麦秆黄原酸酯对水中Cu（II）的吸附

,  ,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

陈俊豪, 李远瞩, 李彦明, 张涛, 李国学, 高茹英, 刁剑雄, 孙英. 麦秆黄原酸酯对水中Cu（II）的吸附[J]. 环境工程学报, 2014, 8(9): 3675-3682.
引用本文: 陈俊豪, 李远瞩, 李彦明, 张涛, 李国学, 高茹英, 刁剑雄, 孙英. 麦秆黄原酸酯对水中Cu（II）的吸附[J]. 环境工程学报, 2014, 8(9): 3675-3682.
shu
Chen Junhao, Li Yuanzhu, Li Yanming, Zhang Tao, Li Guoxue, Gao Ruying, Diao Jianxiong, Sun Ying. Adsorption of Cu(II) in water by straw xanthate[J]. Chinese Journal of Environmental Engineering, 2014, 8(9): 3675-3682.
Citation: Chen Junhao, Li Yuanzhu, Li Yanming, Zhang Tao, Li Guoxue, Gao Ruying, Diao Jianxiong, Sun Ying. Adsorption of Cu(II) in water by straw xanthate[J]. Chinese Journal of Environmental Engineering, 2014, 8(9): 3675-3682.
shu

麦秆黄原酸酯对水中Cu（II）的吸附

  • 1.

    中国农业大学资源与环境学院, 北京 100193

  • 2.

    中国农业大学科学研究院, 北京 100193

  • 基金项目:

    “十二五”科技支撑项目（2012BAD14B01）

  • 中图分类号: X703

Adsorption of Cu(II) in water by straw xanthate

  • 1.

    College of Resources and Environmental Sciences, China Agricultural University, Beijing 100193, China

  • 2.

    Scientific Research Institute, China Agricultural University, Beijing 100193, China

  • Fund Project:

  • 摘要: 采用农业废弃物麦秆为原料制备黄原酸酯，通过傅立叶变换红外光谱FT-IR、扫描电子显微镜SEM等技术对麦秆黄原酸酯物理化学性质进行表征，并对水中Cu2+进行吸附特性研究，考察了不同条件对Cu2+吸附效果的影响，并将其应用于跌水式吸附法对含重金属沼液进行处理，为麦秆黄原酸酯应用于实际污水处理提供理论参考。结果表明，麦秆黄原酸酯对Cu2+的吸附行为符合伪二级动力学吸附模型与Langmuir等温吸附方程，298 K时，Cu2+的饱和吸附量为28.33 mg/g，溶出率为4.97%，对Cu2+的固持能力较强；黄原酸酯跌水吸附法对于含量为50 mg/L以下的Cu2+废水去除率达到80%以上，对实际沼液中Pb、Zn、Cd、Cu的去除率为44.42%~90.16%，去除顺序为Cd>Pb>Cu>Zn。
    Abstract: Straw xanthate was prepared by wheat straw as raw material. The material was characterized by FTIR spectroscopy, SEM and EDS. Adsorption of Cu2+ to straw xanthate in aqueous solution and application of a drop water process to remove the heavy metals from biogas slurry were investigated to provide useful information in predicting the adsorption behavior in practical wastewater treatment. The results show that adsorption data fitted satisfactorily with the pseudo-second order kinetic equation and Langmuir Isotherm. At 298 K, the maximum adsorption equilibrium amount was 28.33 mg/g, only 4.97% of the adsorbate redissolved after high speed oscillation. The drop water adsorption process achieved the elimination of Cu2+ from low concentration wastewater(80%), and the removal rate of Pb, Zn, Cd, Cu from the biogas slurry was from 44.42% to 90.16%(Zn < Cu < Pb < Cd).
  • 加载中
  • [1] Amarasinghe B., Williams R. A. Tea waste as a low cost adsorbent for the removal of Cu and Pb from wastewater. Chemical Engineering Journal, 2007, 132(1): 299-309
    [2] Doan H. D., Lohi A., Dang V. B. H., et al. Removal of Zn2+ and Ni2+ by adsorption in a fixed bed of wheat straw. Process Safety and Environmental Protection, 2008, 86(4): 259-267
    [3] 潘蓉, 曹理想, 张仁铎.青霉菌和镰刀菌对重金属Cd2+, Cu2+, Zn2+和Pb2+的吸附特性.环境科学学报, 2010,30(3): 477-484 Pan R., Cao L. X., Zhang R. D. Biosorption characteristics of heavy metals cadmium, copper, zine, lead by Penicillium and Fusarium fungi. Acta Scientiae Circumstantiae, 2010,30(3):477-484(in Chinese)
    [4] 叶为标, 高群玉.淀粉黄原酸酯在水处理中的应用.粮油加工,2008,(8):94-96 Ye W. B., Gao Q. Y. Development of starch xanthate and its application in water treatment. Cereals & Oils, 2008,(8):94-96(in Chinese)
    [5] Babel S., Kurniawan T. A. Low-cost adsorbents for heavy metals uptake from contaminated water: A review. Journal of Hazardous Materials, 2003,97(1): 219-243
    [6] 刘有才. 淀粉黄原酸酯的制备及其在重金属废水处理中的应用. 昆明: 昆明理工大学硕士学位论文, 2002
    [7] 彭望明.纤维素黄原酸酯对水中Ni2+离子的吸附研究.江汉大学学报(自然科学版),2009,37(4):29-32 Peng W. M. Adsorption of cellulose xanthate to Ni2+ ions in water. Journal of Jianghan University (Natural Sciences), 2009,37(4):29-32(in Chinese)
    [8] Homagai P. L., Ghimire K. N., Inoue K. Adsorption behavior of heavy metals onto chemically modified sugarcane bagasse. Bioresource Technology, 2010, 101(6): 2067-2069
    [9] Yadav S. K., Singh D. K., Sinha S. Adsorption study of lead (II) onto xanthated date palm trunk: Kinetics, isotherm and mechanism. Desalination and Water Treatment, 2013,51(34-36): 6798-6807
    [10] 孙春宝,邢奕,李秋华,等.木屑黄原酸酯的研制及在重金属为水处理中的应用.北京科技大学学报,2006,28(2):108-112 Sun C. B., Xing Y., Li Q. H., et al. Preparation of sawdust cellulose xanthate for the treatment of heavy metal wastewater. Journal of University of Science and Technology Beijing, 2006,28(2):108-112(in Chinese)
    [11] 崔明, 赵立欣, 田宜水, 等. 中国主要农作物秸秆资源能源化利用分析评价.农业工程学报, 2008, 24(12): 291-296 Ming C., Lixin Z., Yishui T., et al. Analysis and evaluation on energy utilization of main crop straw resources in China. Transactions of the Chinese Society of Agricultural Engineering, 2008, 24(12):291-296(in Chinese)
    [12] 周良. 对国内秸秆利用现状的思考. 安徽农业科学, 2012, 40(32): 1585-1585 Zhou L. Thoughts on the domestic present condition of straw utilization. Journal of Anhui Agri. Sci.,2012,40(32):15853-15855(in Chinese)
    [13] 李远瞩,李国学,刁剑雄,等. 麦秆黄原酸酯的合成条件优化及其在去除沼液中重金属的应用.农业环境科学学报,2012,31(9):1848-1853 Li Y. Z., Li G. X., Diao J. X., et al. The optimization of straw xanthates' synthesis condition and the application in elimination of heavy metal ions from biogas slurry. Journal of Agro-Environment Science, 2012,31(9):1848-1853(in Chinese)
    [14] Kilbride C., Poole J., Hutchings T. R. A comparison of Cu, Pb, As, Cd, Zn, Fe, Ni and Mn determined by acid extraction/ICP-OES and ex situ field portable X-ray fluorescence analyses. Environmental Pollution, 2006, 143(1): 16-23
    [15] Kumar P. S., Ramalingam S., Kirupha S. D., et al. Adsorption behavior of nickel (II) onto cashew nut shell: Equilibrium, thermodynamics, kinetics, mechanism and process design. Chemical Engineering Journal, 2011, 167(1): 122-131
    [16] Gonzalez C. A., Chanson H. Hydraulic design of stepped spillways and downstream energy dissipators for embankment dams. Dam Engineering, 2007, 17(4): 223-244
    [17] 张亮,洪松,毛旭辉,等. 自流式复合滤床处理农村生活污水实验研究.华中科技大学学报(自然科学版),2008,36(9):125-128 Zhang L., Hong S., Mao X. H., et al Experimental study on automatic flow compound filter for the treatment of rural domestic wastewater. Journal of Huazhong University of Science and Technology (Nature Science Edition), 2008,36(9):125-128(in Chinese)
    [18] Homagai P. L., Ghimire K. N., Inoue K. Preparation and characterization of charred xanthated sugarcane bagasse for the separation of heavy metals from aqueous solutions. Separation Science and Technology, 2010, 46(2): 330-339
    [19] Liang S., Guo X., Feng N., et al. Application of orange peel xanthate for the adsorption of Pb2+ from aqueous solutions. Journal of Hazardous Materials, 2009, 170(1): 425-429
    [20] Khalir W., Hanafiah M., So'ad S., et al. Adsorption behavior of Pb (II) onto xanthated rubber (Hevea brasiliensis) leaf powder. Polish Journal of Chemical Technology, 2011, 13(4): 84-88
    [21] 何斌.铜试剂-吐温胶束增溶分光光度法测定植物中微量铜.植物营养与肥料学报, 1996,6(2):175-180 He B. Mtcellar solubilization spectrophotometric determination op trace copper in plant with sodium diethyldithiocarbamate and tween-20. Plant Nutrition and Fertilizing Science, 1996, 6(2):175-180(in Chinese)
    [22] zdemir E., Duranoglu D., Beker V, et al. Process optimization for Cr (VI) adsorption onto activated carbons by experimental design. Chemical Engineering Journal, 2011, 172(1): 207-218
    [23] Kumar A., Rao N. N., Kaul S. N. Alkali-treated straw and insoluble straw xanthate as low cost adsorbents for heavy metal removal-preparation, characterization and application. Bioresource Technology, 2000, 71(2): 133-142
    [24] 张利,冯喜文,刘春新,等.大孔树脂吸附金丝桃素的动力学和热力学研究.安徽农业科学, 2010,38(28):15612-15615 Zhang L., Feng X. W., Liu C. X., et al. Study on the kinetics and the thermodynamics of adsorpting hypericin by macroporous resin. Journal of Anhui Agricultural Sciences, 2010, 38(28):15612-15615(in Chinese)
    [25] 钟攀,李泽碧,李清荣,等.重庆沼气肥养分物质和重金属状况研究.农业环境科学学报,2007,26(增刊):165-171 Zhong P., Li Z., Li Q., et al. Contents of selected nutrients and heavy metals in Biogas slurry. Journal of Agro-Environment Science, 2007, 26(5): 165-171(in Chinese)
    [26] 黄惠珠.沼肥营养成分与污染物分析研究.福建农业学报,2010,25(1):86-89 Huang H. Z. Composition of and contaminants in anaerobic fermentation residues. Fujian Journal of Agricultural Sciences, 2010, 25(1):86-89(in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2389
  • HTML全文浏览数:  1429
  • PDF下载数:  681
  • 施引文献:  0
出版历程
  • 收稿日期:  2014-05-19
  • 刊出日期:  2014-09-04
陈俊豪, 李远瞩, 李彦明, 张涛, 李国学, 高茹英, 刁剑雄, 孙英. 麦秆黄原酸酯对水中Cu（II）的吸附[J]. 环境工程学报, 2014, 8(9): 3675-3682.
引用本文: 陈俊豪, 李远瞩, 李彦明, 张涛, 李国学, 高茹英, 刁剑雄, 孙英. 麦秆黄原酸酯对水中Cu（II）的吸附[J]. 环境工程学报, 2014, 8(9): 3675-3682.
shu
Chen Junhao, Li Yuanzhu, Li Yanming, Zhang Tao, Li Guoxue, Gao Ruying, Diao Jianxiong, Sun Ying. Adsorption of Cu(II) in water by straw xanthate[J]. Chinese Journal of Environmental Engineering, 2014, 8(9): 3675-3682.
Citation: Chen Junhao, Li Yuanzhu, Li Yanming, Zhang Tao, Li Guoxue, Gao Ruying, Diao Jianxiong, Sun Ying. Adsorption of Cu(II) in water by straw xanthate[J]. Chinese Journal of Environmental Engineering, 2014, 8(9): 3675-3682.
shu

