绣球花状掺锶碳羟基磷灰石对Pb2+的吸附
Study on Pb2+ adsorption by hydrangea-like strontium-doped carbonate hydroxyapatite
-
摘要: 以NH4H2PO4、Ca（NO3）2·4H2O、Sr（NO3）2和尿素[CO（NH2）2]为原材料，通过水热法合成了一种单分散、由纳米片自组装而成的绣球花状三维（3-D）掺锶碳羟基磷灰石（Sr-CHAp），并用于吸附酸性水溶液中的铅离子（Pb2+）.研究了溶液pH、吸附时间、初始浓度对Sr-CHAp材料吸附Pb2+的影响及在其在不同pH条件下的吸附机理.采用XRD、SEM、FI-IR和BET等技术对材料及吸附产物进行表征.结果表明，该吸附剂材料表面具有介孔结构，平均孔隙宽度是11.10 nm，具有较大的比表面积（43.54 m2·g-1），在pH 3时对Pb2+具有较高的饱和吸附量（985.1 mg·g-1）；其等温线吸附数据符合Langmuir模型，动力学吸附数据符合伪二级动力学模型；在酸性溶液中其对Pb2+的吸附主要表现为溶解/沉淀机理，溶液pH值的大小影响吸附后的产物，强酸性条件下有利于PbHPO4的生成，而pH值为3—6时主要生成Pb10（PO4）6（OH）2.Abstract: Using NH4H2PO4,Ca(NO3)2·4H2O,Sr(NO3)2 and urea [CO(NH2)2] as raw materials,monodisperse nanosheets-assembled hydrangea-like three-dimensional (3-D) strontium-doped carbonate hydroxyapatite (Sr-CHAp) was synthesized by a hydrothermal method, and used as an adsorbent for the removal of lead ions (Pb2+) from acidic aqueous solutions. The effects of pH value,contact time and initial concentration of Pb2+ solutions on the adsorption of the Sr-CHAp material and its adsorption mechanism under different pH were studied. The adsorbent and the products were characterized by XRD,SEM,FI-IR and BET etc.. The results show that the obtained Sr-CHAp had a mesoporous structure, of which the average width is 11.10 nm. It had a large specific surface area of 43.54 m2·g-1 and a high adsorption capacity (985.1 mg·g-1) towards Pb2+ at pH 3. The isotherm accords with the Langmuir model, and the kinetic data conform to the pseudo-second order kinetic model. The mechanism of Pb2+ adsorption was attributed to dissolution/precipitation process in acid solutions. The products were different at different pH value. Strong acidic solution was favorable for the formation of PbHPO4 while Pb10(PO4)6(OH)2 was the main product when pH was between 3—6.
-
-
[1] JIANG S D,YAO Q Z,ZHOU G T,et al. Fabrication of hydroxyapatite hierarchical hollow microspheres and potential application in water treatment[J]. Journal of Physical Chemistry C,2012,116(7): 4484-4492. [2] 张俊,王德平,姚爱华,等. 纳米羟基磷灰石对Ni2+的吸附性能及机理研究[J]. 无机材料学报,2009,24(2): 269-274. ZHANG J,WANG D P,YAO A H,et al. Research on adsorption capacity for Ni2+ and mechanism of nano-hydroxyapatite[J]. Journal of Inorganic Materials. 2009,24(2): 269-274(in Chinese).
[3] SHEHA R R. Sorption behavior of Zn(II) ions on synthesized hydroxyapatites[J]. Journal of Colloid and Interface Science,2007,310(1): 18-26. [4] OGAWA S,KATOH M,NUMAKO C,et al. Immobilization of antimony(III) in oxic soil using combined application of hydroxyapatite and ferrihydrite[J]. Water Air and Soil Pollution,2016,227(4): 1-10. [5] 孙玉绣,周松,杨华. 羟基磷灰石纳米粒子制备及其对Pb2+离子的吸附性能[J]. 环境化学,2010,29(6): 1059-1062. SUN Y X,ZHOU S,YANG H. Preparation of hydroxyapatite nanoparticles and its adsorption properties for Pb2+[J]. Environmental Chemistry,2010,29(6): 1059-1062(in Chinese).
[6] 胡田田,仓龙,王玉军,等. 铅和铜离子在纳米羟基磷灰石上的竞争吸附动力学研究[J]. 环境科学,2012,33(8): 2875-2881. HU T T,CANG L,WANG Y J,et al. Competitive adsorption kinetics of aqueous Pb2+ and Cu2+ on nano-HAP surfaces[J]. Environmental Science,2012,33(8): 2875-2881(in Chinese).
