活性污泥法处理高钙废水中污泥特性的变化

,  ,

downloadPDF

上一篇

下一篇

樊艳丽, 孔秀琴, 牛佳雪. 活性污泥法处理高钙废水中污泥特性的变化[J]. 环境工程学报, 2014, 8(9): 3670-3674.
引用本文: 樊艳丽, 孔秀琴, 牛佳雪. 活性污泥法处理高钙废水中污泥特性的变化[J]. 环境工程学报, 2014, 8(9): 3670-3674.
shu
Fan Yanli, Kong Xiuqin, Niu Jiaxue. Change of sludge characteristics in high cacium wastewater by activated sludge process[J]. Chinese Journal of Environmental Engineering, 2014, 8(9): 3670-3674.
Citation: Fan Yanli, Kong Xiuqin, Niu Jiaxue. Change of sludge characteristics in high cacium wastewater by activated sludge process[J]. Chinese Journal of Environmental Engineering, 2014, 8(9): 3670-3674.
shu

活性污泥法处理高钙废水中污泥特性的变化

  • 1.

    兰州理工大学石油化工学院环境工程系, 兰州 730050

  • 基金项目:

    国家自然科学基金资助项目（51268034）

  • 中图分类号: X703.1

Change of sludge characteristics in high cacium wastewater by activated sludge process

  • 1.

    Department of Environmental Engineering, College of Petrochemical Engineering, Lanzhou University of Technology, Lanzhou 730050, China

  • Fund Project:

  • 摘要: 通过单级SBR法处理模拟高钙废水，研究了活性污泥法处理高钙废水的过程中钙离子对COD，MLVSS，MLSS，SVI，污泥增长速率，污泥形态结构及生物相的影响，揭示活性污泥法处理高钙废水的过程中污泥量巨大的原因。采用逐步增加钙离子浓度的方法，检测到在污泥培养期（[Ca2+]=0 mg/L），COD去除率为98.1%，MLVSS和MLSS稳定在4 900~5 500 mg/L，污泥增长速率为67 mg/（L·d），SVI为55~60 mL/g；在驯化处理期（[Ca2+]=120~2 400 mg/L），COD去除率降至87.37%，MLVSS降至2 500 mg/L，MLSS增加至19 300 mg/L，污泥增长速率为212.31 mg/（L·d），SVI降至25 mL/g；在冲击期（[Ca2+]=4 000 mg/L），COD去除率降至69.23%，MLVSS降至1 600 mg/L，MLSS迅速增加至24 200 mg/L，污泥增长速率为816.67 mg/（L·d），SVI降至14 mL/g。经显微镜观察发现，污泥絮体由松散变得密实，生物相由钟虫等指示性微生物变为不适应环境的胞囊结构。结果表明，随Ca2+浓度的增加，COD去除率下降，MLSS迅速增加，MLVSS和SVI急剧缩小，说明活性污泥中的活性微生物逐渐减少，而无机物组分逐渐增多；钙离子的加入促使系统碳酸平衡向右移动，使离子状态的钙大部分转化为难降解的碳酸盐，并附着于污泥絮体上，污泥绒粒被压缩，使污泥颗粒密实度及MLSS迅速增加，导致污泥排放量巨大。
    Abstract: We studied the influences of different Ca2+ concentrations on the COD removal rate and sludge characteristics, such as MLVSS, MLSS, SVI, sludge growth rate, sludge morphology, and sludge biophase during the process of treating high calcium wastewater with a single sequencing batch reactor, and revealed the causes of huge sludge deposition in this process. Through gradually increasing Ca2+ concentrations, it was detected that in sludge cultivation stage ([Ca2+]=0 mg/L), the COD removal rate was 98.1%, MLVSS and MLSS was around 4 900~5 500 mg/L, sludge growth rate was 67 mg/(L·d), and SVI was 55~60 mL/g; in sludge domestication and disposal stage ([Ca2+]=120~2 400 mg/L), the COD removal rate dropped to 87.37%, MLVSS reduced to 2 500 mg/L, MLSS increased to 19 300 mg/L, the sludge growth rate became 212.31 mg/(L·d), and SVI dropped to 25 mL/g. In the shock stage ([Ca2+]=4 000 mg/L), the COD removal rate fell to 69.23%, MLVSS reduced to 1 600 mg/L, MLSS increased to 24 200 mg/L rapidly, sludge growth rate turned to 816.67 mg/(L·d), and SVI reduced to 14 mL/g. The microscopic observation showed that the structure of sludge flocs turned from loose to compact, and biofacies changed from epistylis to cytocyst. The results indicate that with the increase of Ca2+ concentration, the COD removal rate decreases, MLSS increases rapidly, and MLVSS and SVI drop sharply, which reveals that active microbes reduce and inorganic components increase gradually in the activated sludge; and that the increase of Ca2+ causes the carbonate balance equilibrium of system move to rightwards, and the majority of Ca2+turns into refractory carbonates. These carbonates then attach to the sludge flocs and meanwhile compress them, which leads to the rapid increase of compactness of sludge granules and MLSS. A huge amount of sludge is thus produced.
  • 加载中
  • [1] 邹小兵,孟刚,郑泽根,等.治理明胶生产废水污染研究进展.明胶科学与技术,2004,24(2):74-82 Zou Xiaobing, Meng Gang, Zhen Zegen, et al. Wastewater treatment of gelatin plant. The Science and Technology of Gelatin,2004,24(2):74-82(in Chinese)
    [2] 王远亮,魏小娅.胶原和明胶在化妆品中的应用.明胶科学与技术,1987,7(3):103-112 Wang Yuanliang, Wei Xiaoya. Application of collagen and gelatin in the cosmetics. The Science and Technology of Gelatin,1987,7(3):103-112(in Chinese)
    [3] 殷永泉,刘翔.明胶、骨胶和皮胶工业污染治理状况.明胶科学与技术,2007,27(4):169-184 Yin Yongquan, Liu Xiang. Pollution control situation of gelatin glue bone glue and skin glue industry. The Science and Technology of Gelatin,2007,27(4):169-184(in Chinese)
    [4] 邹小兵.高钙高COD高氮明胶废水长期稳定生物脱氮实验研究.重庆:重庆大学博士学位论文,2004 Zou Xiaobing. The study on long term and steady biological nitrogen removal of high Ca2+ high COD and high N gelatin wastewater. Chongqing: Doctoral Dissertation of Chongqing University,2004(in Chinese)
    [5] 马文臣,徐世杰,房伟,等.炼厂脱盐脱钙废水处理工艺.油气田环境保护,2004,14(2):16-18 Ma Wenchen, Xu Shijie, Fang Wei, et al. Refinery desalination and decalcification wastewater treatment process. Environmental Protection of Oil & Gas Fields,2004,14(2):16-18(in Chinese)
    [6] 赵玉军,殷保华.原油脱钙工艺技术的研究现状与展望.山东化工,2007,36(5):25-28 Zhao Yujun, Yin Baohua. Technology studying status and prospect on technology of removing calcium from crude oil. Shandong Chemical Industy,2007,36(5):25-28(in Chinese)
    [7] 贾菲菲,李多松,张曼,等.我国含盐废水生物处理的研究进展.能源环境保护,2011,26(3):20-22 Jia Feifei, Li Duosong, Zhang Man, et al. The progress of study on biological treatment of salt containing wastewater.Energy Environmental Protection,2011,26(3):20-22(in Chinese)
    [8] Kargil F., Dinceri A.R. Saline wastewater treatment by halophile-supplemented activated sludge culture in an aerated rotating biodisc contactor. Enzyme and Microbial Technology,1998,22(6):427-433
    [9] 肖小兰,陈康,王新华,等.钙离子胁迫下SRT对MBR中污泥性质及膜污染的影响.膜科学与技术,2012,32(4):112-117 Xiao Xiaolan, Chen Kang, Wang Xinhua, et al. Influences of sludge retention time on sludge properties and membrane fouling of submerged membrane bioreactor with the addition of Ca2+. Membrane Science and Technology,2012,32(4):112-117(in Chinese)
    [10] Higgins M.J., Novak J.T. The effect of cations on the settling and dewatering of activated sludges: Laboratory resuits. Water Environ. Res.,1997,69(2):215-224
    [11] Sobeck D.C., Higgins M.J. Examination of three theories for mechanisms of cation-induced bioflocculation. Water Res.,2002,36(3):527-538
    [12] 朱哲,李涛,王东升,等.Ca(Ⅱ)在活性污泥生物絮凝中的作用研究.环境工程学报,2009,3(4):612-616 Zhu Zhe, Li Tao, Wang Dongsheng, et al. Role of Ca(II) in bioflocculation of activated sludge. Chinese Journal of Environmental Engineering,2009,3(4):612-616(in Chinese)
    [13] Kara F., Gurakan G.C., Sanin F.D. Monovalent cations and their influence on activated sludge floc chemistry, structure, and physical characteristics. Biotechnology and Bioengineering,2008,100(2):231-239
    [14] 国家环境保护总局.水和废水监测分析方法(第4版).北京:中国环境科学出版社,2002
    [15] 周群英,王士芬.环境工程微生物学.北京:高等教育出版社,2008
    [16] 马凯,彭继峰.同步硝化反硝化技术的提出及其影响因素分析.安徽建筑工业学院学报(自然科学版),2010,18(4):67-71 Ma Kai, Peng Jifeng. The technology and research on affecting factors of simultaneous nitrification and denitrification. Journal of Anhui Institute of Architecture & Industry (Natural Science),2010,18(4):67-71(in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2127
  • HTML全文浏览数:  1361
  • PDF下载数:  1119
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-09-18
  • 刊出日期:  2014-09-04
樊艳丽, 孔秀琴, 牛佳雪. 活性污泥法处理高钙废水中污泥特性的变化[J]. 环境工程学报, 2014, 8(9): 3670-3674.
引用本文: 樊艳丽, 孔秀琴, 牛佳雪. 活性污泥法处理高钙废水中污泥特性的变化[J]. 环境工程学报, 2014, 8(9): 3670-3674.
shu
Fan Yanli, Kong Xiuqin, Niu Jiaxue. Change of sludge characteristics in high cacium wastewater by activated sludge process[J]. Chinese Journal of Environmental Engineering, 2014, 8(9): 3670-3674.
Citation: Fan Yanli, Kong Xiuqin, Niu Jiaxue. Change of sludge characteristics in high cacium wastewater by activated sludge process[J]. Chinese Journal of Environmental Engineering, 2014, 8(9): 3670-3674.
shu

