鞍山市冬季大气PM2.5中多环芳烃的来源解析及毒性评价

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

张蕾, 姬亚芹, 赵静波, 王伟, 王士宝, 张伟. 鞍山市冬季大气PM2.5中多环芳烃的来源解析及毒性评价[J]. 环境化学, 2017, 36(12): 2668-2675. doi: 10.7524/j.issn.0254-6108.2017030601
引用本文: 张蕾, 姬亚芹, 赵静波, 王伟, 王士宝, 张伟. 鞍山市冬季大气PM2.5中多环芳烃的来源解析及毒性评价[J]. 环境化学, 2017, 36(12): 2668-2675. doi: 10.7524/j.issn.0254-6108.2017030601
shu
ZHANG Lei, JI Yaqin, ZHAO Jingbo, WANG Wei, WANG Shibao, ZHANG Wei. Sources apportionment and toxicity assessment of polycyclic aromatic hydrocarbons in PM2.5 of Anshan city in winter[J]. Environmental Chemistry, 2017, 36(12): 2668-2675. doi: 10.7524/j.issn.0254-6108.2017030601
Citation: ZHANG Lei, JI Yaqin, ZHAO Jingbo, WANG Wei, WANG Shibao, ZHANG Wei. Sources apportionment and toxicity assessment of polycyclic aromatic hydrocarbons in PM2.5 of Anshan city in winter[J]. Environmental Chemistry, 2017, 36(12): 2668-2675. doi: 10.7524/j.issn.0254-6108.2017030601
shu

鞍山市冬季大气PM2.5中多环芳烃的来源解析及毒性评价

  • 1.

    南开大学环境科学与工程学院, 天津, 300350;

  • 2.

    国家环境保护城市空气颗粒物污染防治重点实验室, 天津, 300350;

  • 3.

    鞍山市环境监测中心站, 鞍山, 114004

Sources apportionment and toxicity assessment of polycyclic aromatic hydrocarbons in PM2.5 of Anshan city in winter

  • 1.

    College of Environmental Science and Engineering, Nankai University, Tianjin, 300350, China;

  • 2.

    State Environmental Protection Key Laboratory of Urban Ambient Air Particulate Matter Pollution Prevention and Control, Tianjin, 300350, China;

  • 3.

    An-Shan Environmental Monitoring Center, Anshan, 114004, China

  • 摘要: 2015年1月份采集鞍山市主城区共6个采样点的PM2.5样品，并采集了固定源、移动源、开放源、生物质燃烧源、餐饮油烟等5类污染源，使用GC-MS进行16种多环芳烃（PAHs）质量浓度的分析，运用PMF法和毒性当量分别进行了来源解析和毒性评价.结果表明，鞍山市主城区冬季大气PM2.5中ρ（PAHs）和ρ（BaP）较高，PAHs以3环、4环为主，占PAHs总浓度的82.56%；冬季大气中PAHs主要来源为煤烟尘、焦化尘、移动源、开放源、生物质燃烧源和其他污染源，其贡献率分别为27.8%、24.2%、18.1%、13.4%、4.7%和11.8%；毒性评价表明，鞍山市冬季PAHs的TEQ均值为33.51 ng·m-3，铁西三道街的毒性当量浓度最高.
    Abstract: PM2.5 samples were collected in January 2015 from six main sampling sites in Anshan city. Stationary source,mobile source,open source,biomass burning sources and cooking oil fume were sampled. The concentrations of PAHs were analyzed by GC-MS, and the sources of PAHs were analyzed by PMF and the toxicity assessment was conducted by TEQ. The results showed that the ρ (PAHs) and ρ (BaP) contents in PM2.5 were high,and the three and four ring PAHs were the main PAHs in the city, accounting for 82.56%. The main sources of PAHs in the atmosphere were coal dust, coke dust, mobile source, open source, biomass burning sources and others sources of pollution,the contributions were 27.8%,24.2%,18.1%,13.4%,4.7% and 11.8%,respectively. The toxicity assessment showed that the mean TEQ of PAHs in Anshan was 33.51 ng·m-3,and the TEQ was the highest in TXSDJ.
  • 加载中
  • [1] 尤孝方. 燃烧过程中多环芳烃的生成与数值模拟[D]. 杭州:浙江大学, 2006. YOU X F. Generation and numerical simulation of polycyclic aromatic hydrocarbons in combustion process[D]. Hangzhou:Zhejiang University, 2006(in Chinese).
    [2] LI J, ZHANG G,LI XD, et al. Source seasonality of polycyclic aromatic hydrocarbons (PAHs) in a subtropical city, Guangzhou, South China[J]. Science of the Total Environment, 2006, 355:145-155.
    [3] 王英锋, 张姗姗, 李杏茹,等. 北京大气颗粒物中多环芳烃浓度季节变化及来源分析[J]. 环境化学, 2010, 29(3):369-375.

