活性焦和活性炭负载纳米铁处理TNT红水中的二硝基甲苯磺酸钠

,  ,

downloadPDF

上一篇

下一篇

朱世妮, 徐颖, 叶正芳. 活性焦和活性炭负载纳米铁处理TNT红水中的二硝基甲苯磺酸钠[J]. 环境工程学报, 2012, 6(10): 3503-3508.
引用本文: 朱世妮, 徐颖, 叶正芳. 活性焦和活性炭负载纳米铁处理TNT红水中的二硝基甲苯磺酸钠[J]. 环境工程学报, 2012, 6(10): 3503-3508.
shu
Zhu Shini, Xu Ying, Ye Zhengfang. Treatment of dinitrotoluene sulfonates in TNT red water by active carbon supported and active coke supported NZVI[J]. Chinese Journal of Environmental Engineering, 2012, 6(10): 3503-3508.
Citation: Zhu Shini, Xu Ying, Ye Zhengfang. Treatment of dinitrotoluene sulfonates in TNT red water by active carbon supported and active coke supported NZVI[J]. Chinese Journal of Environmental Engineering, 2012, 6(10): 3503-3508.
shu

活性焦和活性炭负载纳米铁处理TNT红水中的二硝基甲苯磺酸钠

  • 1.

    辽宁工程技术大学资源与环境工程学院, 阜新 123000

  • 2.

    北京大学环境工程系, 水沙科学教育部重点实验室, 北京 100871

  • 基金项目:

    国防科工局基础产品创新计划

  • 中图分类号: X703

Treatment of dinitrotoluene sulfonates in TNT red water by active carbon supported and active coke supported NZVI

  • Fund Project:

