聚苯乙烯泡沫中六溴环十二烷(HBCD)释放速率测定方法

,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

石亚楠, 詹发强, 袁和平, 于颖, 王龙星, 张海军, 陈吉平. 聚苯乙烯泡沫中六溴环十二烷(HBCD)释放速率测定方法[J]. 环境化学, 2018, 37(2): 264-270. doi: 10.7524/j.issn.0254-6108.2017071104
引用本文: 石亚楠, 詹发强, 袁和平, 于颖, 王龙星, 张海军, 陈吉平. 聚苯乙烯泡沫中六溴环十二烷(HBCD)释放速率测定方法[J]. 环境化学, 2018, 37(2): 264-270. doi: 10.7524/j.issn.0254-6108.2017071104
shu
SHI Ya, ZHAN Faqiang, YUAN Heping, YU Ying, WANG Longxing, ZHANG Haijun, CHEN Jiping. A new method for measuring the emission rate of hexabromocyclododecane (HBCD) from polystyrene foam[J]. Environmental Chemistry, 2018, 37(2): 264-270. doi: 10.7524/j.issn.0254-6108.2017071104
Citation: SHI Ya, ZHAN Faqiang, YUAN Heping, YU Ying, WANG Longxing, ZHANG Haijun, CHEN Jiping. A new method for measuring the emission rate of hexabromocyclododecane (HBCD) from polystyrene foam[J]. Environmental Chemistry, 2018, 37(2): 264-270. doi: 10.7524/j.issn.0254-6108.2017071104
shu

聚苯乙烯泡沫中六溴环十二烷(HBCD)释放速率测定方法

  • 1.

    大连海事大学环境科学与工程学院, 大连, 116026;

  • 2.

    中国科学院大连化学物理研究所, 中国科学院分离分析化学重点实验室, 大连, 116023

  • 基金项目:

    国家自然科学基金（21477125）和国家重点基础研究发展计划（973计划）（2015CB453100）资助.

A new method for measuring the emission rate of hexabromocyclododecane (HBCD) from polystyrene foam

  • 1.

    College of Environmental Sciences and Engineering, Dalian Maritime University, Dalian, 116026, China;

  • 2.

    CAS Key Laboratory of Separation Science for Analytical Chemistry, Dalian Institute of Chemical Physics, Chinese Academy of Sciences, Dalian, 116023, China

  • Fund Project: Supported by the National Natual Science Foundation of China (21477125) and the National Basic Research Program of China (973 Program,2015CB453100).

  • 摘要: 本研究构建了适用于测定材料中半挥发性有机物释放速率的新型释放池装置，采用此释放池装置测定发泡聚苯乙烯（EPS）泡沫板中六溴环十二烷（HBCD）在60℃条件下的释放速率，并建立了HBCD的挥发释放模型.3种主要的HBCD非对映体（α-HBCD、β-HBCD和γ-HBCD）的释放行为并不存在明显差异；HBCD在吹扫气体中的浓度在前12 d逐渐增加，然后趋于稳定状态.HBCD在吹扫气体和释放池内壁间存在分配平衡，指数方程可以很好描述HBCD在释放池内壁的吸附水平与其在吹扫气体中浓度水平之间的关系.EPS在60℃条件下HBCD的释放速率为246.5 ng·m-2·d-1.释放模型模拟结果表明，HBCD在60℃条件下的释放主要依赖于其材料-气相分配系数K和对流传质系数hm，基本不受内部扩散系数D值的影响.
    Abstract: A new emission chamber was constructed for the measurments of the emission rates of semi-volatile organic compounds from materials. This emission chamber was used to measure the emission rate of hexabromocyclododecane (HBCD) from expanded polystyrene (EPS) foam at 60℃,and an emission model describing HBCD emission was developed. No significant difference was observed for the emission behavior of the three main HBCD diastereomers (α-HBCD,β-HBCD and γ-HBCD). The concentration of HBCD in purge gas gradually increased with time during the initial 12 days,and then leveled off. There was a partitioning equilibrium of HBCD between gas phase and emission chamber internal surface,and an exponential function could well fit the relationship between levels of HBCD adsorbed on the emission chamber internal surface and levels of HBCD in purge gas. The measured emission rate of HBCD from EPS foam was 246.5 ng·m-2·d-1 at 60℃. The simulation results of emission model indicated that HBCD emission was mainly controlled by material-gas partition coefficient K and convective mass-transfer coefficient hm,whereas independent of material-phase diffusion coefficient D at 60℃.
  • 加载中
  • [1] YI S,LIU J G,JIN J,et al. Assessment of the occupational and environmental risks of hexabromocyclododecane (HBCD) in China[J]. Chemosphere,2016,150:431-437.
    [2] ZHANG J,WILLIAMS T D,ABDALLAH M A,et al. Transcriptomic and metabolomic approaches to investigate the molecular responses of human cell lines exposed to the flame retardant hexabromocyclododecane (HBCD)[J]. Toxicology in Vitro,2015,29(8):2116-2123.
    [3] BARGHI M,SHIN E S,SON M H,et al. Hexabromocyclododecane (HBCD) in the Korean food basket and estimation of dietary exposure[J]. Environmental Pollution,2016,213:268-277.
    [4] United National Environment Program. Proposal to list hexabromocyclododecane in Annex A to Covention (UNEP/POPs/POPRC.5/INF/16)[C].Persistent Organic Pollutants Review Committee Fifth meeting,Geneva,12-16 October 2009.
    [5] ZHANG H,KUO YY,GERECKE A C,et al. Co-release of hexabromocyclododecane (HBCD) and nano-and microparticles from thermal cutting of polystyrene foams[J]. Environmental Science & Technology,2012,46(20):10990-10996.
    [6] UHDE E,BORGSCHULTE A,SALTHAMMER T. Characterization of the field and laboratory emission cell-FLEC:Flow field and air velocities[J]. Atmospheric Environment,1998,32(4):773-781.
    [7] KLENO J G,CLAUSEN P A,WESCHLER C J,et al. Determination of ozone removal rates by selected building products using the FLEC emission cell[J]. Environmental Science & Technology,2001,35(12):2548-2553.
    [8] CLAUSEN P A,HANSEN V,GUNNARSEN L,et al. Emission of di-2-ethylhexyl phthalate from PVC flooring into air and uptake in dust:Emission and sorption experiments in FLEC and CLIMPAQ[J]. Environmental Science & Technology,2004,38(9):2531-2537.
    [9] JENSEN B,WOLKOFF P,WILKINS C K,et al. Characterization of linoleum.1. measurement of volatile organic-compounds by use of the field and laboratory emission cell,flec[J]. Indoor Air,1995,5(1):38-43.
    [10] COX S S,LITTLE J C,HODGSON A T. Predicting the emission rate of volatile organic compounds from vinyl flooring[J]. Environmental Science & Technology,2002,36(4):709-714.
    [11] SCHRIPP T,NACHTWEY B,TOELKE J,et al. A microscale device for measuring emissions from materials for indoor use[J]. Analytical and Bioanalytical Chemistry,2007,387(5):1907-1919.
    [12] ISO 16000-25-2011.Indoor air-part 25:Determination of the emission of semi-volatile organic compounds by building products-Micro-chamber method,2011[S].
    [13] 何余生,李忠,奚红霞,等. 气固吸附等温线的研究进展[J]. 离子交换与吸附2004,20(4):376-384.

