A/SMBBR处理生活污水效能研究及生物膜菌群结构分析

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

贾晓硕, 谢者行, 李卫平, 杨文焕, 敬双怡, 刘文加. A/SMBBR处理生活污水效能研究及生物膜菌群结构分析[J]. 环境化学, 2018, 37(12): 2651-2658. doi: 10.7524/j.issn.0254-6108.2018010501
引用本文: 贾晓硕, 谢者行, 李卫平, 杨文焕, 敬双怡, 刘文加. A/SMBBR处理生活污水效能研究及生物膜菌群结构分析[J]. 环境化学, 2018, 37(12): 2651-2658. doi: 10.7524/j.issn.0254-6108.2018010501
shu
JIA Xiaoshuo, XIE Zhexing, LI Weiping, YANG Wenhuan, JING Shuangyi, LIU Wenjia. A/SMBBR treatment effectiveness of domestic sewage research and structural analysis of biofilm flora[J]. Environmental Chemistry, 2018, 37(12): 2651-2658. doi: 10.7524/j.issn.0254-6108.2018010501
Citation: JIA Xiaoshuo, XIE Zhexing, LI Weiping, YANG Wenhuan, JING Shuangyi, LIU Wenjia. A/SMBBR treatment effectiveness of domestic sewage research and structural analysis of biofilm flora[J]. Environmental Chemistry, 2018, 37(12): 2651-2658. doi: 10.7524/j.issn.0254-6108.2018010501
shu

A/SMBBR处理生活污水效能研究及生物膜菌群结构分析

  • 1.

    内蒙古科技大学能源与环境学院, 包头, 014010;

  • 2.

    北汽特来电(北京)新能源科技有限公司, 北京, 100176

  • 基金项目:

    内蒙古高校项目（NJZY16164）和内蒙古科技大学产学研项目（PY201501）资助.

A/SMBBR treatment effectiveness of domestic sewage research and structural analysis of biofilm flora

  • 1.

    School of Energy and E nvironment, Inner Mongolia University of Science and Technology, Baotou, 014010, China;

  • 2.

    Beijing AUV Bus Branch Company of Beiqi Foton Motor Co., Ltd., Beijing, 100176, China

  • Fund Project: Supported by Inner Mongolia University Project (NJZY16164) and the Production and Research Project of Inner Mongolia University of Science and Technology(PY201501).

  • 摘要: 采用SDC-03作为生物载体，考察特异性移动床生物膜法对生活污水中有机污染物的去除效果，并运用Illumina Hiseq高通量测序技术对微生物进行分析.实验结果表明，COD、氨氮和总氮的平均出水浓度分别为25.65 mg·L-1、5.14 mg·L-1、14.55 mg·L-1，平均去除率分别为91.05%、92.39%、83.44%.该工艺能适应较低温度，最佳HRT和DO浓度分别为10-12 h、3-4 mg·L-1之间.采用Chao1指数、Shannon指数、Simpson指数及PD whole tree值等指数对微生物种群多样性进行分析.对反应器的微生物从门和属两个科目进行分析，得出门水平丰度前10的微生种和属的物种组成.门水平前十的物种分别为变形菌门（Proteobacteria）、拟杆菌门（Bacteroidetes）、芽单胞菌门（Gemmatimonadetes）、Saccharibacteria、厚壁菌门（Firmicutes）、绿弯菌门（Chlorofflexi）、放线菌门（Actinobacteria）、硝化螺旋菌门（Nitrospira）、酸杆菌门（Acidobacteria）、Thermomicrobia.变形菌门和拟杆菌门大量存在于在好氧池中，芽单胞菌门和厚壁菌门有助于反硝化反应的进行；在属水平中得知未知的菌属占大部分.
    Abstract: Using SDC-03 as the biological carrier, this work examined the removal efficiency of the organic pollutants in domestic sewage by A/SMBBR treatment and analyzed the microorganisms therein by the Illumina Hiseq high-throughput sequencing technology. The experiments showed demonstrated that the average effluent concentrations of COD, ammonia nitrogen and total nitrogen were respectively 25.65 mg·L-1, 5.14 mg·L-1 and 14.55 mg·L-1, with average removal ratios of 91.05%, 92.39% and 83.44%. It was demonstrated that this process could better accommodate low temperatures. The most favorable hydraulic retention time remained between 10 and 12 hours, and the optimum dissolved oxygen concentration stayed between 3 and 4 mg·L-1. The microbial diversity was analyzed through Chao1 index, Shannon index, Simpson index, and PD whole tree methods. Microorganisms in the reactor were observed at both the phylum and the genus level. Based on the abundance level, the top 10 species of both phyluon and genus were derived. At the phylum level, Proteobacteria, Bacteroidetes, Gemmat imonadetes, Saccharibacteria, Firmicutes, Chlorofflexi, Actinobacteria, Nitrospira, Acidobacte-ria and Thermomicrobia were among the top 10. A large amount of Proteobacteria and Bacteroidetes were observed in aerobic tanks and Gemmatimonadetes and thick-walled fungi proved to be helpful for denitrification. At the genus level, unknown bacteria accounted for the most.
  • 加载中
  • [1] RUSTEN B, HELLSTRÖM B G, HELLSTRÖM F, et al. Pilot testing and preliminary design of moving bed biofilm reactors for nitrogen removal at the FREVAR wastewater treatment plant[J]. Water Science & Technology, 2000, 41(4):13-20.
    [2] 中丹康灵(北京)生物技术有限公司.生物挂膜填料:201330132291. 6[P]. 2013-12-01.

