预浓缩-气相色谱法分析30种挥发性有机物气体标准样品
Analysis of standard gas mixture of 30 volatile organic compounds by gas chromatography coupled with preconcentration
-
摘要: 采用预浓缩-气相色谱法测定30种挥发性有机物（VOCs）气体标准样品，根据不同条件下各组分响应值和相对响应值的变化对分析方法进行了优化，考察了各级冷阱冷冻温度、解析时间和解析流速对测定结果的影响.结果表明，在一级冷阱冷冻温度为-185℃，解析流速为20 mL·min-1，解析时间120 s；二级冷阱冷冻温度为-50℃，解析时间1 s；三级冷阱冷冻温度为-185℃条件下样品的测定结果最优，采用优化后的实验条件对样品重复分析6次，各组分RSD在1.1%—2.4%之间，结果表明该方法具有良好的精密度.可为研究环境监测用多组分混合的低浓度VOCs类气体标准样品的研制提供技术支持.
-
关键词:
- 预浓缩 /
- 挥发性有机物(VOCs) /
- 标准样品 /
- 优化
Abstract: A method for the determination of the standard gas mixture of 30 volatile organic compounds by gas chromatography combined with preconcentration was developed. The method was optimized according to the response value and relative response value of each component under different conditions. The influence of freezing temperature, desorption time and flow rate during desorption was evaluated. The optimized conditions were -185℃ freezing temperature, 20 mL·min-1 flow rate, and 120 s desorption time for trap 1, -50℃ freezing temperature and 1 s desorption time for trap 2, and -185℃ freezing temperature for trap3. The optimized conditions were used to analyze the samples for six times, and the relative standard deviations(RSDs) was in the range of 1.1%-2.4%. The results showed that the method had good precision.-
Key words:
- preconcentration /
- VOCs /
- standard gas /
- optimized
-
-
[1] ATKINSON R, AREY J. Atmospheric degradation of volatile organic compounds[J]. Chemical Reviews, 2003, 103(12):4605-4638. [2] TSIGARIDISA K, KANNKIDOUM. Secondary organic aerosol importance in the future atmosphere[J]. Atmospheric Environment, 2007, 41(22):4682-4692. [3] 张远航,邵可声,唐孝炎,等. 中国城市光化学烟雾污染研究[J]. 北京大学学报:自然科学版,1998,34(2/3):392 -399. ZHANG Y H, SHAO K S, TANG X Y, et al. The study of urban photochemical smog pollution in China[J]. Acta Scientiarum Naturalium Universitatis Pekinensis, 1998, 34(2/3):392-399(in Chinese).
[4] USEPA. Photochemical assessment monitoring stations implementation manual[R]. U.S. Environmental Protection Agency, 1994, EPA-454/B-93-051. [5] USEPA. Technical assistance document for sampling and analysis of ozone precursors[R]. U.S. Environmental Protection Agency, 1998, EPA/600-R-98/161. [6] USEPA. TO-15, Determination of volatile organic compounds(VOCs) in air collected in specially-prepared canisters and anaylzed by gas chromatography/mass spectrometry(GC/MS)[R]. U.S. Environmental Protection Agency, 1999, EPA/625/R-96/010b. [7] USEPA. TO-17, Determination of volatile organic compounds in ambient air using active sampling onto sorbent tubes[R]. U.S. Environmental Protection Agency, 1999, EPA/625/R-96/010b. [8] 环境保护部. 环境空气挥发性卤代烃的测定活性炭吸附-二硫化碳解析/气相色谱法:HJ 645-2013[S]. 北京:中国环境科学出版社,2013-7-1. Environmental Protection Department. Ambient air-determination of volatile halogenated hydrocarbons-activated charcoal adsorption and carbon disulfide desorption/gas charomatographic methd:HJ 645-2013 [S]. Beijing:China Environmental Science Press, 2013-7-1(in Chinese).
[9] 环境保护部. 环境空气挥发性有机物的测定吸附管采样-热脱附/气相色谱-质谱法:HJ 644-2013[S]. 北京:中国环境科学出版社,2013-7-1. Environmental Protection Department. Ambient air-determination of volatile organic compounds-sorbent adsorption and thermal desorption/gas chromatography mass spectrometry method:HJ 644-2013 [S]. Beijing:China Environmental Science Press, 2013-7-1(in Chinese).
