2种不同性能炭纤维载体的固定床厌氧反应器运行效果比较

,  ,  ,  ,

downloadPDF

上一篇

下一篇

林长松, 袁旭峰, 崔宗均, 程序, 朱万斌. 2种不同性能炭纤维载体的固定床厌氧反应器运行效果比较[J]. 环境工程学报, 2014, 8(1): 203-209.
引用本文: 林长松, 袁旭峰, 崔宗均, 程序, 朱万斌. 2种不同性能炭纤维载体的固定床厌氧反应器运行效果比较[J]. 环境工程学报, 2014, 8(1): 203-209.
shu
Lin Changsong, Yuan Xufeng, Cui Zongjun, Zhu Wanbin, . Comparative study on operational effect of two kinds of fixed-bed anaerobic reactor packed with different properties of carbon fiber as carrier[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 203-209.
Citation: Lin Changsong, Yuan Xufeng, Cui Zongjun, Zhu Wanbin, . Comparative study on operational effect of two kinds of fixed-bed anaerobic reactor packed with different properties of carbon fiber as carrier[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 203-209.
shu

2种不同性能炭纤维载体的固定床厌氧反应器运行效果比较

  • 1.

    六盘水师范学院生命科学系, 六盘水 553004

  • 2.

    中国农业大学生物质工程中心/中国农业大学农学与生物技术学院, 北京 100193

  • 基金项目:

    贵州省教育厅自然科学研究项目（黔教科2008094）

    贵州省高层次人才科研条件特助经费项目（TZJF-2010年-017号）

    六盘水市科技创新人才团队建设项目（52020-2012-04-01-01）

  • 中图分类号: 703.1

Comparative study on operational effect of two kinds of fixed-bed anaerobic reactor packed with different properties of carbon fiber as carrier

  • 1.

    Department of Life Science, Liupanshui Normal University, Liupanshui 553004, China

  • 2.

    Center of Biomass Engineering, College of Agronomy and Biotechnology, China Agricultural University, Beijing 100193, China

  • Fund Project:

  • 摘要: 分别采用炭纤维（CF）和活性炭纤维（ACF）作为固定床厌氧反应器的生物膜载体，以不加任何载体的相同规格的反应器为对照，在中温（35±1）℃、连续进料条件下处理高浓度糖蜜废水，实验历时 165 d ，比较评价了2种不同性能的炭纤维作为载体的固定床厌氧反应器的运行性能。结果表明，CF 和 ACF 均是较好的微生物附着的载体材料，具有较强的处理高负荷有机废水和抵抗pH冲击的能力，能显著地提高反应器运行系统的稳定性。具有高比表面积的 ACF 较之 CF 更易于微生物固着并挂膜。对照在进水 COD超过 20 000 mg/L，相应 OLR为 8.35 kg COD/（m3·d）时，系统开始酸化。而以 CF 和 ACF 为载体的反应器能在进水 COD 高达 70 000 mg/L ，相应的 OLR 分别为 36.85 和 39.06 kg COD/（m3·d） 的高有机负荷下运行，且系统的pH更稳定。对照及以 CF 和 ACF 为载体的反应器的最高容积产气率分别为4.33、17.12和16.12 m3/（m3·d）；165 d 的累积产气量分别为5 665.4、22 675.8和26 112.8 L，后2者的产气量分别是对照产气量的 4.0 和 4.6 倍。
    Abstract: With two fixed-bed anaerobic reactor(FBAR) packed with carbon fiber(CF) and activated carbon fiber(ACF)as carrier respectively, and took the same specifications reactor without adding any carrier as contrast, the operation performances of the two reactors were compared and evaluated. The experimental conditions of mesophilic anaerobic fermentation(35±1)℃and continuous feeding were used to process the wastewater of high concentration molasses. The experiment proceeded 165 days and the results indicated that the CF and ACF are both good carrier materials for microbial attached. The stability of the operation showed their good ability against the load and resist pH impact, obviously improved the stability of the reactor running system. Nevertheless, larger specific surface area possessed by ACF was easier than CF for microbe fixation and biofilm colonization. In the control one, the system gradually acidified when the COD was only 20 000 mg/L, which relevant OLR was 8.35 kg COD/(m3·d), while the FBAR packed with CF or ACF could be stable operation even treating high concentration of organic wastewater which COD was as high as 70 000 mg/L,and the relative OLRs were 31.61,35.13 and 8.35 kg COD/(m3·d), respectively, and pH of the system was more stable than that of the control one. The highest level of the biogas production rate of control reactor, AFBRs packed with CF and ACF were 4.33, 17.12 and 16.12 m3/(m3·d), respectively, and the cumulative gas production were 5 665.4,22 675.8 and 26 112.8 L,respectively. Obviously, the biogas production rate of the latter two was far more above that of the control reactor, the cumulative biogas production of the latter two were 4.0 times and 4.6 times of control one's, respectively.
  • 加载中
  • [1] 张菊萍, 孙华, 周增炎. 一种新型悬浮填料的性能实验研究. 安全与环境学报, 2002,2(5):42-44 Zhang Juping, Sun Hua, Zhou Zengyan. A research on the features of new suspending moving bed biofilm process. Journal of Safety and Environment, 2002, 2(5):42-44 (in Chinese)
    [2] 张凡,程江, 杨卓如, 等. 废水处理用生物填料的研究进展. 环境污染治理技术与设备, 2004, 5(4):8-12 Zhang Fan, Cheng Jiang, Yang Zhuo Ru, et al. Research progress in biofilm carrier for wastewater treatment. Techniques and Equipment for Environmental Pollution Control, 2004, 5(4):8-12 (in Chinese)
    [3] Morper M. R.Up grading of factivated sludege systems for nitrogen removal by application of the LINPORCN process.Wat.Sci.Tech.,1994,29(12):167
    [4] Reimann H. The LINPOR process for nitrification and denitrification.Wat.Sci.Tech.,1990,22(7):297-298
    [5] 沈耀良, 黄勇, 赵丹. 固定化微生物污水处理技术(第1版).北京:化学工业出版社,2002
    [6] 魏永前, 刘德启. 碳纤维膜生物反应器在处理城市生活污水中的应用研究. 苏州大学学报(自然科学版), 2005,21(3):67-69,77 Wei Yongqian, Liu Deqi. Application of carbon fiber membrane bioreactor for urban domestic sewage. Journal of Suzhou University (Natural Science), 2005, 21(3):67-69,77 (in Chinese)
    [7] 陈贤清,唐永艳. 炭纤维载体表面快速固着机理研究.重庆科技学院学报(自然科学版),2010,12(10):81-83,113 Chen Xianqing,Tang Yongyan. Rapid immobilization mechanism of carbon fiber carrier surface. Journal of Chongqing University of Science and Technology(Natural Science Edition), 2010,12(10):81-83,113 (in Chinese)
    [8] 刘存平,曾莉,岑真章. 炭纤维在环境技术中的应用. 重庆科技学院学报(自然科学版),2008,10(3):41-42,53 Liu Cunping, Zeng Li, Qin Zhenzhang. The applied research of carbon fibers in the environment. Journal of Chongqing University of Science and Technology(Natural Science Edition), 2008,10(3):41-42,53(in Chinese)
    [9] 林长松,袁旭峰,王小芬,等. 炭纤维载体固定床厌氧发酵启动运行效果实验. 环境工程学报,2009, 3(9): 1557-1562 Lin Changsong, Yuan Xufeng, WangXiaofen,et al.Treatment of high strength molasses wastewater with an aerobic fixed-bed reactor, Chinese Journal of Environmental Engineering, 2009, 3(9): 1557-1562(in Chinese)
    [10] 林长松,袁旭峰,王小芬,等. 固定床厌氧反应器处理高浓度糖蜜废水. 农业工程学报,2009, 25(7):195-200 Lin Changsong, Yuan Xufeng, WangXiaofen,et al.Treat ment of high strength molasses wastewater with an aerobic fixed-bed reactor. Transactions of the CSAE, 2009, 25(7):195-200 (in Chinese)
    [11] 马兆昆, 刘杰. 炭纤维生物膜载体在反硝化脱氮中的应用.中国环境科学,2003,23(3):247-250 Ma Zhaokun, Liu Jie. Application of carbon fiber as biofilm carriers in denitrification. China Environmental Science, 2003,23(3):247-250 (in Chinese)
    [12] 马兆昆, 刘杰. 碳纤维表面特性对兼性及厌氧微生物固着的影响.材料研究学报,2004,1(1):60-64 Ma Zhaokun, Liu Jie. Effect of surface characteristics of carbon fiber on immobilization of facultative and anaerobic aerobes. Chinese Journal of Materials Research, 2004,1(1):60-64 (in Chinese)
    [13] Majumder P. S., Gupta S. K. Effect of influentpHand alkalinity on the removal of chlorophenols in sequential anaerobic-aerobic reactors. Bioresource Technology, 2009,100 (5) :1881-1883
    [14] Ramakrishna C., Desai J.D. High rate anaerobic digestion of a petrochemical wastewater using biomass support particles. World Journal of Microbiology and Biotechnology, 1997, 13(3): 329-334
    [15] 白玉华, 张代钧, 祖波, 等. 低COD废水启动EGSB反应器.环境工程学报,2007, 1(4):29-33 Bai Yuhua, Zhang Daijun, Zu Bo, et al. The start-up of expanded granular sludge bed reactor with low strength COD. Chinese Journal of Environmental Engineering, 2007, 1(4):29-33 (in Chinese)
    [16] 何品晶, 潘修疆, 吕凡, 等.pH对有机垃圾厌氧水解和酸化速率的影响. 中国环境科学, 2006, 26 (1):57-61 He Pinjing, Pan Xiujiang, Lv Fan, et al. The influence of pH value on anaerobic hydrolysis and acidogenesis rates of biodegradable organic waste. China Environmental Science, 2006, 26 (1):57-61 (in Chinese)
    [17] Bras R., Gomes A., Ferra M. I. A., et al. Monoazo and diazo dye decolourisation studies in a methanogenic UASB reactor. Biotechnology, 2005,115 (1):57-66
    [18] Jain S. R., Mattiasson B. Acclimatization of methanogenic consortia for low pH biomethanation. Biotechnology Letters, 1998, 20(8):771-775
    [19] 刘杰, 马兆昆. 碳纤维表面特性对反硝化菌固着化的影响. 北京化工大学学报, 2003, 30(2): 40-44 Liu Jie, Ma Zhaokun. Effect of surface characteristics of carbon fiber on immobilization of denitrifying bacterium. Journal of Beijing University of Chemical Technology, 2003, 30(2): 40-44 (in Chinese)
    [20] 刘杰, 何振坤, 王绍堂. 炭纤维生物膜的形成机制:Ⅰ.炭纤维表面特性对微生物固着化的影响.新型炭材料, 2002,17(3):20-24 Liu Jie, He Zhenkun,Wang Shaotang. Formation mechanism of careon of carbon fiber biofilms Ⅰ: Effects of carbon fiber surface charactristics on the immobilization of microorganisms. New Carbon Materials, 2002,17(3):20-24 (in Chinese)
    [21] Michaud S., Bernet N., Buffiere P., et al. Methane yield as a monitoring parameter for the start-up of anaerobic fixed film reactors. Water Research, 2002, 36 (5):1385-1391
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1681
  • HTML全文浏览数:  1017
  • PDF下载数:  997
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-03-05
  • 刊出日期:  2014-01-03
林长松, 袁旭峰, 崔宗均, 程序, 朱万斌. 2种不同性能炭纤维载体的固定床厌氧反应器运行效果比较[J]. 环境工程学报, 2014, 8(1): 203-209.
引用本文: 林长松, 袁旭峰, 崔宗均, 程序, 朱万斌. 2种不同性能炭纤维载体的固定床厌氧反应器运行效果比较[J]. 环境工程学报, 2014, 8(1): 203-209.
shu
Lin Changsong, Yuan Xufeng, Cui Zongjun, Zhu Wanbin, . Comparative study on operational effect of two kinds of fixed-bed anaerobic reactor packed with different properties of carbon fiber as carrier[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 203-209.
Citation: Lin Changsong, Yuan Xufeng, Cui Zongjun, Zhu Wanbin, . Comparative study on operational effect of two kinds of fixed-bed anaerobic reactor packed with different properties of carbon fiber as carrier[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 203-209.
shu