    Dan kangling (Beijing) biological technology co., LTD. Biofilm packing:201330132291. 6[P]. 2013-12-01(in Chinese).

    [3] SHIN D H, SHIN W S, KIM Y H, et al. Application of a combined process of moving-bed biofilm reactor (MBBR) and chemical coagulation for dyeing waste-water treatment[J]. Water Science and Technology,2006,54(9):181-189.
    [4] CHEN S, SUN D, CHUNG J S. Treatment of pesticide wastewater by moving-bed biofilm reactor combined with Fenton-coagulation pretreatment[J]. Journal of Hazardous Materials, 2007, 144(1):577-584.
    [5] 郑敏,杨波,王诚文,等. 中试MBBR装置强化氨氮去除速率的影响条件研究[J]. 中国环境科学,2012,32(10):1778-1783.

    ZHENG M, YANG B, WANG C W, et al. Enhanced ammonia removal rate in a pilot-scale MBBR[J]. China Environmental Science. 2012,32(10):1778-1783(in Chinese).

    [6] ZHANG S, WANG Y, HE W, et al. Impacts of temperature and nitrifying community on nitrification kinetics in a moving-bed biofilm reactor treating polluted raw water[J]. Chemical Engineering Journal, 2014, 236(3):242-250.
    [7] BISWAS K, TAYLOR M W, TURNER S J. Successional development of biofilms in moving bed biofilm reactor (MBBR) systems treating municipal wastewater.[J]. Applied Microbiology & Biotechnology, 2014, 98(3):1429-1440.
    [8] 赵倩. 特异性流化生物膜(SMBBR)处理发酵类制药废水中试研究[D].包头:内蒙古科技大学,2015. ZHAO Q. Treatment of fermentation type of pharmaceutical wastewater by SMBBR[D]. Inner Mongolia:Mongolia University of Science and Technology, 2015(in Chinese).
    [9] 李卫平,卢雪枫,杨文焕,等. 厌氧/特异性移动床生物膜反应器(A/SMBBR)组合工艺处理农药含酚废水[J].环境工程学报,2017,11(3):1570-1574.

    LI W P, LU X F, YANG W H, et al. Treatment of pesticides phenol-containing wastewater by anaerobic-specific moving bed biofilm reactor (A/SMBBR) combined process[J]. Chinese Journal of Environmental Engineering, 2017,11(3):1570-1574(in Chinese).

    [10] 李卫平,李杰,朱浩君,等.SMBBR工艺不同填料处理生活污水[J].环境工程学报,2015,9(9):4427-4432.

    LI W P, LI J, ZHU H J, et al. Treatment of domestic sewage by SMBBR process with different fillers[J]. Chinese Journal of Environmental Engineering, 2015,9(9):4427-4432(in Chinese).

    [11] 于玲红,隋秀斌,杨文焕,等. AMBBR/SMBBR与A/O工艺处理石油发酵工业废水的对比研究[J].现代化工,2017,37(3):179-184.

    YU L H, SUI X B, YANG W H, et al. A comparative study on treatment of petroleum fermentation industrial wastewater by AMBBR/SMBBR and A/O process[J]. Modern Chemical Industry, 2017,37(3):179-184(in Chinese).