  • 摘要: 以活性焦和活性炭为载体,采用液相还原法制备了负载纳米铁,比较了两种负载纳米铁对TNT红水中难降解物质二硝基甲苯磺酸钠(包括2,4-DNT-3-SO3Na和2,4-DNT-5-SO3Na)的去除能力。实验结果表明,作为负载材料活性焦的相对有效比表面积与孔体积要优于活性炭,而且有利于更好地发挥出负载纳米铁的优势。单位面积活性焦负载纳米铁去除2,4-DNT-5-SO3Na的能力明显高于活性炭负载纳米铁,单位面积活性焦负载纳米铁去除2,4-DNT-3-SO3Na的能力在较小投加量条件下高于活性炭负载纳米铁,但均随投加量的增加而下降;而对于活性炭负载纳米铁,其单位面积去除能力基本不受投加量的影响,而且对二硝基甲苯磺酸钠的去除率高于活性焦负载纳米铁。耦合混凝沉淀的总去除效果表明,单位面活性焦负载纳米铁对2,4-DNT-5-SO3Na的去除能力高于活性炭负载纳米铁,而对2,4-DNT-3-SO3Na的去除能力则低于活性炭负载纳米铁。
    Abstract: Activated carbon supported nanoscale zero-valent iron (NZVI/AC) and activated coke supported nanoscale zero-valent iron (NZVI/ACoke) were prepared using liquid phase reducing method.Their transformation capacities of 2,4-DNT-3-SO3Na and 2,4-DNT-5-SO3Na,a kind of degradation refractory nitro aromatic compounds,were compared.The experimental results revealed that activated coke was a better choose for supporting NZVI than activated carbon for the larger relative effective surface area and pore volume as well as enhancing the synergistic action between NZVI and carrier.NZVI/ACoke showed a higher transformation capacity of 2,4-dinitrotoluene sulfonates per unit area than NZVI/AC at first,but it decreased as the amount of NZVI/ACoke increased.However,the area-modified transformation capacities of NZVI/AC almost did not change with increasing amounts of NZVI/AC,and the removal efficiencies of 2,4-dinitrotoluene sulfonates were higher than those gained by NZVI/ACoke.When combined with coagulation-sedimentation,NZVI/ACoke showed a higher transformation capacity of 2,4-DNT-5-SO3Na per unit area than NZVI/AC,but a lower transformation capacity of 2,4-DNT-3-SO3Na than NZVI/AC.
  • 加载中
  • [1] Gilbert E.E.Recovery of organic values from TNT purification wastewater.Propellants and Explosives,1977,2(6):118-125
    [2] Jain M.R.,Zinjarde S.S.,Deobagkar D.D.,et al.2,4,6-ttrinitrotoluene transformation by a tropical marine yeast Yarrowia lipolytica NCIM 3589.Marine Pollutution Bulletin,2004,49(9):783-788
    [3] Zhang X.,Lin Y.M.,Chen Z.L.2,4,6-trinitrotoluene reduction kinetics in aqueous solution using nanoscale zerovalent iron.Journal of Hazardous Materials,2009,165(1-3):923-927
    [4] Zhang X.,Lin Y.M.,Shan X.Q.,et al.Degradation of 2,4,6-trinitrotoluene (TNT) from explosive wastewater using nanoscale zero-valent iron.Chemical Engineering Journal,2010,158(3):566-570
    [5] Naja G.,Halasz A.,Thiboutot S.,et al.Degradation of hexahydro-1,3,5-trinitro-1,3,5-triazine (RDX) using zerovalent iron nanoparticles.Environmental Science & Technology,2008,42(12):4364-4370
    [6] Hwang Y.H.,Kim D.G.,Shin H.S.Mechanism study of nitrate reduction by nano zero valent iron.Journal of Hazardous Materials,2011,185(2-3):1513-1521
    [7] Yang G.C.,Lee H.L.Chemical reduction of nitrate by nanosized iron:Kinetics and pathways.Water Research,2005,39(5):884-894
    [8] Agrawal A.,Tratnyek P.G.Reduction of nitro aromatic compounds by zero-valent iron metal.Environmental Science & Technology,1996,30(1):153-160
    [9] Liang F.,Fan J.,Guo Y.H.,et al.Reduction of nitrite by ultrasound-dispersed nanoscale zero-valent iron particles.Industrial & Engineering Chemistry Research,2008,47(22):8550-8554
    [10] Davel J.,Suidan M.T.,Adrian N.Biodegradation of the energetic compound TNT through a multiple-stage treatment approach.Water Science and Technology,2003,47(9):129-135
    [11] Choi H.,Al-Abed S.R.,Agarwal S.,et al.Synthesis of reactive nano-Fe/Pd bimetallic system-impregnated activated carbon for the simultaneous adsorption and dechlorination of PCBs.Chemistry of Materials,2008,20(11):3649-3655
    [12] 张环,金朝晖,韩璐,等.负载型纳米铁化学反硝化法去除硝酸盐氮的研究.中国给水排水,2006,22(15):83-87 Zhang H.,Jin Z.H.,Han L.,et al.Study on nitrate nitrogen removal in chemical denitrification by supported nano zero-valent iron.China Water & Wastewater,2006,22(15):83-87(in Chinese)
    [13] Wang Y.P.,Wang L.J.,Peng P.Y.Treatment of naphthalene derivatives with iron-carbon micro-electrolysis.Transactions of Nonferrous Metals Society of China,2009,16(6):1442-1447
    [14] Zhu H.J.,Jia Y.F.,Wu X.,et al.Removal of arsenic from water by supported nano zero-valent iron on activated carbon.Journal of Hazardous Materials,2009,172(2-3):1591-1596
    [15] Pereira M.C.,Coelho F.S.,Nascentes C.C.,et al.Use of activated carbon as a reactive support to produce highly active-regenerable Fe-based reduction system for environmental remediation.Chemosphere,2010,81(1):7-12
    [16] Finqueneisel G.,Zimny T.,Albiniak A.,et al.Cheap adsorbent.Part 1:Active cokes from lignites and improvement of their adsorptive properties by mild oxidation.Fuel,1998,77(6):549-556
    [17] Mitomo A.,Sato T.,Kobayashi N.,et al.Adsorption removal of hydrogen sulfide by activated coke produced from wood pellet in the recycle system of biomass.Journal of Chemical Engineering of Japan,2003,36(9):1050-1056
    [18] Kojima N.,Mitomo A.,Itaya Y.,et al.Adsorption removal of pollutants by active cokes produced from sludge in the energy recycle process of wastes.Waste Management,2002,22(4):339-404
    [19] Wiessner A.,Remmler M.,Kuschk P.,et al.The treatment of a deposited lignite pyrolysis wastewater by adsorption using activated carbon and activated coke.Colloids and Surfaces A—Physicochemical and Engineering Aspects,1998,139(1):91-97
    [20] Zhang M.H.,Zhao Q.L.,Bai X.,et al.Adsorption of organic pollutants from coking wastewater by activated coke.Colloids and Surfaces A—Physicochemical and Engineering Aspects,2010,362(1-3):140-146
    [21] Echeandiaa S.,Ariasa P.L.,Barrioa V.L.,et al.Synergy effect in the HDO of phenol over Ni-W catalysts supported on active carbon:Effect of tungsten precursors.Applied Catalysis B:Environmental,2010,101(1-2):1-12
    [22] Nurmi J.T.,Tratnyek P.G.,Sarathy V.,et al.Characterization and properties of metallic iron nanoparticles:spectroscopy,electrochemistry,and kinetics.Environmental Science & Technology,2005,39(5):1221-1230
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2120
  • HTML全文浏览数:  994
  • PDF下载数:  1285
  • 施引文献:  0
出版历程
  • 收稿日期:  2011-09-18
  • 刊出日期:  2012-10-16
朱世妮, 徐颖, 叶正芳. 活性焦和活性炭负载纳米铁处理TNT红水中的二硝基甲苯磺酸钠[J]. 环境工程学报, 2012, 6(10): 3503-3508.
引用本文: 朱世妮, 徐颖, 叶正芳. 活性焦和活性炭负载纳米铁处理TNT红水中的二硝基甲苯磺酸钠[J]. 环境工程学报, 2012, 6(10): 3503-3508.
shu
Zhu Shini, Xu Ying, Ye Zhengfang. Treatment of dinitrotoluene sulfonates in TNT red water by active carbon supported and active coke supported NZVI[J]. Chinese Journal of Environmental Engineering, 2012, 6(10): 3503-3508.
Citation: Zhu Shini, Xu Ying, Ye Zhengfang. Treatment of dinitrotoluene sulfonates in TNT red water by active carbon supported and active coke supported NZVI[J]. Chinese Journal of Environmental Engineering, 2012, 6(10): 3503-3508.
shu

