好氧颗粒污泥对膜生物反应器污泥性能的影响

,  ,  ,

downloadPDF

上一篇

下一篇

宋志伟, 曹雯雯, 王秋旭, 王丽燕. 好氧颗粒污泥对膜生物反应器污泥性能的影响[J]. 环境工程学报, 2014, 8(9): 3725-3730.
引用本文: 宋志伟, 曹雯雯, 王秋旭, 王丽燕. 好氧颗粒污泥对膜生物反应器污泥性能的影响[J]. 环境工程学报, 2014, 8(9): 3725-3730.
shu
Song Zhiwei, Cao Wenwen, Wang Qiuxu, Wang Liyan. Influence of aerobic granular sludge on sludge property in membrane bioreactor during phenolic wastewater treatment[J]. Chinese Journal of Environmental Engineering, 2014, 8(9): 3725-3730.
Citation: Song Zhiwei, Cao Wenwen, Wang Qiuxu, Wang Liyan. Influence of aerobic granular sludge on sludge property in membrane bioreactor during phenolic wastewater treatment[J]. Chinese Journal of Environmental Engineering, 2014, 8(9): 3725-3730.
shu

好氧颗粒污泥对膜生物反应器污泥性能的影响

  • 1.

    黑龙江科技大学环境与化工学院, 哈尔滨 150022

  • 2.

    哈尔滨石油学院化学工程系, 哈尔滨 150028

  • 3.

    哈尔滨学院理学院, 哈尔滨 150086

  • 基金项目:

    黑龙江省自然科学基金项目（E201461）

    黑龙江省普通高等学校青年学术骨干支持计划项目（1155G4P）

  • 中图分类号: X703.1

Influence of aerobic granular sludge on sludge property in membrane bioreactor during phenolic wastewater treatment

  • 1.

    School of Environmental and Chemical Engineering, Heilongjiang University of Science and Technology, Harbin 150022, China

  • 2.

    Department of Chemistry Engineering, Harbin Institute of Petroleum, Harbin 150028, China

  • 3.

    School of Science, Harbin University, Harbin 150086, China

  • Fund Project:

  • 摘要: 采用膜生物反应器进行含酚废水的处理，探讨投加好氧颗粒污泥对反应器中污泥性能的影响。结果表明，在膜生物反应器中投加好氧颗粒污泥能有效改善污泥性能，提高处理效果。从采用絮状污泥到逐渐增加好氧颗粒污泥投加量为100%的过程中，反应器中污泥浓度明显提高，MLSS由5 582 mg/L增加到8 168 mg/L；沉降性能得到改善，SVI由135.85 mL/g下降到29.36 mL/g；疏水性增强，Zeta电位由-20.302 mV升高到-4.325 mV；对含酚废水中COD、NH3-N的降解能力明显提高，COD、NH3-N、NO3-N去除率分别由87.3%、83.2%、55.3%增加到99.2%、94.9%、66.3%。改善了膜污染现象，膜通量衰减率由63.3%降低到42.8%。用二元多项式三维回归分析，得到污染物去除率关于好氧颗粒污泥投加量和反应器运行时间的二元方程，对指导好氧颗粒污泥膜生物反应器的连续运行具有重要意义。
    Abstract: Sludge property was analyzed while aerobic granular sludge were added into membrane bio-reactor(MBR)during phenolic wastewater treatment. The results showed that sludge physical property was improved, and sludge biodegradable ability was enhanced. In the process of adding aerobic granular sludge into MBR gradually from 0 to 100 percent, MLSS concentration rised from 5 582 mg/L to 8 168 mg/L, SVI decreased from 135.85 mL/g to 29.36 mL/g,Zeta potential increased from -20.302 mV to -4.325 mV,meanwhile the removal rate of COD, NH3-N, NO3-N increased from87.3%, 83.2%, 55.3% to 99.2%, 94.9%, 66.3%, respectively.The membrane fouling slowed down, the attenuation of membrane flux declined from 63.3% to 42.8%. The bivariate equation was simulated by using three-dimensional regression analysis, it states the relativity between removal rate of pollutants and aerobic granules dosage as well as running time of reactor, which is significant to the continious operation of aerobic granular sludge membrane bio-reactor.
  • 加载中
  • [1] 于开宁,王程,李燕,等. 焦化废水深度处理研究进展. 工业水处理,200929(9): 11-14 Yu K.N., Wang Ch., Li Y., et al. Progress in the research on advanced treatment of coking-plant wastewater. Industrial Water Treatment,2009, 29(9):11-14(in Chinese)
    [2] 宋志伟,张芙蓉. A/O和A2/O工艺对膜生物反应器处理焦化废水影响的研究.环境工程学报,2009,3(12): 2198-2202 Song Z.W., Zhang F.R. Influence of A/O and A2/O process on coking wastewater treatment in membrane bioreactor. Chinese Journal of Enviromental Engineering,2009, 3(12):2198-2202(in Chinese)
    [3] 宋志伟,张芙蓉.污泥浓度对膜生物反应器处理焦化废水影响的研究. 黑龙江科技学院学报,2009,19(6):423-426 Song Z.W., Zhang F.R.Influence of MLSS on treatment efficiency of coking wastewater in membrane bioreactor. Journal of Heilongjiang Insttitute of Science & Technology,2009,19(6):423-426(in Chinese)
    [4] Han S. S., Bae T.H., Jang G.G., et al. Influence of sludge retentiontime on membrane fouling and bioactivities in membrane bioreactor system. Process Biochemistry, 2005,40(7):2393-2400
    [5] 李春杰, 耿琰, 周琪. SMSBR处理焦化废水的膜污染机理研究. 中国给水排水,2002, 18(2): 5-9 Li C.J., Geng Y., Zhou Q., et al. Mechanism of membrane fouling in coke wastewater treatment by submerged membrane sequencing batch reactor. China Water & Wastewater,2002, 18(2): 5-9(in Chinese)
    [6] Yang W., Cicek N., Ilg J. State-of-the-art of membrane bioreactors: Worldwide research and commercial applications in North America. Journal of Membrane Science,2006, 270(1-2):201-211
    [7] 王建龙,张子健,吴伟伟. 好氧颗粒污泥的研究进展. 环境科学学报,2009,29(3):449-473 Wang J.L., Zhang Z.J., Wu W.W. Research advances in aerobic granular sludge.Acta Scientiae Circumstantiae,2009,29(3):449-473(in Chinese)
    [8] 仲海涛, 胡勇有, 张宪宁, 等. 颗粒污泥技术在污水处理中的应用研究进展. 江苏环境科技,2006, 19(4): 35-38 Zhong H.T., Hu Y.Y., Zhang X.N. Research of applying granule in wastewater treatment processes. Jiangsu Environmental Science and Technology,2006, 19(4):35-38(in Chinese)
    [9] Abdulah N., Ujang Z., Yahya A. Aerobic granular sludge formation for high strength agro-based wastewater treatment.Bioresource Technology,2011, 102(12):6778-6781
    [10] Yuan X.J., Gao D.W. Effect of dissolved oxygen on nitrogen removal and process control in aerobic granular sludge reactor. Journal of Hazardous Materials,2010, 178(1-3): 1041-1045
    [11] 王景峰,王暄,季民,等. 好氧颗粒污泥膜生物反应器脱氮性能. 环境科学,2007,28(3):528-533 Wang J.F., Wang X., Ji Min., et al. Characteristics of nitrogen removal in aerobic granular sludge membrane bioreactor. Enviromental Science,2007, 28(3):528-533(in Chinese)
    [12] 朱振中,周艳,李秀芬,等.好氧颗粒污泥膜生物反应器的运行特性.环境科学,2006,27(1):57-62 Zhu Z.Z., Zhou Y.,Li X.F., et al. Characteristics of aerobic granular sludge membrane bioreactor for wastewater treatment. Enviromental Science,2006, 27(1):57-62(in Chinese)
    [13] 宋志伟, 梁洋.好氧颗粒污泥的培养及其性能. 黑龙江科技学院学报,2008,18(3):164-167 Song Z.W., Liang Y. Culture and characteristics of aerobic granular sludge. Journal of Hei Longjiang Insttitute of Science & Technology,2008,18(3):164-167(in Chinese)
    [14] 国家环境保护总局.水和废水监测分析方法(第4版).中国环境科学出版社,2002
    [15] Beun J. J.,Hendriks A.,van Loosdrecht M. C. M., et al. Aerobic granulation in a sequencing batch reactor. Water Research,1999,33(10):2283-2290
    [16] 孙寓娇,左剑恶,杨洋,等.好氧亚硝化颗粒污泥中硝化细菌群落结构分析.环境科学,2006,27(9):1858-1861 Sun Y.J., Zuo J.E., Yang Y., et al. Community structure of nitrification bacteria in aerobic short-cut nitrification granule. Enviromental Science,2006,27(9):1858-1861(in Chinese)
