应用新型调制荧光成像系统(Imaging-PAM)原位评估底泥毒性的方法

,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

虞龙, 苗秀珍, 于洋, 张民, 阳振, 叶琳琳, 孔繁翔. 应用新型调制荧光成像系统(Imaging-PAM)原位评估底泥毒性的方法[J]. 环境化学, 2010, 29(6): 1116-1120.
引用本文: 虞龙, 苗秀珍, 于洋, 张民, 阳振, 叶琳琳, 孔繁翔. 应用新型调制荧光成像系统(Imaging-PAM)原位评估底泥毒性的方法[J]. 环境化学, 2010, 29(6): 1116-1120.
shu
YU Long, MIAO Xiuzhen, YU Yang, ZHANG Min, YANG Zhen, YE Linlin, KONG Fanxiang. AN IN-SITU ASSESSMENT OF SEDIMENT TOXICITY WITH THE APPLICATION OF IMAGING-PAM[J]. Environmental Chemistry, 2010, 29(6): 1116-1120.
Citation: YU Long, MIAO Xiuzhen, YU Yang, ZHANG Min, YANG Zhen, YE Linlin, KONG Fanxiang. AN IN-SITU ASSESSMENT OF SEDIMENT TOXICITY WITH THE APPLICATION OF IMAGING-PAM[J]. Environmental Chemistry, 2010, 29(6): 1116-1120.
shu

应用新型调制荧光成像系统(Imaging-PAM)原位评估底泥毒性的方法

  • 1.

    南京工业大学生物与制药工程学院, 南京, 210009;

  • 2.

    中国科学院南京地理与湖泊研究所, 湖泊与环境国家重点实验室, 南京, 210008

  • 基金项目:

    国家自然科学基金项目(20807043)

    中国科学院南京地理与湖泊研究所所长基金(07SL021001)资助

AN IN-SITU ASSESSMENT OF SEDIMENT TOXICITY WITH THE APPLICATION OF IMAGING-PAM

  • 1.

    College of Biotechnology and Pharmaceutical Engineering, Nanjing University of Technology, Nanjing, 210009, China;

  • 2.

    Nanjing Institute of Geography & Limnology, Chinese Academy of Sciences, State Key Laboratory of Lake Science and Environment, Nanjing, 210008, China

  • Fund Project:

  • 摘要: 应用新型调制叶绿素荧光成像系统Imaging-PAM,通过最大叶绿素荧光量子产量(Fv/Fm)、实际荧光量子产量(YⅡ)指标的测定原位评估了友谊河底泥对斜生栅藻(Scenedesmus obliqnus)的毒性效应.数据显示,在友谊河底泥悬浮液中,栅藻的Fv/Fm和YⅡ值在12h前快速上升,12h后呈现出时间-效应型曲线,72h时Fv/Fm和YⅡ分别下降至对照的44%和35%,Fv/Fm和YⅡ的半抑制时间分别为57h和45h.同时,通过对友谊河底泥样品中重金属含量的检测,计算地积累指数(Igeo),得出友谊河底泥中的Hg、Zn和Cu分别为严重污染,重污染和偏重污染水平,这可能是影响藻类光合作用的主要污染物.本研究为进行底泥毒性评估提供了新的原位分析方法.
    Abstract: New modulated chlorophyll fluorescence imaging system Imaging-PAM has been applied as an effective detection in short-term bioassays with Scenedesmus obliquus. Maximum quantum yield of chlorophyll fluorescence (Fv/Fm) and the actual fluorescence quantum yield (YⅡ) were used to assess the toxicity of the sediment from Youyi River. Data showed that in 12h exposure there was a rapid increase in Fv/Fm and YⅡof Scenedesmus obliquus in the sediment suspension of Youyi River, whereas after 12h a time-response curve appeared. In 72h the Fv/Fm and YⅡdropped to 44% and 35% of that of the control respectively, the half-inhibition time of Fv/Fm and YⅡwere 57h and 45h. At the same time by detecting the concentration of heavy metals in the sediment of Youyi River, the index of geoaccumulation (Igeo) was accounted as follows: Hg, Zn, and Cu reached serious pollution, heavy pollution and partial heavy pollution levels respectively. They are the probobly the primary contaminants affecting the photosynthesis of algae. This study may provide a new method to assess the toxicity of sediment in situ.
  • 加载中
  • [1] Grunwald B, Kuhl M. A system for imaging variable chlorophyll fluorescence of aquatic phototrophs[J].Ophelia, 2004, 58(2):79-89
    [2] Hill R, Schreiber U, Gademann R, et al. Spatial heterogeneity of photosynthesis and the effect of temperature-induced bleaching conditions in three species[J]. Mar Biol, 2004, 144(4):633-640
    [3] Ralph P J, Macinnis-Ng C M O, Frankart C. Fluorescence imaging application: effect of leaf age on seagrass photokinetics[J].Aquat Bot,2005, 81(1):69-84
    [4] Podola B, Nowack E C M, Melkonian M. The use of multiplestrain algal sensor chips for the detection and identification of volatile organic compounds[J].Biosens Bioelectron, 2004, 19(10):1253-1260
    [5] 任小龙, 贾志宽, 陈小莉,等. 半干旱区沟垄集雨对玉米光合特性及产量的影响[J].作物学报, 2008, 34(5):838-845
    [6] 马守臣, 徐炳成, 李凤民,等. 冬小麦(Triticum aestivum)分蘖冗余生态学意义以及减少冗余对水分利用效率的影响[J].生态学报, 2008, 28(1):321-326
    [7] 窦新永, 吴国江, 黄红英,等. 麻枫树幼苗对干旱胁迫的响应[J].应用生态学报,2008, 19(7):1425-1430
    [8] 彭长连. 三种濒危木兰植物幼树光合特性对高温的响应[J].生态学报, 2008, 28(7):1-9
    [9] 宋莉英, 孙兰兰, 舒展,等. 干旱和复水对入侵植物三裂叶蟛蜞菊叶片叶绿素荧光特性的影响[J]. 生态学报, 2009, 29(7):3714-3721
    [10] 林阿朋, 王超, 乔洪金,等. 青岛海域漂浮和沉降浒苔的光合作用研究[J].科学通报, 2009, 54(4):294-298
    [11] Vankooten, Snel J F H. The use of chlorophyll fluorescence nomenclature in plant stress physiology[J].Photosynth Res, 1990, 25(3):147-150
    [12] 许大全, 张玉忠, 张荣铣,等. 植物光合作用光抑制[J].植物生理学通讯, 1992, 28(4):237-243
    [13] 张玉荣, 刘峰, 单体锋,等. 利用叶绿素荧光技术揭示人工培育的铜藻幼苗对胁迫温度、光照和盐度的反应[J].南方水产, 2009, 5(2):1-9
    [14] D'Ambrosio N, Arena C, De Santo A V. Temperature response of photosynthesis, excitation energy dissipation and alternative electron sinks to carbon assimilation in beta vulgaris L[J].Environ Exp Bot, 2006, 55(3):248-257
    [15] Joo Silva, Rui Santos. Can chlorophyl fluorescence be used to estimate photosynthetic production in the seagrass zostera noltii?[J].J Exp Mar Bio Ecol, 2004, 307(2):207-216
    [16] Calabrese E J, Baldwin L A. Toxicology rethinks its central belief. Hormesis demands a reappraisal of the way risks are assessed[J]. Nature, 2003, 421(6924):691-692
    [17] Merrin S, Adams, Jennifer L S. Development of a whole sediment toxicity test using a benthic marine microalga[J]. Environ Toxicol Chem, 2004, 23(8):1957-1968
    [18] Ballan D C. Response of the phytoplanktonic algae to Cu and Ag exposure:vesicular metal bioaccumulation and lack of starsh bodies[J]. Biol Cell, 1991, 72(1/2):103-112
    [19] Schansker G. Performance of active photosystemⅡcenters in photoinhibited pea leaves[J].Photosynth Res, 1999, 62 (2/3):175-184
    [20] Mmler G. Index of geoaccumulafion in sediments of the rhine river[J].Geojournal, 1969, 2(5):108-118
    [21] Mallick N, Mohn F H. Use of chlorophyll fluorescence in metal-stress research:a case study with the green mlcroalga Scenedesmus[J].Ecotoxicol Environmen Saf, 2003, 55(1):64-69
