水力停留时间变化对2种人工湿地净化效果的影响

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

吴建强, 周训华, 王敏, 唐浩, 吴健, 沙晨燕. 水力停留时间变化对2种人工湿地净化效果的影响[J]. 环境工程学报, 2012, 6(10): 3537-3542.
引用本文: 吴建强, 周训华, 王敏, 唐浩, 吴健, 沙晨燕. 水力停留时间变化对2种人工湿地净化效果的影响[J]. 环境工程学报, 2012, 6(10): 3537-3542.
shu
Wu Jianqiang, Zhou Xunhua, Wang Min, Tang Hao, Wu Jian, Sha Chenyan. Influence of hydraulic retention time variation on purification effects of two different constructed wetlands[J]. Chinese Journal of Environmental Engineering, 2012, 6(10): 3537-3542.
Citation: Wu Jianqiang, Zhou Xunhua, Wang Min, Tang Hao, Wu Jian, Sha Chenyan. Influence of hydraulic retention time variation on purification effects of two different constructed wetlands[J]. Chinese Journal of Environmental Engineering, 2012, 6(10): 3537-3542.
shu

水力停留时间变化对2种人工湿地净化效果的影响

  • 1.

    上海市环境科学研究院, 上海 200233

  • 2.

    珠江水资源保护科学研究所, 广州 510610

  • 基金项目:

    国家公益性行业(农业)科研专项(200903056)

  • 中图分类号: X173

Influence of hydraulic retention time variation on purification effects of two different constructed wetlands

  • Fund Project:

  • 摘要: 依托建立在新沂河河漫滩的人工湿地中试工程开展现场实验,研究分析水力停留时间变化对2种人工湿地污染物净化效果的影响。结果表明:水力停留时间的变化显著影响潜流和垂直流湿地污染物净化的效果,2种湿地高锰酸盐指数和氨氮(NH4+-N)去除效果随水力停留时间的变化均呈现先上升后下降的趋势。垂直流人工湿地显示出比潜流湿地更好、更稳定的污染物净化效果,其高锰酸盐指数和NH4+-N去除效果的最佳停留时间均出现在2 d左右,2种污染物的去除率分别达到93.1%和87.7%;而潜流湿地在水力停留时间为2 d左右时高锰酸盐指数去除率最高,达到92.3%,在2.5 d左右的时候NH4+-N去除率最高,达到81.5%。潜流和垂直流湿地都适合应用于新沂河污染河水的处理,在设计和实践应用中,两者的水力停留时间参数均可设定为2 d。
    Abstract: Based on the pilot-scale field experiment of constructed wetland on the riverside of Xinyi River,the relationship between hydraulic retention time variation and purification effect of two different constructed wetlands was studied.It is showed that hydraulic retention time variation significantly influenced purification effect of subsurface flow constructed wetland (SSFW) and vertical flow constructed wetland (VFW).With the variation of hydraulic retention time,potassium permanganate index (CODMn) and ammonia nitrogen (NH4+-N) removal effect increased,and then declined.The purification effect of VFW was better and more stable than SSFW.For both wetlands,the best retention time for CODMn and NH4+-N removal effect appeared about 2 d.The removal rates were 93.1% and 87.7%,respectively.However,for SSFW,the best hydraulic retention time of CODMn removal was about 2 d,and the removal rate was 92.3%.The best retention time for NH4+-N removal was about 2.5 d,the removal rate was 81.5% accordingly.SSFW and VFW are both suitable for Xinyi River pollution treatment;the best hydraulic retention time of both wetlands can be set as 2 d.
  • 加载中
  • [1] Greenway M.Suitability of macrophytes for nutrient removal from surface flow constructed wetlands receiving secondary treated sewage effluent in Queensland,Australia.Water Science and Technology,2003,48(2):121-128
    [2] Cheng S.,Grosse W.,Karrenbrock F.,et al.Efficiency of constructed wetlands in deconta mination of water polluted by heavy metals.Ecological Engineering,2001,18(3):317-325
    [3] 刘红,代明利,欧阳威,等.潜流人工湿地改善官厅水库水质试验研究.中国环境科学,2003,23(5):462-466 Liu Hong,Dai Mingli,Ouyang Wei,et al.Experimental studies on subsurface flow constructed wetland for water quality improvement in Guanting.China Environmental Science,2003,23(5):462-466(in Chinese)
    [4] 修春海,于水利,李玲.不同人工湿地对微污染原水处理效果的研究.中国给水排水,2008,24(23):64-71 Xiu Chunhai,Yu Shuili,Li Ling.Different constructed wetlands for treatment of micro-polluted raw water.China Water & Wastewater,2008,24(23):64-71(in Chinese)
    [5] 闻岳,周琪,蒋玲燕,等.水平潜流人工湿地对污水中有机物的降解特性.中国环境科学,2007,27(4):508-512 Wen Yue,Zhou Qi,Jiang Lingyan,et al.Degradation characteristics of organic substances in polluted surface waters treatment with horizontal subsurface flow constructed wetlands.China Environmental Science,2007,27(4):508-512(in Chinese)
    [6] 崔玉波,李相猛,赵可.潜流人工湿地废水处理技术的效能.吉林建筑工程学院学报,2002,19(2):7-10 Cui Yubo,Li Xiangmeng,Zhao Ke.The performance of constructed subsurface low wetland for wastewater treatment.Journal of Jilin Architectural and Civil Engineering Institute,2002,19(2):7-10(in Chinese)
    [7] Kivaisi A.K.The potential for constructed wetlands for wastewater treatment and reuse in developing countries:A review.Ecological Engineering,2001,16(5):545-560
    [8] Nhapi I.,Dalu J.,Siebel M.A.,et al.An evaluation of duckweed-based pond system as an alternative option for decentrlised treatment and reuse of wastewater in Zimbabwe.Water Science and Technology,2003,48(2):327-333
    [9] 司马卫平,何强,夏安林,等.人工湿地处理城市污水效能的影响因素分析.环境工程学报,2008,2(3):319-323 Sima Weiping,He Qiang,Xia Anlin,et al.Analysis on influencing factors of treatment efficiency of municipal wastewater with constructed wetlands.Chinese Journal of Environmental Engineering,2008,2(3):319-323(in Chinese)
    [10] 杨长明,顾国泉,李建华,等.潜流人工湿地系统停留时间分布与N、P浓度空间变化.环境科学,2008,29 (11):3043-3048 Yang Changming,Gu Guoquan,Li Jianhua,et al.Residence time distributions and spatial variation of N,P in the subsurface-flow constructed wetlands for purification of eutrophic aquaculture water.Environmental Science,2008,29(11):3043-3048(in Chinese)
    [11] 李现坡,杨勇,马院红,等.潜流式湿地系统停留时间分布实验结果分析.环境污染与防治,2008,30(2):64-67 Li Xianpo,Yang Yong,Ma Yuanhong,et al.Study of residence time distribution for subsurface flow constructed wetlands.Environmental Pollution & Control,2008,30(2):64-67(in Chinese)
    [12] 国家环境保护局.水与废水监测分析方法.北京:中国环境科学出版社,1998
    [13] 张甲耀,夏盛林,邱克明,等.潜流人工湿地污水处理系统氮去除及氮转化细菌的研究.环境科学学报,1999,19(3):323-327 Zhang Jiayao,Xia Shenglin,Qiu Keming,et al.Nitrogen removal by a subsurface flow constructed wetlands wastewatertreatment system and nitrogen-transformation bacteria.Acta Scientiae Circumstantiae,1999,19(3):323-327(in Chinese)
    [14] 卢学强,唐运平,李万庆,等.污水湿地处理工程水力停留时间的测定.干旱环境监测,1999,30(2):74-76 Lu Xueqiang,Tang Yunping,Li Wanqing,et al.HRT measurement of wetland project for wastewater treatment.Arid Environmental Monitoring,1999,30(2):74-76(in Chinese)
    [15] 郑艳侠,冯绍元,刘培斌,等.水温与水力停留时间对人工渗滤系统的影响.环境科学学报,2008,28(12):2509-2513 Zhen Yanxia,Fen Shaoyuan,Liu Peibing,et al.The effect of water temperature and HRT on constructed rapid infiltration treatment of slightly-polluted surface water.Acta Scientiae Circum Stantiae,2008,28(12):2509-2513(in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2793
  • HTML全文浏览数:  1796
  • PDF下载数:  1505
  • 施引文献:  0
出版历程
  • 收稿日期:  2011-08-10
  • 刊出日期:  2012-10-16
吴建强, 周训华, 王敏, 唐浩, 吴健, 沙晨燕. 水力停留时间变化对2种人工湿地净化效果的影响[J]. 环境工程学报, 2012, 6(10): 3537-3542.
引用本文: 吴建强, 周训华, 王敏, 唐浩, 吴健, 沙晨燕. 水力停留时间变化对2种人工湿地净化效果的影响[J]. 环境工程学报, 2012, 6(10): 3537-3542.
shu
Wu Jianqiang, Zhou Xunhua, Wang Min, Tang Hao, Wu Jian, Sha Chenyan. Influence of hydraulic retention time variation on purification effects of two different constructed wetlands[J]. Chinese Journal of Environmental Engineering, 2012, 6(10): 3537-3542.
Citation: Wu Jianqiang, Zhou Xunhua, Wang Min, Tang Hao, Wu Jian, Sha Chenyan. Influence of hydraulic retention time variation on purification effects of two different constructed wetlands[J]. Chinese Journal of Environmental Engineering, 2012, 6(10): 3537-3542.
shu

水力停留时间变化对2种人工湿地净化效果的影响

  • 1. 上海市环境科学研究院, 上海 200233
  • 2. 珠江水资源保护科学研究所, 广州 510610
  • 收稿日期:  2011-08-10
基金项目:

国家公益性行业(农业)科研专项(200903056)

摘要: 依托建立在新沂河河漫滩的人工湿地中试工程开展现场实验,研究分析水力停留时间变化对2种人工湿地污染物净化效果的影响。结果表明:水力停留时间的变化显著影响潜流和垂直流湿地污染物净化的效果,2种湿地高锰酸盐指数和氨氮(NH4+-N)去除效果随水力停留时间的变化均呈现先上升后下降的趋势。垂直流人工湿地显示出比潜流湿地更好、更稳定的污染物净化效果,其高锰酸盐指数和NH4+-N去除效果的最佳停留时间均出现在2 d左右,2种污染物的去除率分别达到93.1%和87.7%;而潜流湿地在水力停留时间为2 d左右时高锰酸盐指数去除率最高,达到92.3%,在2.5 d左右的时候NH4+-N去除率最高,达到81.5%。潜流和垂直流湿地都适合应用于新沂河污染河水的处理,在设计和实践应用中,两者的水力停留时间参数均可设定为2 d。
