活性炭对水中微量酰胺咪嗪吸附规律

,  ,

downloadPDF

上一篇

下一篇

吕婧, 张立秋, 封莉. 活性炭对水中微量酰胺咪嗪吸附规律[J]. 环境工程学报, 2012, 6(10): 3529-3536.
引用本文: 吕婧, 张立秋, 封莉. 活性炭对水中微量酰胺咪嗪吸附规律[J]. 环境工程学报, 2012, 6(10): 3529-3536.
shu
LV Jing, Zhang Liqiu, Feng Li. Adsorption rules of activated carbons for trace carbamazepine in water[J]. Chinese Journal of Environmental Engineering, 2012, 6(10): 3529-3536.
Citation: LV Jing, Zhang Liqiu, Feng Li. Adsorption rules of activated carbons for trace carbamazepine in water[J]. Chinese Journal of Environmental Engineering, 2012, 6(10): 3529-3536.
shu

活性炭对水中微量酰胺咪嗪吸附规律

  • 1.

    北京林业大学北京水体污染源控制技术重点实验室, 北京 100083

  • 基金项目:

    教育部博士点新教师基金(20090014120018)

    教育部新世纪优秀人才项目(NCEF-08-0732)

  • 中图分类号: TU991.25

Adsorption rules of activated carbons for trace carbamazepine in water

  • Fund Project:

  • 摘要: 选择3种商品活性炭(煤质炭MAC、杏壳炭XAC、椰壳炭YAC),从其对水中微量药物酰胺咪嗪(carbamazepine,CBZ)的吸附平衡、吸附等温式、吸附动力学和热力学等方面详细考察了不同种类活性炭对CBZ的吸附去除规律。实验结果表明,3种活性炭与CBZ接触反应10 h后均达到吸附平衡,对CBZ的平衡吸附量在8.3 mg/g左右;比较了Langmuir和Freundlich两种吸附等温式,发现Langmuir方程更适合描述3种活性炭对CBZ的吸附过程;计算表明3种活性炭的吸附过程均符合拟二级动力学方程,Weber-Morris方程的模拟结果则说明膜扩散和内扩散共同限制了3种活性炭对CBZ的吸附速率;3种活性炭的Ea值分别为29.87 kJ/mol(MAC)、36.02 kJ/mol(XAC)和38.86 kJ/mol(YAC),表明3种活性炭吸附CBZ时同时发生了物理吸附和化学吸附作用,且以化学吸附为主;20~40℃时3种活性炭的△G均为负值,说明3种活性炭对CBZ的吸附反应可以自发进行;MAC、XAC、YAC的△H值分别为-3.10、-3.05和-3.02 kJ/mol,负值表明吸附过程放热,上述△H值较小则说明温度对CBZ的吸附影响不大;3种活性炭吸附CBZ过程的△S值为0.94 J/(mol·K)(MAC)、2.24 J/(mol·K)(XAC)和2.97 J/(mol·K)(YAC),说明吸附过程熵值增加,在外界条件不改变的情况下该吸附过程不可逆,同时可以看出在3种活性炭中,CBZ分子更倾向于吸附在YAC上。
    Abstract: The removal of trace carbamazepine(CBZ) in water by absorption of three kinds of commercial activated carbon(coal carbon MAC、apricot carbon XAC and coconut carbon YAC) was studied using the adsorption equilibrium,adsorption isotherm,adsorption kinetics and thermodynamics.The results showed that the adsorption equilibrium of each ACs was obtained after about 10 hours.Similar adsorption quantities of CBZ were achieved about 8.3 mg/g.Langmuir adsorption isotherm equation was more suitable to describe the adsorption process compared with Freundlich equation.It was shown that the pseudo second-order kinetic equation could describe the adsorption kinetics for CBZ onto the three ACs,while the boundary layer diffusion and intra particle diffusion are rate limiting.The activation energy (Ea) values of three ACs were 29.87 kJ/mol (MAC),36.02 kJ/mol (XAC),38.86 kJ/mol (YAC),indicating the common effect of physical and chemical adsorption and do minance of the latter.Furthermore,the negative values of △G at 20~40℃ suggested that the adsorptions were spontaneous;the △H values of MAC,XAC and YAC were-3.10,-3.05,-3.02 kJ/mol,respectively,which indicated exothermic character of the adsorption processes and weak influence of temperature;the values of △S were 0.94 J/(mol·K)(MAC),2.24 J/(mol·K)(XAC),2.97 J/(mol·K)(YAC),meaning the process was irreversible under the given environmental conditions.
  • 加载中
  • [1] Sosiak A.,Hebben T.A preliminary survey of pharmaceuticals and endocrine disrupting compounds in treated municipal wastewaters and receiving rivers of Alberta.Edmonton:Alberta Environment,Environmental Monitoring and Evaluation Branch,2005
    [2] Ternes T.A.Occurrence of drugs in German sewage treatment plants and rivers.Water Research,1998,32(11):3245-3260
    [3] Drewes J.E.,Heberer T.,Reddersen K.Fate of pharmaceuticals during indirect potable reuse.Water Science and Technology,2002,46(3):73-80
    [4] Tauber R.Quantitative analysis of pharmaceuticals in drinking water from ten Canadian Cities.Enviro-Test Laboratories,Xenos Division,Ontario,Canada,2003
    [5] Stackelberg P.E.,Furlong E.T.,Meyer M.T.,et al.Persistence of pharmaceutical compounds and other organic wastewater conta minants in a conventional drinking-water-treatment plant.Science of the Total Environment,2004,329(1-3):99-113
    [6] Stackelberg P.E,Gibs J.,Furlong E.T.,et al.Efficiency of conventional drinking-water-treatment processes in removal of pharmaceuticals and other organic compounds.Science of the Total Environment,2007,377(2-3):255-272
    [7] Heberer T.,Mechlinski A.,Fanck B.,et al.Field studies on the fate and transport of pharmaceutical residues in bank filtration.Ground Water Monit Remediat,2004,24(2):70-77
    [8] Togola A.,Budzinski H.Multi-residue analysis of pharmaceutical compounds in aqueous samples.Journal of Chromatography A,2008,1177(1):150-158
    [9] Weigel S.,Bester K.,Hühnerfuss H.New method for rapid solid-phase extraction of large-volume water samples and its application to non-target screening of North Sea water for organic conta minants by gas chromatography-mass spectrometry.Journal of Chromatography A,2001,912(1):151-161
    [10] Eric Kristia Putra,Ramon Pranowo,Jaka Sunarso,et al.Performance of activated carbon and bentonite for adsorption of amoxicillin from wastewater:Mechanisms,isotherms and kinetics.Water Research,2009,43(9):2419-2430
    [11] Rivera-Utrilla J.,Prados-Joya G.,Sánchez-Polo M.,et al.Removal of nitroimidazole antibiotics from aqueous solution by adsorption/bioadsorption on activated carbon.Journal of Hazardous Materials,2009,170(1):298-305
    [12] Navarrete Casas R.,García Rodriguez A.,Rey Bueno F.,et al.Interaction of xanthenes with activated carbonⅠ.Kinetics of the adsorption process.Applied Surface Science,2006,252(17):6022-6025
    [13] Mestre A.S.,Pinto M.L.,Pires J.,et al.Effect of solution pH on the removal of clofibric acid by cork-based activated carbons.Carbon,2010,48(4):972-980
    [14] Óna Y.,Akmil-Basar C.,Sarlcl-özdemir C.Elucidation of the naproxen sodium adsorption onto activated carbon prepared from waste apricot:Kinetic,equilibrium and thermodynamic characterization.Journal of Hazardous Materials,2007,148(3):727-734
    [15] Paul Westerhoff,Yeo min Yoon,Shane Senyder,et al.Fate of endocrine-disruptor,pharmaceutical,and personal Care product chemicals during simulated drinking water treatment processes.Water Science and Technology,2005,39(17):6649-6663
    [16] Shane A.Snyder,Samer Adham,Adam M.Redding,et al.Role of membranes and activated carbon in the removal of endocrine disruptors and pharmaceuticals.Desalination,2006,202(1-3):156-181
    [17] Yu Zirui,Sigrid Peldszus,Peter M.Huck.Adsorption characteristics of selected pharmaceuticals and an endocrine disrupting compound—Naproxen,carbamazepine and nonylphenol—on activated carbon.Water Research,2008,42(12):2873-2882
    [18] Zhang Yongjun,GeiBn Sven-Uwe,Gal Carmen.Carbamazepine and diclofenac:Removal in wastewater treatment plants and occurrence in water bodies.Chemosphere,2008,73(8):1151-1161
    [19] Hamdaoui O.,Naffrechoux E.Modeling of adsorption isotherms of phenol and chlorophenols onto granular activated carbon.Part II.Models with more than two parameters.Journal of Hazardous Materials,2007,147(1-2):401-411
    [20] Mikhail Borisover,Maggie Sela,Benny Chefetz.Enhancement effect of water associated with natural organic matter (NOM) on organic compound—NOM interactions:A case study with carbamazepine.Chemosphere,2011,82(10):1454-1460
    [21] Patryk Oleszczuk,Pan Bo,Xing Baoshan.Adsorption and desorption of oxytetracycline and carbamazepine by multiwalled carbon nanotubes.Environment Science and Technology,2009,43(24):9167-9173
    [22] Ho Y.S.,McKay G.Pseudo-second order model for sorption processes.Process Biochem.,1999,34(5):451-465
    [23] Weber W.Jr,Morris J.C.Kinetics of adsorption on carbon from solution.Journal of Sanitary Engineering Division,Proceed American Society of Civil Engineers,1963,89(1):31-59
    [24] 刘大中,王锦.物理吸附与化学吸附.山东轻工业学院学报,1999,13(2):23-25 Liu Dazhong,Wang Jin.Physisorption and chemisorption.Journal of Shangdong Institute of Light Industry,1999,13(2):23-25(in Chinese)
    [25] Terzyk A.P.,Rychlicki G.,Wiertnia M.S.,et al.Effect of the carbon surface layer chemistry on benzene adsorption from the vapor phase and from dilute aqueous solutions.Langmuir,2005,21(26):12257-12267
    [26] Hulscher Th.E.M.,Cornelissen G.Effect of temperature on sorption equilibrium and sorption kinetics of organic micropollutants—A review.Chemosphere,1996,32(4):609-626
