石墨气体扩散电极的制备与性能优化

,  ,  ,

downloadPDF

上一篇

下一篇

贾涛涛, 薛娟琴, 毕强, 汪丛. 石墨气体扩散电极的制备与性能优化[J]. 环境工程学报, 2014, 8(6): 2262-2266.
引用本文: 贾涛涛, 薛娟琴, 毕强, 汪丛. 石墨气体扩散电极的制备与性能优化[J]. 环境工程学报, 2014, 8(6): 2262-2266.
shu
Jia Taotao, Xue Juanqin, Bi Qiang, Wang Cong. Preparation and performance optimization of graphite gas diffusion electrode[J]. Chinese Journal of Environmental Engineering, 2014, 8(6): 2262-2266.
Citation: Jia Taotao, Xue Juanqin, Bi Qiang, Wang Cong. Preparation and performance optimization of graphite gas diffusion electrode[J]. Chinese Journal of Environmental Engineering, 2014, 8(6): 2262-2266.
shu

石墨气体扩散电极的制备与性能优化

  • 1.

    西安建筑科技大学冶金工程学院, 西安 710055

  • 基金项目:

    国家自然科学基金资助项目（51278407）

    陕西省自然科学基金重点项目（2012JZ7003）

    陕西省科技统筹创新工程计划课题（2011KTDZ01-05-05）

    陕西省教育厅专项科研项目（13JS062）

  • 中图分类号: X52

Preparation and performance optimization of graphite gas diffusion electrode

  • 1.

    Institute of Metallurgical Engineering, Xi'an University of Architecture and Technology, Xi'an 710055, China

  • Fund Project:

  • 摘要: 电极的制备工艺及参数直接影响电极材料的活性。主要考察了C/PTFE质量比、碾压压力、煅烧温度、造孔剂NH4HCO3及稀土掺杂等因素对电极产出H2O2的影响规律。研究结果表明，电极最佳制备条件为：石墨和PTFE质量比为2：1、石墨、造孔剂和稀土元素质量比为6：1：1、碾压压力10 MPa、煅烧温度330℃。在pH=3、电解质Na2SO4浓度为0.05 mol/L条件下，电解2 h后，改性电极产生的H2O2从95 mg/L提高到350 mg/L，提高了268.4%。
    Abstract: Electrode preparation process and parameters directly influence the activity of electrode materials. This research mainly examines the C/PTFE mass ratio, rolling pressure, calcination temperature and NH4HCO3 and rare earth doped element such as pore-forming agent on the electrode produce the influence law of H2O2. Research results show that the best electrode preparation conditions are as follows: the quality of graphite and PTFE ratio of 2:1, graphite, pore-forming agent and rare earth elements quality ratio of 6:1:1, rolling pressure of 10 MPa, calcination temperature of 330℃. Under the conditions of pH=3 and [NaSO4]=0.05 mol/L, the H2O2 generated by 2 hours' electrolysis with modified electrodes increases by 268.4%, from 95 mg/L to 350 mg/L.
  • 加载中
  • [1] 周明华,戴启洲,雷乐成,等. 新型二氧化铅阳极电催化降解有机污染物的特性研究.物理化学学报,2004,20(8):871-872 Zhou M.H.,Dai Q.Z.,Lei L.C.,et al. New lead dioxide anode electric catalytic degradation of organic pollutants in the characteristics of the study. Journal of physical Chemistry,2004,20(8):871-872(in Chinese)
    [2] 孙大强,毛宗强.质子交换膜染料电池膜电极组件研究.电源技术,2003,(2):92-93 Sun D.Q.,Mao Z.Q. Proton exchange membrane dye cell membrane electrode component. Power Supply Technology,2003,(2):92-93(in Chinese)
    [3] 李亚峰,佟玉衡,陈立杰.实用废水处理技术(第2版).北京:化学工业出版社,2007
    [4] Nidheesh, P. V., Gandhimathi R. Trends in electro-Fenton process for water and wastewater treatment. Desalination,2012,8(1):1-15
    [5] 李华亮,唐念,赵宁.电芬顿水处理技术最新研究进展.北方环境,2011,23(11):182-211 Li H.L.,Tang N.,Zhao N. Electric Fenton latest research progress of water treatment technology. Northern Environment,2011,23(11):182-211(in Chinese)
    [6] 姜成春,庞素艳,马军,等.钛盐光度法测定Fenton氧化中的过氧化氢.中国给水排水,2006,22(4):89-91 Jiang C.C.,Pang S.Y.,Ma J.,et al. Titanium salt spectrophotometry Fenton oxidation of hydrogen peroxide. China Water & Wastewater, 2006,22(4):89-91(in Chinese)
    [7] 郁青红,周明华,雷乐成.新型气体扩散电极体系高效产H2O2的研究.物理化学学报,2006,22(7):883-887 Yu Q. H.,Zhou M. H.,Lei L.C. New type of gas diffusion electrode system efficient production research of H2O2. Journal of Physical Chemistry,2006,22(7):883-887(in Chinese)
    [8] 李平,徐文英.C/PTFE气体扩散电极的杀菌特性研究.中国给水排水,2010,25(16):75-78 Li P.,Xu W.Y. C/PTFE gas diffusion electrode sterilization characteristic research. China Water & Wastewater, 2010,25(16):75-78(in Chinese)
    [9] 王辉,于秀娟,孙德智.一种新型电化学体系降解苯酚的机理研究.环境科学学报,2005,25(7):901-907 Wang H.,Yu X. J.,Sun D.Z. A new type of electrochemical system research the mechanism of degradation of phenol. Acta Scientiae Circumstantiae,2005,25(7):901-907(in Chinese)
    [10] 周震涛,王刚.造孔剂对空气电极性能的影响.电池,2003,33(6):353-354 Zhou Z.T.,Wang G. Pore-forming agent on the properties of air electrode. The Battery, 2003,33(6):353-354(in Chinese)
    [11] Harrington T., Pletcher D. The removal of low levels of organics from aqueous solutions using Fe (Ⅱ) and hydrogen peroxide formed in situ at gas diffusion electrodes. Journal of the Electrochemical Society, 1999,146(8):2983-2989
    [12] 廖飞.氧化镧掺杂石墨/PTFE电极性能研究.杭州:浙江工业大学硕士学位论文,2011 Liao F. Lanthanum oxide doped graphite/PTFE electrode performance study. Hangzhou: Master's Degree Thesis of Zhejiang University of Technology,2011(in Chinese)
    [13] Assumpcao M. H. M. T., Moraes A., De Souza R. F. B., et al.Low content cerium oxide nanoparticles on carbon for hydrogen peroxide electrosynthesis.Applied Catalysis A:General,2012,411:1-6
    [14] 沈洁,樊金红,马鲁铭.气体扩散电极在水处理领域中的研究进展.四川环境,2008,27(5):71-73 Shen J.,Fan J.H.,Ma L.M. Gas diffusion electrode research progress in the field of water treatment. Sichuan Environment, 2008,27(5):71-73(in Chinese)
    [15] 甄丽敏,盛义平,王秀丽.阴极电生H2O2及电-Fenton法降解甲机橙.环境工程学报,2010,4(3):612-613 Zhen L.M.,Sheng Y.P.,Wang X.L. Cathode raw H2O2 degradation of a machine and electric-Fenton method of orange. Chinese Journal of Environmental Engineering,2010,4 (3):612-613(in Chinese)
    [16] 李铮.电芬顿体系中高效气体扩散电极的研究与制备.秦皇岛:燕山大学硕士学位论文,2008 Li Z. Power Fenton system efficient gas diffusion electrode in the research and preparation. Qinhuangdao: Master's Degree Thesis of Yanshan University,2008(in Chinese)
