木粉/壳聚糖接枝丙烯酸-丙烯酰胺吸附树脂对二元重金属离子溶液中Pb2+的吸附

,  ,  ,  ,

downloadPDF

上一篇

下一篇

谢建军, 姚庆鑫, 韩心强, 吴义强, 李新功. 木粉/壳聚糖接枝丙烯酸-丙烯酰胺吸附树脂对二元重金属离子溶液中Pb2+的吸附[J]. 环境工程学报, 2013, 7(8): 2947-2955.
引用本文: 谢建军, 姚庆鑫, 韩心强, 吴义强, 李新功. 木粉/壳聚糖接枝丙烯酸-丙烯酰胺吸附树脂对二元重金属离子溶液中Pb2+的吸附[J]. 环境工程学报, 2013, 7(8): 2947-2955.
shu
Xie Jianjun, Yao Qingxin, Han Xinqiang, Wu Yiqiang, Li Xingong. Selective adsorption of Pb2+ on wood flour/chitosan graft acrylic acid-acrylamide resins in two heavy metal ion solutions[J]. Chinese Journal of Environmental Engineering, 2013, 7(8): 2947-2955.
Citation: Xie Jianjun, Yao Qingxin, Han Xinqiang, Wu Yiqiang, Li Xingong. Selective adsorption of Pb2+ on wood flour/chitosan graft acrylic acid-acrylamide resins in two heavy metal ion solutions[J]. Chinese Journal of Environmental Engineering, 2013, 7(8): 2947-2955.
shu

木粉/壳聚糖接枝丙烯酸-丙烯酰胺吸附树脂对二元重金属离子溶液中Pb2+的吸附

  • 1.

    中南林业科技大学材料科学与工程学院, 长沙 410004

  • 基金项目:

    国家林业公益性行业科研专项(201104004)

    国家自然科学基金资助项目(31270603)

  • 中图分类号: TQ028.14;O647.314;TB34

Selective adsorption of Pb2+ on wood flour/chitosan graft acrylic acid-acrylamide resins in two heavy metal ion solutions

  • 1.

    School of Materials Science and Engineering, Central South University of Forestry and Technology, Changsha 410004, China

  • Fund Project:

  • 摘要: 采用自制木粉/壳聚糖接枝丙烯酸-丙烯酰胺吸附树脂R1、R2、R3对二元金属离子Cu2+/Pb2+和Zn2+/Pb2+溶液中的吸附性能进行了较系统考察。Pb2+离子溶液中存在竞争离子Cu2+、Zn2+时,随竞争离子浓度增加,3种吸附树脂R1、R2、R3对Pb2+的吸附量明显下降,而竞争离子吸附量显著增加。二元溶液中各金属离子浓度相同时,3种树脂对竞争离子Cu2+、Zn2+的吸附量大于对Pb2+的吸附量;各溶液中分别加入NaCl及NaNO3、尿素后,对Pb2+离子的吸附量下降迅速。随吸附树脂用量增加,竞争离子Cu2+、Zn2+的吸附量逐渐减小,Pb2+的吸附量在吸附树脂用量0.10g/L(Zn2+/Pb2+溶液)或0.15g/L(Cu2+/Pb2+溶液)时出现最大值。溶液pH值对树脂吸附性能有显著影响。3.02+的吸附量快速增大;52+的吸附量基本不变;92+的吸附量减小,而对竞争离子的吸附量或增大或减小。
    Abstract: The adsorption properties of three self-made wood flour/chitosan graft acrylic acid-acrylamide copolymerization resins (note as adsorbing resin R1, R2 and R3) were explored in detail for two metal ions, Cu2+/Pb2+ and Zn2+/Pb2+ mixing solutions. While there were the competitive ions Cu2+ and Zn2+ in Pb2+ solutions, the adsorption capacities of Pb2+ for three adsorption resins R1, R2 and R3 decreased obviously and those of the competitive ions Cu2+ and Zn2+ increased fastly with an increase of the concentrations of Cu2+ and Zn2+. The adsorption capacities of the competitive ions Cu2+ and Zn2+ were larger than those of Pb2+ when the concentration of each metal ions was equal in two metal ion solutions and those of Pb2+ decreased after NaCl, NaNO3 and urea were added into the metal ion Zn2+/Pb2+ or Cu2+/Pb2+ solution. When the masses(usage) of the adsorbing resins increased, the adsorption capacities of the competitive ions Cu2+ and Zn2+ decreased gradually while those of Pb2+ had a maximum at the mass concentration 0.10 g/L for Zn2+/Pb2+ solution or 0.15 g/L for Cu2+/Pb2+ solution with an increase of the usage of three types of the adsorption resins. The pH values of the Zn2+/Pb2+ or Cu2+/Pb2+ solution had an obvious effect on the adsorption properties of three resins R1, R2 and R3. The adsorption capacities of Cu2+, Zn2+ and Pb2+ for three resins R1, R2 and R3 increased quickly when the pH value was between 3 and 5, and these hardly changed when the pH value was between 5 and 9, while the adsorption capacities of Pb2+ for three resins R1, R2 and R3 decreased, and these of Cu2+ and Zn2+ for three resins R1, R2 and R3 either increased or decreased when the pH value was between 9 and 11.
  • 加载中
  • [1] 王爱勤.甲壳素化学.北京:科学出版社,2008.331-442
    [2] 曲荣君.金属离子吸附材料:制备·结构·性能.北京:化学工业出版社,2009.265-332
    [3] Zohuriaan-Mehr M. J. Advances in chtin and chitosan modification through graft copolymerization: A comprehensive review. Iran. Polym. J., 2005,14(3):235-265
    [4] Babel S., Kurniawan T. A. Low-cost adsorbents for heavy metals uptake from contaminated water: Review. J. Hazard. Mater., 2003,B97(3):219-243
    [5] 张荣,龙柱,阙晓明,等. 壳聚糖的接枝共聚反应技术进展及应用前景.造纸化学品,2006,18(S):20-26 Zhang R., Long Z., Que X. M., et al. Advances in graft copolymerization technique of chitosan and its potential application. Paper Chemicals, 2006,18(S):20-26(in Chinese)
    [6] 陈煜,陆铭,罗运军,等.甲壳素和壳聚糖的接枝共聚改性.高分子通报,2004,(2):54-62 Chen Y., Lu M., Luo Y. J., et al. Graft copolymerization of chitin and chitosan. Chinese Polym. Bullutin, 2004,(2):54-62(in Chinese)
    [7] 汪玉庭,刘玉红,张淑琴.甲壳素、壳聚糖的化学改性及其衍生物应用研究进展.功能高分子学报, 2002,15(1):107-114 Wang Y. T., Liu Y. H., Zhang S. Q. Progress in research and application of chemical modification of chitin and chitosan and their derivatives. J. Funct. Polym., 2002,15(1):107-114(in Chinese)
    [8] Wang X. H., Zheng Y. A., Wang A. Q. Fast removal of copper ions from aqueous solution by chitosan-g-poly(acrylic acis)/attapulgite composites. J. Hazard. Mater., 2009,168(4):970-977
    [9] Wan Ngah W. S., Endud C. S., Mayanar R. Removal of copper(II) ions from aqueous solution onto chitosan and cross-linked chitosan beads. React. Funct. Polym., 2002,50(2):181-190
    [10] Bao Y., Ma J. Z., Li N. Synthesis and swelling behaviors of sodium carboxymethyl cellulose-g-poly(AA-co-AM-co-AMPS)/MMT superabsorbent hydrogel. Carbohydr. Polym., 2011,84(1):76-82
    [11] 李晟.壳聚接枝丙烯酸-丙烯酰胺高吸水树脂的制备.长沙:中南林业科技大学硕士学位论文, 2010 Li S. Preparation of superabsorbent of chitosan graft acrylic acid and acrylamide. Changsha: Master's Degree Thesis of Central South University of Forestry and Technology, 2010(in Chinese)
    [12] 孙胜玲,王爱勤.铅模板交联壳聚糖对 Pb(Ⅱ)的吸附性能.中国环境科学,2005,25(2):192-195 Sun S. L., Wang A. Q. Adsorption properties of Pb(Ⅱ) template chitosan by cross-linked with glutaraldehyde. China Environ. Sci., 2005,25(2):192-195(in Chinese)
    [13] 韩心强.木粉/壳聚糖改性吸附树脂的制备及其应用.长沙:中南林业科技大学硕士学位论文,2011 Han X. Q. Preparation of graft modification resin of wood flour/chitosan and its adsorption propeties of lead ion. Changsha: Master's Degree Thesis of Central South University of Forestry and Technology, 2011(in Chinese)
    [14] 何新建,谢建军,张绘营,等.KLPAAM复合高吸水树脂吸附.化工学报,2011,62(2):1162-1169 He X. J., Xie J. J., Zhang H. Y., et al. Adsorption of KLPAAM superabsorbents composites. J. Chem. Ind. Eng. Soc. China(CIESC Journal), 2011,62(2):1162-1169(in Chinese)
    [15] 罗道成,刘俊峰.改性硅藻土对废水中Pb2+,Cu2+,Zn2+吸附量的研究.中国矿业,2005,114(17):63-67 Luo D. C., Liu J. F. Study on the adsorption of Pb2+, Cu2+ and Zn2+ in the wastewater for the modifying diatomite. Chinese Mining Ind., 2005,114(17):63-67(in Chinese)
    [16] 徐志固.现代配位化学.北京:化学工业出版社,1987
    [17] Kesenci K., Say R., Denizli A. Removal of heavy metal ions from water by using poly(ethylene glycol dimethacrylate-co-acrylamide) beads. Eur. Polym. J., 2002,38(7):1443-1448
    [18] Xie J. J., Liu X. R., Liang J. F. Absorbency and adsorption of poly(acrylic acid-coacrylamide) hydrogel. J. Appl. Polym. Sci., 2007,106(8):1606-1613
    [19] Garcia V. R., Hatton T. A. Metal ion complexation with lignin derivatives. Chem. Eng. J., 2003,94(1):99-105
    [20] Gupta K. C., Fawzi H. J. Effects of degree of deacetylation and cross-linking on physical characteristics, swelling and release behavior of chitosan microsphere. Carbonhydr. Polym., 2006,66(1):43-54
    [21] 马全红,邹宗柏,高永红.丙酮酸改性壳聚糖对金属离子的吸附量研究.现代化工,2000,20(10):44-46 Ma Q. H., Zou Z. B., Gao Y. H. Study on the adsorption of metal ion for acetylformic acid modifying chitosan. Modern Chem. Ind., 2000,20(10):44-46(in Chinese)
