高级搜索

气升回流一体化工艺处理生活污水

,  ,  ,

downloadPDF

上一篇

下一篇

张媛媛, 潘杨, 黄勇, 陈智杰. 气升回流一体化工艺处理生活污水[J]. 环境工程学报, 2014, 8(1): 121-125.
引用本文: 张媛媛, 潘杨, 黄勇, 陈智杰. 气升回流一体化工艺处理生活污水[J]. 环境工程学报, 2014, 8(1): 121-125.
shu
Zhang Yuanyuan, Pan Yang, Huang Yong, Chen Zhijie. Treatment of domestic sewage by airlift-reflux integrated reactor[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 121-125.
Citation: Zhang Yuanyuan, Pan Yang, Huang Yong, Chen Zhijie. Treatment of domestic sewage by airlift-reflux integrated reactor[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 121-125.
shu

气升回流一体化工艺处理生活污水

  • 1.

    苏州科技学院环境生物技术研究所, 苏州 215011

  • 2.

    苏州科技学院环境科学与工程学院, 苏州 215011

  • 基金项目:

    江苏省“333”“高层次人才培养”工程（2011Ⅲ-2179）

  • 中图分类号: X703

Treatment of domestic sewage by airlift-reflux integrated reactor

  • 1.

    Environment Biotechnology Research Institute, Suzhou University of Science and Technology, Suzhou 215011, China

  • 2.

    School of Environmental Science and Engineering, Suzhou University of Science and Technology, Suzhou 215011, China

  • Fund Project:

  • 摘要: 针对分散型生活污水处理开发了气升回流一体化工艺，以校园生活污水为对象，研究其对生活污水中污染物的去除效果。该系统由好氧区、厌氧区、沉淀区和气升室组成，以曝气的剩余气体的气升作用实现混合液的回流，节省动力消耗。结果表明，本工艺对COD、氨氮及悬浮物（SS）有较好的去除效果，去除率分别达到80%、90%和75%左右，出水COD、NH4+-N及SS平均浓度在40 mg/L、6.5 mg/L和10 mg/L左右。当进水COD在100~1 000 mg/L之间波动时，出水水质稳定。该工艺有较强的抗冲击负荷能力，且可实现剩余污泥的自消解。本工艺具有结构紧凑、占地少，运行费用低，维护简单的特点。
    Abstract: According to the characteristics of decentralization wastewater, a novel airlift-reflux integrated process was developed. The campus wastewater is used for this experiment, its capacity to treat pollutants was observed. The system consists of four zones with aerobic zone, anaerobic zone, settling zone and airlift zone. In order to save power, the rest of aeration gas was gathered to realize the intermixture reflux. The treatment efficiency of campus sewage's pollutants was observed. The research results show that better removal of COD,ammonia nitrogen and SS could be achieved. The removal rates of COD, NH4+-N and SS can reach 80%, 90% and 75%, respectively. Correspondingly, the effluent average concentrations were 40 mg/L, 6.5 mg/L and 10 mg/L. When the influent concentrations of COD ranged from 100 to 1 000 mg/L, the effluent quality was stable. The updated process has a strong ability to resist shock loading and self-digestion of excess sludge. In addition, the characteristics of compact structure, land saving, low cost and easily maintenance can be obtained in this process.
  • 加载中
  • [1] 王志强,李黎,罗海霞,等.农村生活污水处理技术研究.安徽农业科学,2012,40(5):2957-2959 Wang Zhiqiang, Li Li, Luo Haixia, et al. Research on rural domestic sewage processing technology. Journal of Anhui Agricultural Sciences, 2012,40(5) : 2957-2959(in Chinese)
    [2] 李海明.农村生活污水分散式处理系统与实用技术研究.环境科学与技术,2009,32(9):177-181 Li Haiming. Distributed rural sewage treatment system and practical technology. Environmental Science & Technology, 2009,32(9):177-181 (in Chinese)
    [3] 齐瑶,常杪.小城镇和农村生活污水分散处理的适用技术.中国给水排水,2008,24(18):24-27 Qi Yao, Chang Miao. Technical applicability for decentralized sewage treatment in small towns and rural areas. China Water & Wastewater, 2008,24(18):24-27 (in Chinese)
    [4] 张荣,杨永强,刘劲松,等.分散式高负荷地下渗滤污水处理系统的设计和运行.环境工程学报,2011,5(8):1755-1760 Zhang Rong, Yang Yongqiang, Liu Jinsong, et al. Design and operation of decentralized high hydraulic loading subsurface infiltration wastewater treatment system. Chinese Journal of Environmental Engineering, 2011,5(8):1755-1760 (in Chinese)
    [5] 左金龙,李俊生,黄丽坤,等.低DO浓度下A/O型SBR工艺除污性能研究.中国给水排水,2011,27 (15):99-102 Zuo Jinlong, Li Junsheng, Huang Likun, et al. Pollutant removal performance of A/O-type SBR process under low DO. China Water & Wastewater, 2011,27(15):99-102(in Chinese)
    [6] Hanaki K., Wantawin C., Ohgaki S. Nitrification at low levels of dissolved oxygen without organic loading in a suspend-growth reactor. Water Research, 1990,24(3) :297-302
    [7] 胡友彪,张文涛,黄周满. 温度对MBBR和A/O工艺中污染物去除效果比较.环境科学与技术,2012,35(2) : 178-181 Hu Youbiao,Zhang Wentao,Huang Zhouman,et al. Comparison of effect of temperature on MBBR and A/O process for sewage treatment. Environmental Science & Technology,2012,35(2) : 178-181(in Chinese)
    [8] 王社平,黄宁俊,邵军峰,等. 倒置A2/O工艺对城市污水的处理效果分析. 中国给水排水,2011,27 (21):59-62 Wang Sheping, Huang Ningjun, Shao Junfeng, et al. Effect analysis of inverted A2/O process for treating municipal sewage. China Water & Wastewater, 2011,27(21):59-62(in Chinese)
    [9] 仇艺,冯宝荣.浅析高污泥浓度与生物脱氮除磷的关系.江苏环境科技,2007,20(2) : 108-120 Chou Yi, Feng Baorong.Analysis of the relationship between high sludge density and biological removal of nitrogen and phosphorus. Jiangsu Environmental Science and Technology, 2007,20(2) : 108-120(in Chinese)
    [10] 徐晓毅,刘慧君,朱跃敏,等.A/O-MBR中MLSS浓度对污泥性能及膜通量的影响.环境工程学报,2012,6(3) : 949-953 Xu Xiaoyi, Liu Huijun, Zhu Yuemin, et al. Effect of MLSS on sludge characteristics and membrane flux in A/O-MBR. Chinese Journal of Environmental Engineering, 2012,6(3) : 949-953 (in Chinese)
    [11] Neyens E., Baeyens J., Dewil R., et al. Advanced sludge treatment affects extracellular polymeric substances to improve activated sludge dewatering. Journal of Hazardous Materials,2004,106(2):83-92
    [12] 张海丰,孙宝盛,齐耿申.传统活性污泥法与膜生物反应器污泥沉降性能的比较.四川环境,2005,24(3):1-3 Zhang Haifeng, Sun Baosheng, Qi Gengshen. A comparison of sludge settleability between a conventional activated sludge process and a membrane bioreactor. Sichuan Environment, 2005,24(3):1-3 (in Chinese)
    [13] Simos Malamis, Andreas Andreadakis. Fractionation of proteins and carbohydrates of extracellular polymeric substances in a membrane bioreactor system. Bioresource Technology, 2009,100(13):3350-3357
    [14] Adrienne Menniti, Eberhard Morgenroth. Mechanisms of SMP production in membrane bioreactors: Choosing an appropriate mathematical model structure.Water Research,2010, 44(18):5240-5251
    [15] Ni Bingjie, Fang Fang, Xie Wenming, et al. Growth, maintenance and product formation of autotrophs in activated sludge: Taking the nitrite-oxidizing bacteria as an example. Water Research,2008, 42(16):4261-4270
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1784
  • HTML全文浏览数:  948
  • PDF下载数:  880
  • 施引文献:  0
出版历程
  • 收稿日期:  2012-07-03
  • 刊出日期:  2014-01-03
张媛媛, 潘杨, 黄勇, 陈智杰. 气升回流一体化工艺处理生活污水[J]. 环境工程学报, 2014, 8(1): 121-125.
引用本文: 张媛媛, 潘杨, 黄勇, 陈智杰. 气升回流一体化工艺处理生活污水[J]. 环境工程学报, 2014, 8(1): 121-125.
shu
Zhang Yuanyuan, Pan Yang, Huang Yong, Chen Zhijie. Treatment of domestic sewage by airlift-reflux integrated reactor[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 121-125.
Citation: Zhang Yuanyuan, Pan Yang, Huang Yong, Chen Zhijie. Treatment of domestic sewage by airlift-reflux integrated reactor[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 121-125.
shu

气升回流一体化工艺处理生活污水

  • 1.  苏州科技学院环境生物技术研究所, 苏州 215011
  • 2.  苏州科技学院环境科学与工程学院, 苏州 215011
  • 收稿日期:  2012-07-03
基金项目:

江苏省“333”“高层次人才培养”工程（2011Ⅲ-2179）

摘要: 针对分散型生活污水处理开发了气升回流一体化工艺，以校园生活污水为对象，研究其对生活污水中污染物的去除效果。该系统由好氧区、厌氧区、沉淀区和气升室组成，以曝气的剩余气体的气升作用实现混合液的回流，节省动力消耗。结果表明，本工艺对COD、氨氮及悬浮物（SS）有较好的去除效果，去除率分别达到80%、90%和75%左右，出水COD、NH4+-N及SS平均浓度在40 mg/L、6.5 mg/L和10 mg/L左右。当进水COD在100~1 000 mg/L之间波动时，出水水质稳定。该工艺有较强的抗冲击负荷能力，且可实现剩余污泥的自消解。本工艺具有结构紧凑、占地少，运行费用低，维护简单的特点。

English Abstract

    全文HTML

参考文献 (15)