活性焦和活性炭负载纳米铁处理TNT红水中的二硝基甲苯磺酸钠

  • 1. 辽宁工程技术大学资源与环境工程学院, 阜新 123000
  • 2. 北京大学环境工程系, 水沙科学教育部重点实验室, 北京 100871
  • 收稿日期:  2011-09-18
基金项目:

国防科工局基础产品创新计划

摘要: 以活性焦和活性炭为载体,采用液相还原法制备了负载纳米铁,比较了两种负载纳米铁对TNT红水中难降解物质二硝基甲苯磺酸钠(包括2,4-DNT-3-SO3Na和2,4-DNT-5-SO3Na)的去除能力。实验结果表明,作为负载材料活性焦的相对有效比表面积与孔体积要优于活性炭,而且有利于更好地发挥出负载纳米铁的优势。单位面积活性焦负载纳米铁去除2,4-DNT-5-SO3Na的能力明显高于活性炭负载纳米铁,单位面积活性焦负载纳米铁去除2,4-DNT-3-SO3Na的能力在较小投加量条件下高于活性炭负载纳米铁,但均随投加量的增加而下降;而对于活性炭负载纳米铁,其单位面积去除能力基本不受投加量的影响,而且对二硝基甲苯磺酸钠的去除率高于活性焦负载纳米铁。耦合混凝沉淀的总去除效果表明,单位面活性焦负载纳米铁对2,4-DNT-5-SO3Na的去除能力高于活性炭负载纳米铁,而对2,4-DNT-3-SO3Na的去除能力则低于活性炭负载纳米铁。