2种不同性能炭纤维载体的固定床厌氧反应器运行效果比较

  • 1. 六盘水师范学院生命科学系, 六盘水 553004
  • 2. 中国农业大学生物质工程中心/中国农业大学农学与生物技术学院, 北京 100193
  • 收稿日期:  2013-03-05
基金项目:

贵州省教育厅自然科学研究项目（黔教科2008094）

贵州省高层次人才科研条件特助经费项目（TZJF-2010年-017号）

六盘水市科技创新人才团队建设项目（52020-2012-04-01-01）

摘要: 分别采用炭纤维（CF）和活性炭纤维（ACF）作为固定床厌氧反应器的生物膜载体，以不加任何载体的相同规格的反应器为对照，在中温（35±1）℃、连续进料条件下处理高浓度糖蜜废水，实验历时 165 d ，比较评价了2种不同性能的炭纤维作为载体的固定床厌氧反应器的运行性能。结果表明，CF 和 ACF 均是较好的微生物附着的载体材料，具有较强的处理高负荷有机废水和抵抗pH冲击的能力，能显著地提高反应器运行系统的稳定性。具有高比表面积的 ACF 较之 CF 更易于微生物固着并挂膜。对照在进水 COD超过 20 000 mg/L，相应 OLR为 8.35 kg COD/（m3·d）时，系统开始酸化。而以 CF 和 ACF 为载体的反应器能在进水 COD 高达 70 000 mg/L ，相应的 OLR 分别为 36.85 和 39.06 kg COD/（m3·d） 的高有机负荷下运行，且系统的pH更稳定。对照及以 CF 和 ACF 为载体的反应器的最高容积产气率分别为4.33、17.12和16.12 m3/（m3·d）；165 d 的累积产气量分别为5 665.4、22 675.8和26 112.8 L，后2者的产气量分别是对照产气量的 4.0 和 4.6 倍。