    WANG Y F, ZHANG SS,LI X R, et al. Seasonal variation and source analysis of polycyclic aromatic hydrocarbons (PAHs) in atmospheric particulates in Beijing[J]. Environmental Chemistry, 2010, 29(3):369-375.(in Chinese).

    [4] WU S, ZHOU JZ, PAN Y, et al. Dioxin distribution characteristics and health risk assessment in different size particles of fly ash from MSWIs in China[J]. Waste Management, 2016, 5(1):113-120.
    [5] LIU J, HU N, SHI X. Characterization and source apportionment of polycyclic aromatic hydrocarbons (PAHs) in Sediments from the Bohai Sea, China[C]. EGU General Assembly Conference. EGU General Assembly Conference Abstracts, 2015.
    [6] El-MUBARAK A H, RUSHDI A I, Al-MUTLAQ K F, et al. Identification and source apportionment of polycyclic aromatic hydrocarbons in ambient air particulate matter of Riyadh, Saudi Arabia.[J]. Environmental Science and Pollution Research, 2014, 21(1):558-567.
    [7] 丁潇, 白志鹏, 韩斌,等. 鞍山市大气PM10中多环芳烃(PAHs)的污染特征及其来源[J]. 环境科学研究, 2011, 24(2):162-171.

    DING X, BAI Z P, HAN B, et al. Pollution characteristics and sources of polycyclic aromatic hydrocarbons (PAHs) in PM10 in Anshan City[J]. Environmental Science Research, 2011, 24(2):162-171(in Chinese).

    [8] LIMU, YI LI MIRE A. BU DA; LIFU,et al.Autumn and wintertime polycyclic aromatic hydrocarbons in PM2.5 and PM2.5-10 from urumqi, China[J].Aerosol and Air Quality Research,2013,13(1):407-414.
    [9] 戴伟, 高佳琪, 曹罡,等. 深圳市郊区大气中PM2.5的特征分析[J]. 环境科学, 2012, 33(6):1952-1957.

    DAI W, GAO JQ, CAO G, et al. Characteristics of PM2.5 in the Atmosphere in Shenzhen Suburbs[J]. Environmental Science, 2012, 33(6):1952-1957(in Chinese).

    [10] 田福林, 陈景文, 敖江婷. 受体模型应用于典型持久性有毒物质的来源解析研究进展[J]. 环境化学, 2009, 28(3):319-327.

    TIAN F L,CHEN J W, AO J T, et al. Application of receptor model to the analysis of typical persistent toxic substances[J]. Environmental Chemistry, 2009, 28(3):319-327(in Chinese).

    [11] LANG Y H, Li GL, Wang X M, et al. Combination of Unmix and PMF receptor model to apportion the potential sources and contributions of PAHs in wetland soils from Jiaozhou Bay, China[J]. Marine Pollution Bulletin, 2015, 90(1-2):129-134.
    [12] 赵雪艳, 任丽红, 姬亚芹,等. 重庆主城区春季大气PM10及PM2.5中多环芳烃来源解析[J]. 环境科学研究, 2014, 27(12):1395-1402.

    ZHAO X Y, REN L H, JI Y Q, et al. Characteristics of polycyclic aromatic hydrocarbons in PM10 and PM2.5 in Spring in Main Urban Area of Chongqing[J]. Environmental Science Research, 2014, 27(12):1395-1402(in Chinese).

    [13] 周颖, 周家斌, 王磊,等. 武汉秋冬季大气PM2.5中多环芳烃的分布特征及来源[J]. 生态环境学报, 2013,22(3):506-511.

    ZHOU Y, ZHOU J B, WANG L, et al. Distribution characteristics and sources of PAHs in PM2.5 in autumn and winter in Wuhan[J]. Journal of Eco-Environmental Sciences, 2013,22(3):506-511(in Chinese).

    [14] 陈刚, 周潇雨, 吴建会,等. 成都市冬季PM2.5中多环芳烃的源解析与毒性源解析[J]. 中国环境科学, 2015, 35(10):3150-3156.

    CHEN G, ZHOU X Y, WU J K, et al. Source analysis and toxicological analysis of polycyclic aromatic hydrocarbons in PM2.5 in winter in China[J]. China Environmental Science, 2015, 35(10):3150-3156(in Chinese).

    [15] PAATERO P, TAPPER U. Analysis of different modes of factor analysis as least squares fit problems[J]. Chemometrics& Intelligent Laboratory Systems, 1993, 18(2):183-194.
    [16] PAATERO P. Least squares formulation of robust non-negative factor analysis[J]. Chemometrics & Intelligent Laboratory Systems, 1997, 37(1):23-35.
    [17] BZDUSEK PA, CHRISTENSEN ER, Li A, et al. Source apportionment of sediment PAHs in Lake Calumet, Chicago:Application of factor analysis with nonnegative constraints.[J]. Environmental Science & Technology, 2004, 38(1):97-103.
    [18] 王苏蓉, 喻义勇, 王勤耕,等. 基于PMF模式的南京市大气细颗粒物源解析[J]. 中国环境科学, 2015, 35(12):3535-3542.

