混凝-超滤短流程工艺处理北方水库原水

,  ,  ,  ,

downloadPDF

上一篇

下一篇

曲明, 滕李军, 傅金祥, 杨勇, 卢善文. 混凝-超滤短流程工艺处理北方水库原水[J]. 环境工程学报, 2014, 8(1): 210-214.
引用本文: 曲明, 滕李军, 傅金祥, 杨勇, 卢善文. 混凝-超滤短流程工艺处理北方水库原水[J]. 环境工程学报, 2014, 8(1): 210-214.
shu
Qu Ming, Teng Lijun, Fu Jinxiang, Yang Yong, Lu Shanwen. Treatment of raw water of northern reservoir by coagulation/ultrafiltration membrane short technological process[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 210-214.
Citation: Qu Ming, Teng Lijun, Fu Jinxiang, Yang Yong, Lu Shanwen. Treatment of raw water of northern reservoir by coagulation/ultrafiltration membrane short technological process[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 210-214.
shu

混凝-超滤短流程工艺处理北方水库原水

  • 1.

    抚顺市自来水公司, 抚顺 113000

  • 2.

    沈阳建筑大学市政与环境工程学院, 沈阳 110168

  • 基金项目:

    辽宁省教育厅科学技术研究项目（L2011088）

  • 中图分类号: TU991.24

Treatment of raw water of northern reservoir by coagulation/ultrafiltration membrane short technological process

  • 1.

    Fushun Waterworks Company, Fushun 113000, China

  • 2.

    School of Municipal and Environmental Engineering, Shenyang Jianzhu University, Shenyang 110168, China

  • Fund Project:

  • 摘要: 采用混凝-超滤膜短流程工艺对大伙房水库原水进行处理，考察其除污染性能和膜污染情况，并对该短流程工艺参数进行优化。结果表明，当利用超滤膜直接过滤原水时，膜污染较重，并且对污染物质的去除率较低；而采用混凝-超滤短流程工艺时，膜污染得到一定程度上的缓解；当絮凝剂投加量为7 mg/L、膜清洗周期为30 min时，对浊度、CODMn和UV254的去除率分别为95.61%、40.42%和37.12%，出水水质能够满足生活饮用水卫生标准。
    Abstract: We adopted the coagulation/ultrafiltration membrane short technological process to treat the raw water of Dahuofang Reservoir and investigated the pollution removal performance and the membrane pollution of this process. In addition, we optimized the parameters of this short technological process. The experiment indicates that serious membrane fouling is produced if the raw water is directly filtered by ultrafiltration membrane and the removal rate of pollutants remains at a low level; when the coagulation/ultrafiltration membrane short technological process is applied, membrane fouling could be relieved to some extent. When flocculent is added by 7 mg/L and the cleaning period of the membrane is 30 minutes, the removal rates of turbidity, CODMn and UV254 are 95.61%, 40.42% and 37.12%, respectively, and the quality of yielding water could meet the hygienic standard for drinking water.
  • 加载中
  • [1] 王海燕,陶金成,仲志,等.采用浸没式超滤膜处理水厂沉淀池出水的研究.给水排水,2010,36(11):136-140
    [2] 李圭白,杨艳玲.超滤——第三代城市饮用水净化工艺的核心技术.供水技术,2007,1(1):1-3 Li G.B., Yang Y.L. Ultrafiltration—the 3rd generation key water purification technology for city. Water Technology, 2007, 1(1):1-3(in Chinese)
    [3] 王捷,张宏伟,贾辉,等.预处理技术在膜饮用水处理中的研究进展.天津工业大学学报,2005,24(5):98-104 Wang J., Zhang H.W., Jia H., et al. Developments of pretreatment of membrane progress for potable water treatment.Journal of Tianjin Polytechnic University,2005, 24(5):98-104(in Chinese)
    [4] 顾宇人,曹林春,陈春圣,等.超滤膜法短流程工艺在南通市芦泾水厂提标改造工程中的应用.给水排水,2010,31(11):9-15 Gu Y.R., Cao L.C., Chen C.S., et al. Application of the shortened ultra-filtration membrane process in Lujing Water Treatment Plant upgrading reconstruction project in Nantong City. Water & Wastewater Engineering, 2010, 31(11):9-15(in Chinese)
    [5] 何文杰,胡建坤,卜建伟.超滤膜技术在市政供水行业的工程应用.给水排水,2010,36(6):9-13 He W.J., Hu J.K., Bu J.W. Project application of ultrafiltration technologies in the municipal supply industry. Water & Wastewater Engineering, 2010, 36(6):9-13(in Chinese)
    [6] 常海庆,梁恒,高伟,等.东营南郊净水厂超滤膜示范工程的设计和运行经验简介.给水排水,2012,38(6):9-13
    [7] 贺斌,金永民,褚龙.辽宁大伙房水库水质评价.北方环境,2010,22(2):38-40 He B., Jin Y.M., Zhu L. Water quality assessment of Liaoning Da Huo Fang reservoir in Liaoning Province. Northern Environment, 2010, 22(2): 38-40(in Chinese)
    [8] 张艳,李圭白.混凝沉淀-浸没式超滤膜处理东江水的中试研究.中国给水排水,2009,25(11):37-39 Zhang Y., Li G.B. Coagulation-sedimentation and submerged ultrafiltration membrane for treatment of Dong River water.China Water & Wastewater, 2009, 25(11):37-39(in Chinese)
    [9] 龚海宁,曹达文,董秉直,等.接触砂滤与超滤组合工艺处理淮河水研究.城市公用事业,2002,16(4):18-20
    [10] Arrojo B., Mosquera-Corra A., Garrido J.M., et al. A membrane coupled to a sequencing batch reactor for water reuse and removal of coliform bacteria. Desalination, 2005,179(1-3):109-116
    [11] Madaeni S.S. The application of membrane technology for water disinfection. Water Research, 1999, 33(2): 301-308
    [12] 蒋绍阶,刘宗源.UV254作为水处理中有机物控制指标的意义.重庆建筑大学学报,2002,24(2):61-65 Jiang S.J., Liu Z.Y. The Meaning of UV254 as an organic matter monitoring parameter in water supply & wastewater treatment. Journal of Chongqing Jianzhu University, 2002,24(2):61-65(in Chinese)
    [13] 董秉直,陈艳,高乃云,等.混凝对膜污染的防止作用.环境科学,2005,26(1):90-93 Dong B.Z., Chen Y., Gao N.Y., et al. Effect of coagulation on preventing membrane from fouling. Environmental Science,2005,26(1):90-93(in Chinese)
    [14] 黄国鑫,陈鸿汉,黄继国,等. 中空纤维超滤膜处理油田清水注水中试. 环境工程, 2009, 27(3): 52-56 Huang G.X., Chen H.H., Huang J.G., et al. Pilot study on oil field rinsing water-injection by hollow fiber up membrane. Environmental Engineering, 2009, 27(3): 52-56(in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1716
  • HTML全文浏览数:  860
  • PDF下载数:  672
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-03-15
  • 刊出日期:  2014-01-03
曲明, 滕李军, 傅金祥, 杨勇, 卢善文. 混凝-超滤短流程工艺处理北方水库原水[J]. 环境工程学报, 2014, 8(1): 210-214.
引用本文: 曲明, 滕李军, 傅金祥, 杨勇, 卢善文. 混凝-超滤短流程工艺处理北方水库原水[J]. 环境工程学报, 2014, 8(1): 210-214.
shu
Qu Ming, Teng Lijun, Fu Jinxiang, Yang Yong, Lu Shanwen. Treatment of raw water of northern reservoir by coagulation/ultrafiltration membrane short technological process[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 210-214.
Citation: Qu Ming, Teng Lijun, Fu Jinxiang, Yang Yong, Lu Shanwen. Treatment of raw water of northern reservoir by coagulation/ultrafiltration membrane short technological process[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 210-214.
shu

混凝-超滤短流程工艺处理北方水库原水

  • 1. 抚顺市自来水公司, 抚顺 113000
  • 2. 沈阳建筑大学市政与环境工程学院, 沈阳 110168
  • 收稿日期:  2013-03-15
基金项目:

辽宁省教育厅科学技术研究项目（L2011088）

摘要: 采用混凝-超滤膜短流程工艺对大伙房水库原水进行处理，考察其除污染性能和膜污染情况，并对该短流程工艺参数进行优化。结果表明，当利用超滤膜直接过滤原水时，膜污染较重，并且对污染物质的去除率较低；而采用混凝-超滤短流程工艺时，膜污染得到一定程度上的缓解；当絮凝剂投加量为7 mg/L、膜清洗周期为30 min时，对浊度、CODMn和UV254的去除率分别为95.61%、40.42%和37.12%，出水水质能够满足生活饮用水卫生标准。