麦秆黄原酸酯对水中Cu（II）的吸附

  • 1. 中国农业大学资源与环境学院, 北京 100193
  • 2. 中国农业大学科学研究院, 北京 100193
  • 收稿日期:  2014-05-19
基金项目:

“十二五”科技支撑项目（2012BAD14B01）

摘要: 采用农业废弃物麦秆为原料制备黄原酸酯，通过傅立叶变换红外光谱FT-IR、扫描电子显微镜SEM等技术对麦秆黄原酸酯物理化学性质进行表征，并对水中Cu2+进行吸附特性研究，考察了不同条件对Cu2+吸附效果的影响，并将其应用于跌水式吸附法对含重金属沼液进行处理，为麦秆黄原酸酯应用于实际污水处理提供理论参考。结果表明，麦秆黄原酸酯对Cu2+的吸附行为符合伪二级动力学吸附模型与Langmuir等温吸附方程，298 K时，Cu2+的饱和吸附量为28.33 mg/g，溶出率为4.97%，对Cu2+的固持能力较强；黄原酸酯跌水吸附法对于含量为50 mg/L以下的Cu2+废水去除率达到80%以上，对实际沼液中Pb、Zn、Cd、Cu的去除率为44.42%~90.16%，去除顺序为Cd>Pb>Cu>Zn。