    WANG S R, YU Y Y, WANG Q G, et al. Preparation of atmospheric fine particulate matter in Nanjing based on PMF model[J].Chinese Journal of Environmental Science, 2015, 35(12):3535-3542(in Chinese).

    [19] SMITH D J T, HARRISON R M. Concentrations, trends and vehicle source profile of polynuclear aromatic hydrocarbons in the U.K. atmosphere[J]. Atmospheric Environment, 1996, 30(14):2513-2525.
    [20] KAMALl A, MALIK R N. Comments on polycyclic aromatic hydrocarbons (PAHs) in urban surface dust of Guangzhou, China:Status, sources and human health risk assessment.[J]. Science of th Total Environment, 2014, 478(478):200.
    [21] DACHS J, THOMAS I V, GIGLIOTTI C L, et al. Processes driving the short-term variability of polycyclic aromatic hydrocarbons in the Baltimore and northern Chesapeake Bay atmosphere, USA[J]. Atmospheric Environment, 2002, 36(14):2281-2295.
    [22] OMAR N Y, MON T C, RAHMAN N A, et al. Distributions and health risks of polycyclic aromatic hydrocarbons (PAHs) in atmospheric aerosols of Kuala Lumpur, Malaysia.[J]. Science of the Total Environment, 2006, 369(1-3):76-81.
    [23] ZHAO Z B, LIU K, XIE W, et al. Soluble polycyclic aromatic hydrocarbons in raw coals[J]. Journal of Hazardous Materials, 2000, 73(1):77-85.
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1284
  • HTML全文浏览数:  1211
  • PDF下载数:  203
  • 施引文献:  0
出版历程
  • 收稿日期:  2017-03-06
  • 刊出日期:  2017-12-15
张蕾, 姬亚芹, 赵静波, 王伟, 王士宝, 张伟. 鞍山市冬季大气PM2.5中多环芳烃的来源解析及毒性评价[J]. 环境化学, 2017, 36(12): 2668-2675. doi: 10.7524/j.issn.0254-6108.2017030601
引用本文: 张蕾, 姬亚芹, 赵静波, 王伟, 王士宝, 张伟. 鞍山市冬季大气PM2.5中多环芳烃的来源解析及毒性评价[J]. 环境化学, 2017, 36(12): 2668-2675. doi: 10.7524/j.issn.0254-6108.2017030601
shu
ZHANG Lei, JI Yaqin, ZHAO Jingbo, WANG Wei, WANG Shibao, ZHANG Wei. Sources apportionment and toxicity assessment of polycyclic aromatic hydrocarbons in PM2.5 of Anshan city in winter[J]. Environmental Chemistry, 2017, 36(12): 2668-2675. doi: 10.7524/j.issn.0254-6108.2017030601
Citation: ZHANG Lei, JI Yaqin, ZHAO Jingbo, WANG Wei, WANG Shibao, ZHANG Wei. Sources apportionment and toxicity assessment of polycyclic aromatic hydrocarbons in PM2.5 of Anshan city in winter[J]. Environmental Chemistry, 2017, 36(12): 2668-2675. doi: 10.7524/j.issn.0254-6108.2017030601
shu

鞍山市冬季大气PM2.5中多环芳烃的来源解析及毒性评价

  • 1.  南开大学环境科学与工程学院, 天津, 300350;
  • 2.  国家环境保护城市空气颗粒物污染防治重点实验室, 天津, 300350;
  • 3.  鞍山市环境监测中心站, 鞍山, 114004
  • 收稿日期:  2017-03-06

摘要: 2015年1月份采集鞍山市主城区共6个采样点的PM2.5样品，并采集了固定源、移动源、开放源、生物质燃烧源、餐饮油烟等5类污染源，使用GC-MS进行16种多环芳烃（PAHs）质量浓度的分析，运用PMF法和毒性当量分别进行了来源解析和毒性评价.结果表明，鞍山市主城区冬季大气PM2.5中ρ（PAHs）和ρ（BaP）较高，PAHs以3环、4环为主，占PAHs总浓度的82.56%；冬季大气中PAHs主要来源为煤烟尘、焦化尘、移动源、开放源、生物质燃烧源和其他污染源，其贡献率分别为27.8%、24.2%、18.1%、13.4%、4.7%和11.8%；毒性评价表明，鞍山市冬季PAHs的TEQ均值为33.51 ng·m-3，铁西三道街的毒性当量浓度最高.