[10] 环境保护部. 环境空气挥发性有机物的测定罐采样/气相色谱-质谱法:HJ 759-2015[S]. 北京:中国环境科学出版社,2015-12-1. Environmental Protection Department. Ambient air-determination of volatile organic compounds-collected by specially-prepared canistersand analyzed by gas chromatography/mass spectrometry:HJ 759-2015 [S]. China Environmental Science Press, 2015-12-1(in Chinese).
[11] 王伯光,张远航,邵敏,等. 预浓缩-GC-MS技术研究室内空气中挥发性有毒有机物[J]. 环境化学,2001,20(6):606-615. WANG B G, ZHANG Y H, SHAO M, et al. Study of volatile organic compounds from indoors by preconcentrator-GC-MS[J]. Environmental Chemistry, 2001, 20(6):606-615(in Chinese).
[12] 肖珊美,何桂英,陈章跃. 苏玛罐采样预浓缩-GC-MS测定空气中的挥发性有机化合物[J]. 光谱实验室,2006,23(4):671-675. XIAO S M, HE G Y, CHEN Z Y. Determination of volatile organic compounds in ambient air using summa canisters with subsequent analysis by GC-MS[J]. Chinese Journal of spectroscopy Laboratory, 2006, 23(4):671-675(in Chinese).
[13] 刘雅婷,彭跃,白志鹏,等. 沈阳市大气挥发性有机物(VOCs)污染特征[J]. 环境科学,2011,32(9):2777-2785. LIU Y T, PENG Y, BAI Z P, et al. Characterization of atmospheric volatile organic compounds in Shenyang[J]. Environmental Science, 2011, 32(9):2777-2785(in Chinese).
[14] 梁榕源. 预冷冻浓缩系统与气相色谱-质谱联用测定空气中挥发性有机物[J]. 中国环境监测,2008,24(1):17-20. LIANG R Y. Determination of volatile organic compounds in environmental air by cryo-concentration/GCMS[J]. Environmental Monitoring in China, 2008, 24(1):17-20(in Chinese).
[15] 朱海俭,黄学敏,曹利,等. 预浓缩与GC-MS联用分析垃圾填埋场恶臭气体[J]. 中国环境监测,2012,28(4):91-94. ZHU H J, HUANG X M, CAO L, et al. Determination of landfill gas by gas chromatograph-mass spectrometer coupled preconcentration techniques method[J]. Environmental Monitoring in China, 2012, 28(4):91-94(in Chinese).
[16] [17] 祁心,郝庆菊,吉东生,等. 重庆市北碚城区大气中VOCs组成特征研究[J]. 环境科学,2014,35(9):3293-3301. QI X, HAO Q J, JI D S, et al. Composition characteristics of atmospheric volatile organic compounds in the urban area of Beibei district, Chongqing[J]. Environmental Science, 2014, 35(9):3293-3301(in Chinese).
[18] 李宁,王倩,郭健,等. 氮气中六种氯代烷烃混合标准气体的研制[J]. 色谱,2010,28(5):521-524. LI N, WANG Q, GUO J, et al. Development of standard gas mixture of six chlorinated hydrocarbons in nitrogen[J]. Chinese Journal of Chromatography, 2010, 28(5):521-524(in Chinese).
[19] 李宁,范洁,王倩,等. 环境监测用5种氯代烯烃混合气体标准样品研制[J]. 中国环境监测,2014,30(5):101-104. LI N, FAN J, WANG Q, et al. Development of a standard reference material containing 5 chlorinated hydrocarbons for environmental monitoring[J]. Environmental Monitoring in China, 2014, 30(5):101-104(in Chinese).
[20] 刘涛,王倩,樊强,等. 氮气中1,3-丁二烯气体标准样品的研制[J]. 中国环境监测,2011,27(6):40-45. LIU T, WANG Q, FAN Q, et al. Study on preparation of standard gas of 1,3-butadiene in nitrogen[J]. Environmental Monitoring in China, 2011, 27(6):40-45(in Chinese).
-