活性污泥法处理高钙废水中污泥特性的变化

  • 1. 兰州理工大学石油化工学院环境工程系, 兰州 730050
  • 收稿日期:  2013-09-18
基金项目:

国家自然科学基金资助项目（51268034）

摘要: 通过单级SBR法处理模拟高钙废水，研究了活性污泥法处理高钙废水的过程中钙离子对COD，MLVSS，MLSS，SVI，污泥增长速率，污泥形态结构及生物相的影响，揭示活性污泥法处理高钙废水的过程中污泥量巨大的原因。采用逐步增加钙离子浓度的方法，检测到在污泥培养期（[Ca2+]=0 mg/L），COD去除率为98.1%，MLVSS和MLSS稳定在4 900~5 500 mg/L，污泥增长速率为67 mg/（L·d），SVI为55~60 mL/g；在驯化处理期（[Ca2+]=120~2 400 mg/L），COD去除率降至87.37%，MLVSS降至2 500 mg/L，MLSS增加至19 300 mg/L，污泥增长速率为212.31 mg/（L·d），SVI降至25 mL/g；在冲击期（[Ca2+]=4 000 mg/L），COD去除率降至69.23%，MLVSS降至1 600 mg/L，MLSS迅速增加至24 200 mg/L，污泥增长速率为816.67 mg/（L·d），SVI降至14 mL/g。经显微镜观察发现，污泥絮体由松散变得密实，生物相由钟虫等指示性微生物变为不适应环境的胞囊结构。结果表明，随Ca2+浓度的增加，COD去除率下降，MLSS迅速增加，MLVSS和SVI急剧缩小，说明活性污泥中的活性微生物逐渐减少，而无机物组分逐渐增多；钙离子的加入促使系统碳酸平衡向右移动，使离子状态的钙大部分转化为难降解的碳酸盐，并附着于污泥絮体上，污泥绒粒被压缩，使污泥颗粒密实度及MLSS迅速增加，导致污泥排放量巨大。
