Science, 2013, 411(6): 145-151
    [23] RAMÍREZ A, SIERRA L, LEBEAU B, et.al. Formation of Si-H groups during the functionalization of mesoporous silica with Grignard reagents [J]. Microporous and Mesoporous Materials, 2007, 98(1-3): 115-122.
    [24] 吕慧峰,翟建平,李琴,等.酸性甲醛改性对花生壳吸附重金属离子的影响[J].环境污染与防治,2007,29(11):837-840.

    LV H F, ZHAI J P, LI Q, et al. Effects of acidic formaldehyde treatment of peanut hull on its adsorptive capacities for heavy metals[J]. Environmental Pollution & Control, 2007,11(29):837-840(in Chinese).

    [25] 孙昌梅.含亲水性链结构的聚苯乙烯基螯合吸附剂[D].天津:天津大学,2006. SUN C M. Study of polystyrene-based chelating adsorbents with different hydrophilic chain structure. [D].Tianjin:Tianjin University,2006(in Chinese).
    [26] 王增娣, 殷平, 曲荣君,等. 氨基膦酸改性硅胶在乙醇体系中对汞的吸附性能研究[J]. 青岛科技大学学报:自然科学版, 2011, 32(6):588-595.

    WANG Z D, YIN P, QU R J, et al. Adsorption of Hg(Ⅱ) on silica-gel functionalized by triethylenetetraminomethylenephosphonic acid in ethanol solutions.[J]. Journal of Qingdao University of Science and Technology(Natural Science Edition), 2011, 32(6):588-595(in Chinese).

  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  907
  • HTML全文浏览数:  860
  • PDF下载数:  377
  • 施引文献:  0
出版历程
  • 收稿日期:  2016-09-05
  • 刊出日期:  2017-05-15
钱翌, 李少权, 武洋. 脂肪胺-硅胶的制备与其吸附Pb（Ⅱ）性能[J]. 环境化学, 2017, 36(5): 1140-1147. doi: 10.7524/j.issn.0254-6108.2017.05.2016090501
引用本文: 钱翌, 李少权, 武洋. 脂肪胺-硅胶的制备与其吸附Pb（Ⅱ）性能[J]. 环境化学, 2017, 36(5): 1140-1147. doi: 10.7524/j.issn.0254-6108.2017.05.2016090501
shu
QIAN Yi, LI Shaoquan, WU Yang. Synthesis of silica modified with aliphatic amine and its adsorption for Pb(Ⅱ)[J]. Environmental Chemistry, 2017, 36(5): 1140-1147. doi: 10.7524/j.issn.0254-6108.2017.05.2016090501
Citation: QIAN Yi, LI Shaoquan, WU Yang. Synthesis of silica modified with aliphatic amine and its adsorption for Pb(Ⅱ)[J]. Environmental Chemistry, 2017, 36(5): 1140-1147. doi: 10.7524/j.issn.0254-6108.2017.05.2016090501
shu

脂肪胺-硅胶的制备与其吸附Pb（Ⅱ）性能

  • 1. 青岛科技大学, 环境与安全工程学院, 青岛, 266042
  • 收稿日期:  2016-09-05
基金项目:

国家自然科学基金（51372129，51572138），山东省自然科学基金（ZR2013DQ002）和青岛市民生科技计划（14-2-3-70-nsh）资助

摘要: 该研究以二氧化硅、γ-氨丙基三乙氧基硅烷、甲基丙烯酸甲酯和乙二胺为原料合成了脂肪胺-硅胶树脂，并利用FTIR、TG对其结构及官能团接枝率进行分析；利用所制备的脂肪胺-硅胶材料进行了重金属离子Pb（Ⅱ）的吸附研究，考察了吸附时间、温度、pH值及重金属离子对吸附的影响，并利用Langmuir和Freundlich吸附等温方程进行拟合.结果表明，该材料对Pb（Ⅱ）的吸附量达到1.67 mmol·g-1；合成树脂对Pb（Ⅱ）的吸附过程可用Langmuir吸附等温方程进行拟合，根据G.E.Boyd方程可知，吸附过程符合液膜扩散控制机理.