    [12] 韩剑宏,赵倩,朱浩君,等.SMBBR预处理发酵类制药废水[J].化工环保,2015, 35(2):169-173.

    HAN J H, ZHAO Q, ZHU H J, et al. Pretreatment of pharmaceutical fermentation wastewater by SMBBR[J]. Environmental protection of chemical industry, 2015, 35(2):169-173(in Chinese).

    [13] 韩剑宏,李海洋,敬双怡,等. A/SMBBR组合工艺处理DOP生产废水[J].工业水处理,2017,34(4):43-46.

    HAN J H, LI H Y, JING S Y, et al. Treatment of wastewater from DOP production by A/SMBBR combined process[J]. Industrial Water Treatment, 2017,34(4):43-46(in Chinese).

    [14] 张鹏.MBBR法处理城市污水去除污染物的特性研究[D].长沙:湖南大学,2015. ZHANG P. Study on the characters of treating urban sewage to remove pollutants with MBBR process[D]. Changsha:Hunan Universit, 2015(in Chinese).
    [15] 国家环境保护总局.水和废水检测分析方法[M].4版.北京:中国环境科学出版社,2002:33-34. National environmental protection administration. water and wastewater detection and analysis methods[M]. Beijing:China Environmental Science Press, 2002:33

    -34(in Chinese).

    [16] 张自杰,林荣忱,金儒霖.排水工程(第四版)[M]. 北京:中国建筑工业出版社,2000. ZHANG Z J, LIN R C, JIN R L. Drainage works (fourth edition)[M]. Beijing:China Architecture Industry Press, 2000(in Chinese).
    [17] 唐若凯, 肖作义, 杨文焕,等. 多级SMBBR工艺处理低C/N比城市污水中试研究[J]. 应用化工, 2017, 46(9):1728-1732.

    TANG R K, XIAO Z Y, YANG W H, et al. Biological nutrient removal in multi-SMBBR process when treating low C/N ratio municipal wastewater[J]. Applied Chemical Industry, 2017, 46(9):1728-1732(in Chinese).

    [18] 顾夏声,胡洪营,文湘华,等.水处理生物学[M].北京:中国建筑工业出版社,2006. GU X S, HU H Y, WEN X H, et al. Water treatment biology[M]. Beijing:China construction Industry Press, 2006(in Chinese).
    [19] 李军,杨秀山,彭永臻,等.微生物与水处理工程[M].北京:化学工业出版社,2002. LI J, YANG X S, PENG Y Z, et al. Microbial and water treatment engineering[M]. Beijing:Chemical Industry Press, 2002(in Chinese).
    [20] 肖可可, 周律, 贺北平,等. 城市污水A2/O移动床生物膜工艺菌群结构分析[J]. 中国给水排水, 2016,32(9):20-24.

    XIAO K K, ZHOU L, HE B P, et al. Analysis of microbial community structure in A2/O MBBR system for treatment of municipal wastewater[J]. China Water &Wastewater, 2016, 32(9):20-24(in Chinese).

    [21] 聂小军.基于高通量测序技术的小麦和紫茎泽兰基因组学初步研究[D]. 西安:西北林业大学博士论文,2013. NIE X J, Preliminary genomic study of two non-mondel plants:Wheat and crofton weed through high-theroughput sequencing technology[D]. Xian:Doctoral Thesis Of Northwest Forestry University, 2013(in Chinese).
    [22]
    [23] 石芳永,宋奔奔,傅松哲.竹子填料海水曝气生物滤器除氮性能和硝化细菌群落变化研究[J].渔业科学进展,2009,3(1):92-96.

    SHI F Y, SONG B B, FU S Z, et al. Pilot study on ammonium removal efficiency and nitrifying bacteria variety in marine biofilter charged with bamboo substrate[J]. Progress in Fishery, 2009,3(1):92-96(in Chinese).

    [24] 王丽华, 吕铮, 郝春博,等. 某石油污染场地地下水中降解菌群落结构研究[J]. 环境科学与技术, 2013,15(7):1-8.

    WANG L H, LV Z, HAO C B, et al. Degrading bacteria community structure in groundwater of a petroleum-contaminated site[J]. Environmental Science and Technology, 2013, 15(7):1-8(in Chinese).