[7] SRILAKSHMI C,SARAF R. Ag-doped hydroxyapatite as efficient adsorbent for removal of Congo red dye from aqueous solution: Synthesis,kinetic and equilibrium adsorption isotherm analysis[J]. Microporous and Mesoporous Materials,2016,219: 134-144. [8] NIE Y L,HU C,KONG C P. Enhanced fluoride adsorption using Al(III) modified calcium hydroxyapatite[J]. Journal of Hazardous Materials,2012,233: 194-199. [9] ZHANG F,ZHAO Z S,TAN R Q,et al. Efficient and selective immobilization of Pb2+ in highly acidic wastewater using strontium hydroxyapatite nanorods[J]. Chemical Engineering Journal,2012,203(5): 110-114. [10] CHEN F,ZHU Y J,WANG K W,et al. Surfactant-free solvothermal synthesis of hydroxyapatite nanowire/nanotube ordered arrays with biomimetic structures[J]. Cryst Eng Comm,2011,13(6): 1858-1863. [11] BHARATH G,KUMAR A J,KARTHICK K,et al. Shape evolution and size controlled synthesis of mesoporous hydroxyapatite nanostructures and their morphology dependent Pb(II) removal from waste water[J]. Rsc Advances,2014,4(70): 37446-37457. [12] WANG K W,ZHU Y J,CHEN F,et al. Microwave-assisted synthesis of hydroxyapatite hollow microspheres in aqueous solution[J]. Materials Letters,2011,65(15): 2361-2363. [13] ZHAO X Y,ZHU Y J,ZHAO J,et al. Hydroxyapatite nanosheet-assembled microspheres: Hemoglobin-templated synthesis and adsorption for heavy metal ions[J]. Journal of Colloid and Interface Science,2014,416: 11-18. [14] LIN K L,LIU P Y,WEI L,et al. Strontium substituted hydroxyapatite porous microspheres: Surfactant-free hydrothermal synthesis,enhanced biological response and sustained drug release[J]. Chemical Engineering Journal,2013,222: 49-59. [15] 董黎静,朱志良,仇雁翎,等. 羟基磷灰石及其复合材料对重金属的吸附研究进展[J]. 化学通报,2013,76(5): 405-410. DONG L J,ZHU Z L,QIU Y L,et al. Advance in research of heavy metals removal by hydroxyapatite and its composite[J]. Chemistry Bulletin,2013,76(5): 405-410(in Chinese).
[16] BAI L Z,LI Z P,ZHANG Y,et al. Synthesis of water-dispersible graphene-modified magnetic polypyrrole nanocomposite and its ability to efficiently adsorb methylene blue from aqueous solution[J]. Chemical Engineering Journal,2015,279: 757-766. [17] LIN K L,CHANG J,ZHU Y J,et al. A facile one-step surfactant-free and low-temperature hydrothermal method to prepare uniform 3D structured carbonated apatite flowers[J]. Crystal Growth and Design,2009,9(1): 177-181. [18] DING G J,ZHU Y J,QI C,et al. Amorphous calcium phosphate nanowires prepared using beta-glycerophosphate disodium salt as an organic phosphate source by a microwave-assisted hydrothermal method and adsorption of heavy metals in water treatment[J]. Rsc Advances,2015,50(5): 40154-40162. [19] ZHUANG F Q,TAN R Q,SHEN W F,et al. Magnetic strontium hydroxyapatite microspheres for the efficient removal of Pb(II) from acidic solutions[J]. Journal of Chemical and Engineering Data,2014,59(11): 3873-3881. [20] QI Y C,SHEN J,JIANG Q Y,et al. Hierarchical porous hydroxyapatite microspheres: Synthesis and application in water treatment[J]. Journal of Materials Science,2016,51(5): 2598-2607. [21] EI KHAL H,BATIS N H. Effects of temperature on the preparation and characteristics of hydroxyapatite and its adsorptive properties toward lead[J]. New Journal of Chemistry,2015,39(5): 3597-3607. [22] MOUSA S M,AMMAR N S,IBRAHIM H A. Removal of lead ions using hydroxyapatite nano-material prepared from phosphogypsum waste[J]. Journal of Saudi Chemical Society,2016,20(3): 357-365. [23] FERNANDO M S,DE SILVA R M,DE SILVA K M N. Synthesis, characterization,and application of nano hydroxyapatite and nanocomposite of hydroxyapatite with granular activated carbon for the removal of Pb2+ from aqueous solutions[J]. Applied Surface Science,2015,351: 95-103. [24] RAMESH S T,RAMESHBABU N,GANDHIMATHI R,et al. Adsorptive removal of Pb(II) from aqueous solution using nano-sized hydroxyapatite[J]. Applied Water Science,2013,3(1): 105-113. [25] LIAO D X,ZHENG W,LI X M,et al. Removal of lead(II) from aqueous solutions using carbonate hydroxyapatite extracted from eggshell waste[J]. Journal of Hazardous Materials,2010,177(1-3): 126-130. [26] 唐文清,冯泳兰,李小明. 掺硅碳羟基磷灰石的制备及其对Pb2+的吸附性能[J]. 中国环境科学,2013,33(6): 1017-1024. TANG W Q,FENG Y L,LI X M. Adsorption characteristics of Pb2+ from aqueous solution and synthetic silicon-substituted carbonate hydroxyapatite particles[J]. China Environmental Science,2013,33(6): 1017-1024(in Chinese).
[27] ZHUANG F Q,TAN R Q,SHEN W F,et al. Synthesis of β-type strontium hydrogen phosphate nanosheets and its immobilization of Pb2+ in acidic aqueous solution[J]. Acta Metallurgica Sinica (English Letters),2015,28(4): 438-443. [28] ZHUANG F Q,TAN R Q,SHEN W F,et al. Monodisperse magnetic hydroxyapatite/Fe3O4,microspheres for removal of lead(II) from aqueous solution[J]. Journal of Alloys and Compounds,2015,637: 531-537. -