    HE Y S,LI Z,XI H X,et al. The research progress of gas-solid adsorption isotherm[J]. Ion Exchange and Adsorption, 2004,20(4):376-384(in Chinese).

    [14] XU Y,LITTLE J C. Predicting emissions of SVOCs from polymeric materials and their interaction with airborne particles[J]. Environmental Science & Technology,2006,40(2):456-461.
    [15] LI F,NIU J L. An inverse technique to determine volatile organic compounds diffusion and partition coefficients in dry building material[J]. Heat and Mass Transfer,2005,41(9):834-842.
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1568
  • HTML全文浏览数:  1500
  • PDF下载数:  384
  • 施引文献:  0
出版历程
  • 收稿日期:  2017-07-11
  • 刊出日期:  2018-02-15
石亚楠, 詹发强, 袁和平, 于颖, 王龙星, 张海军, 陈吉平. 聚苯乙烯泡沫中六溴环十二烷(HBCD)释放速率测定方法[J]. 环境化学, 2018, 37(2): 264-270. doi: 10.7524/j.issn.0254-6108.2017071104
引用本文: 石亚楠, 詹发强, 袁和平, 于颖, 王龙星, 张海军, 陈吉平. 聚苯乙烯泡沫中六溴环十二烷(HBCD)释放速率测定方法[J]. 环境化学, 2018, 37(2): 264-270. doi: 10.7524/j.issn.0254-6108.2017071104
shu
SHI Ya, ZHAN Faqiang, YUAN Heping, YU Ying, WANG Longxing, ZHANG Haijun, CHEN Jiping. A new method for measuring the emission rate of hexabromocyclododecane (HBCD) from polystyrene foam[J]. Environmental Chemistry, 2018, 37(2): 264-270. doi: 10.7524/j.issn.0254-6108.2017071104
Citation: SHI Ya, ZHAN Faqiang, YUAN Heping, YU Ying, WANG Longxing, ZHANG Haijun, CHEN Jiping. A new method for measuring the emission rate of hexabromocyclododecane (HBCD) from polystyrene foam[J]. Environmental Chemistry, 2018, 37(2): 264-270. doi: 10.7524/j.issn.0254-6108.2017071104
shu

聚苯乙烯泡沫中六溴环十二烷(HBCD)释放速率测定方法

  • 1.  大连海事大学环境科学与工程学院, 大连, 116026;
  • 2.  中国科学院大连化学物理研究所, 中国科学院分离分析化学重点实验室, 大连, 116023
  • 收稿日期:  2017-07-11
基金项目:

国家自然科学基金（21477125）和国家重点基础研究发展计划（973计划）（2015CB453100）资助.

摘要: 本研究构建了适用于测定材料中半挥发性有机物释放速率的新型释放池装置，采用此释放池装置测定发泡聚苯乙烯（EPS）泡沫板中六溴环十二烷（HBCD）在60℃条件下的释放速率，并建立了HBCD的挥发释放模型.3种主要的HBCD非对映体（α-HBCD、β-HBCD和γ-HBCD）的释放行为并不存在明显差异；HBCD在吹扫气体中的浓度在前12 d逐渐增加，然后趋于稳定状态.HBCD在吹扫气体和释放池内壁间存在分配平衡，指数方程可以很好描述HBCD在释放池内壁的吸附水平与其在吹扫气体中浓度水平之间的关系.EPS在60℃条件下HBCD的释放速率为246.5 ng·m-2·d-1.释放模型模拟结果表明，HBCD在60℃条件下的释放主要依赖于其材料-气相分配系数K和对流传质系数hm，基本不受内部扩散系数D值的影响.
