吴悦, 吴纯德, 胡冰, 梁佳莉. O3/GAC-常规处理珠江水系不同原水[J]. 环境工程学报, 2014, 8(2): 520-524.
引用本文: 吴悦, 吴纯德, 胡冰, 梁佳莉. O3/GAC-常规处理珠江水系不同原水[J]. 环境工程学报, 2014, 8(2): 520-524.
shu
Wu Yue, Wu Chunde, Hu Bing, Liang Jiali. Purification of different raw waters of Pearl River using O3/GAC-conventional treatment[J]. Chinese Journal of Environmental Engineering, 2014, 8(2): 520-524.
Citation: Wu Yue, Wu Chunde, Hu Bing, Liang Jiali. Purification of different raw waters of Pearl River using O3/GAC-conventional treatment[J]. Chinese Journal of Environmental Engineering, 2014, 8(2): 520-524.
shu

O3/GAC-常规处理珠江水系不同原水

  • 1.

    华南理工大学环境与能源学院, 广州 510006

  • 2.

    工业聚集区污染控制与生态修复教育部重点实验室, 广州 510006

  • 基金项目:

    国家自然科学基金资助项目（51078148，41173103）

    国家“水体污染控制与治理”科技重大专项（2009ZX07423-003）

  • 中图分类号: X522

Purification of different raw waters of Pearl River using O3/GAC-conventional treatment

  • 1.

    College of Environment and Energy, South China University of Technology, Guangzhou 510006, China

  • 2.

    Key Laboratory of Pollution Control and Ecosystem Restoration in Industry Clusters, Ministry of Education, Guangzhou 510006, China

  • Fund Project:

  • 摘要: 以东江、西江和北江3种原水为研究对象，采用臭氧预处理-常规处理-臭氧活性炭系列处理，研究原水中有机物的去除及臭氧化副产物的产生和转化。结果表明，东江、西江和北江水中CODMn、UV254、甲醛和溴酸盐沿各处理单元过程变化规律基本一致；CODMn总去除率分别为60%、51%和39%，UV254总去除率分别为74%、96%和97%，最终出水甲醛浓度分别为0.004 mg/L、0 mg/L和0 mg/L，BrO3-分别为3.1 μg/L、8.7 μg/L和35.5 μg/L；CODMn的去除主要在预臭氧和活性炭过滤2个处理单元，预臭氧对UV254总去除率贡献最大，甲醛和溴酸盐浓度在主臭氧处理单元达到其峰值（西江甲醛除外）；氨氮和有机物浓度较低、pH值较高的北江原水，出水溴酸盐浓度最高。
    Abstract: The raw waters from Dongjiang River, Xijiang River and Beijiang River were taken as the research objects, and the removal of organic matter and the generation and transformation of ozonation byproducts by preozonation-conventional treatment-O3-GAC combined processes were investigated. The results showed that change laws of CODMn,UV254,formaldehyde and bromate of the three rivers in the processing units were consistent. The total removal rates of CODMn are 60%,51% and 39%, respectively; while those of UV254 are 74%,96% and 97%, respectively. The effluent concentrations of formaldehyde are 0.004 mg/L,0 mg/L and 0 mg/L, respectively; while those of bromate are 3.1 μg/L,8.7 μg/L and 35.5 μg/L, respectively. CODMn are mainly removed in preozonation and GAC units. The influence of preozonation on UV254 removal is relatively great. The peaks of formaldehyde and bromate appear after the post-ozonation unit (except for formaldehyde of Xijiang River). The concentration of bromate in treated water of Beijiang River which has less ammonia nitrogen and organic matter and higher pH value is the highest.
  • 加载中
  • [1] 陈明媚. 珠江流域水污染治理的问题与对策. 广州: 华南理工大学硕士学位论文, 2011 Chen M. M. On the issues and countermeasures to water pollution treatment in the Pearl River Basin. Guangzhou: Master Dissertation of South China University of Technology, 2011 (in Chinese)
    [2] GB5749-2006. 生活饮用水卫生标准. 北京: 中华人民共和国卫生部, 2006
    [3] 贺道红, 高乃云, 曾文慧, 等. 臭氧生物活性炭深度处理黄浦江上游原水. 中国给水排水, 2006, 22(1): 13-17 He D. H., Gao N. Y., Zeng W. H., et al. Pilot-scale study on advanced treatment of Huangpu River upper reaches raw water by ozone-BAC. China Water & Wastewater, 2006, 22(1): 13-17 (in Chinese)
    [4] 李思敏, 赵南南, 李志广. 臭氧/活性炭工艺深度处理微污染水源水的中试. 中国给水排水, 2011, 27(11): 45-47 Li S. M., Zhao N. N., Li Z. G. Pilot study on advanced treatment of micro-polluted source water by O3/GAC process. China Water & Wastewater, 2011, 27(11): 45-47 (in Chinese)
    [5] Kim K. S., Oh B. S., Kang J. W., et al. Effect of ozone and GAC process for the treatment of micro-pollutants and DBPs control in drinking water: Pilot scale evaluation. Ozone Sci. Eng., 2005, 27(1): 69-79
    [6] Melnick R. L. An alternative hypothesis on the role of chemically induced protein droplet nephropathy in renal carcinogenesis. Regulatory Toxicol and Pharmacol, 1992, 16(3): 111-125
    [7] 孔令宇, 张晓健, 王占生. 臭氧-生物活性炭与单独活性炭工艺处理效果比较. 中国给水排水, 2006, 22(11): 49-51 Kong L. Y., Zhang X. J., Wang Z. S. Comparison of performance between O3-BAC and GAC processes. China Water & Wastewater, 2006, 22(11): 49-51 (in Chinese)
    [8] 李璇, 吕锡武, 朱光灿. 臭氧-生物活性炭工艺处理黄浦江微污染原水的中试研究. 水处理技术, 2007, 33(11): 53-56 Li X., Lv X. W., Zhu G. C. Pilot studies on ozone-biological activated carbon process for treating micro-polluted raw water in Huangpu Jiang River. Technology of Water Treatment, 2007, 33(11): 53-56 (in Chinese)
    [9] 黄小红, 鄢敏林, 石鲁娜. 太湖原水净化过程中有机物分子量分布特性研究. 供水技术, 2011, 5(6): 6-9 Huang X. H., Yan M. L., Shi L. N. Molecular weight distribution of organic matters in water purification process for Taihu Lake raw water. Water Technology, 2011, 5(6): 6-9 (in Chinese)
    [10] 郭召海, 杨敏, 张昱, 等. 预臭氧与后臭氧-生物活性炭联用工艺研究. 环境科学, 2005, 26(6): 79-83 Guo Z. H., Yang M., Zhang Y., et al. Study on the combination of preozonation and post-ozonation-BAC process for drinking water treatment. Environmental Science, 2005, 26(6): 79-83 (in Chinese)
    [11] 金鹏康, 王晓昌, 王洪波. 水中腐植酸的臭氧化特性研究. 西安建筑科技大学学报, 2000, 32(4): 334-337 Jin P. K., Wang X. C., Wang H. B. A study on the characteristics of ozonation of aquatic humic substances. J.Xi'an Univ. of Arch. & Tech., 2000, 32(4): 334-337 (in Chinese)
    [12] Ferguson D. W., Gramith J. T., McGuire M. J. Applying ozone for organics control and disinfection: A utility perspective. AWWA, 1993, 85(1): 64-71
    [13] 陆少鸣, 王宁, 杨立. O3-BAC给水深度处理工艺的优化运行. 华南理工大学学报, 2006, 34(12): 10-14 Lu S. M., Wang N., Yang L. Operation optimization of O3-BAC advanced treatment process for drinking water. Journal of South China University of Technology (Natural Science), 2006, 34(12): 10-14 (in Chinese)
    [14] Can Z. S., Gurol M. D. Formaldehyde formation during ozonation of drinking water. Ozone: Science & Engineering, 2003, 25(1): 41-51
    [15] von Gunten U. Ozonation of drinking water: part Ⅱ. disinfection and by-product formation in presence of bromide, iodide or chlorine. Water Res., 2003, 37(7): 1469-1487
    [16] von Gunten U., Hoigne J. Bromate formation during ozonation of bromide-containing waters: Interaction of ozone and hydroxyl radical reactions. Environmental Science & Technology, 1994, 28(7): 1234-1242
    [17] 施东文, 谢曙光, 汪蕊, 等. 生物炭形成过程对溴酸盐和有机物的去除能力研究. 中国给水排水, 2006, 22(19): 5-7 Shi D. W., Xie S. G., Wang R., et al. Removal of bromate and organic substances during transition from fresh activated carbon to BAC. China Water & Wastewater, 2006, 22(19): 5-7 (in Chinese)
    [18] Asami M., Aizawa T., Morioka T., et al. Bromate removal during transition from new granular activated carbon(GAC) to biological activated carbon(BAC). Water Research, 1999, 33(12): 2797-2804
    [19] Amirsardari Y., Yu Q., Williams P. Effect of ozonation and UV irradiation with direct filtration on disinfection and disinfection by-product precursors in drinking water treatment. Environmental Technology, 2001, 22(9): 1015-1023
