填充粒子对三维电极处理MDEA污水的影响

王兵; 舒帮云; 任宏洋; 王波

doi:10.12030/j.cjee.201601141

环境工程学报

填充粒子对三维电极处理MDEA污水的影响

, , ,

王兵, 舒帮云, 任宏洋, 王波. 填充粒子对三维电极处理MDEA污水的影响[J]. 环境工程学报, 2017, 11(1): 205-210. doi: 10.12030/j.cjee.201601141

引用本文:

王兵, 舒帮云, 任宏洋, 王波. 填充粒子对三维电极处理MDEA污水的影响[J]. 环境工程学报, 2017, 11(1): 205-210. doi: 10.12030/j.cjee.201601141

WANG Bing, SHU Bangyun, REN Hongyang, WANG Bo. Effects of three dimensional electrode filling particles on treatment of MDEA effluent[J]. Chinese Journal of Environmental Engineering, 2017, 11(1): 205-210. doi: 10.12030/j.cjee.201601141

Citation:

WANG Bing, SHU Bangyun, REN Hongyang, WANG Bo. Effects of three dimensional electrode filling particles on treatment of MDEA effluent[J]. Chinese Journal of Environmental Engineering, 2017, 11(1): 205-210. doi: 10.12030/j.cjee.201601141

填充粒子对三维电极处理MDEA污水的影响

1.
西南石油大学化学化工学院, 成都, 610500
2.
四川省环境保护油气田污染防治与环境安全重点实验室, 成都, 610500
基金项目:
中石化科技项目（114120）

四川省科技支撑项目（16CZ2067）
中图分类号: X743

Effects of three dimensional electrode filling particles on treatment of MDEA effluent

1.
College of Chemistry and Chemical Engineering, Southwest Petroleum University, Chengdu 610500, China
2.
Key Laboratory of Environmental Pollution Prevention on Oil and Gas Fields and Environmental Safety in Sichuan, Chengdu 610500, China
Fund Project:

摘要: 采用三相三维电极反应器处理MDEA模拟污水，重点考察了粒子电极形状、加量、堆放方式以及绝缘程度对MDEA污水处理效果的影响。研究结果表明：当填充粒子投加量为600 000 mg·L-1时，COD去除率最高，为52.9%；采用α堆放方式时，因粒子电极沿电场线方向的有效长度更长，粒子电极工作端电压、端电流越大，COD去除率越高。此外，采用粒子电极负载醋酸纤维素的全绝缘方式，可有效避免短路电流的形成，在电催化处理30 min时，其比不绝缘的COD去除率提高了20%。
- 三维电极 /
- 粒子电极 /
- 堆放方式 /
- 绝缘程度
Abstract: A three-phase, three-dimensional electrode reactor treated simulative wastewater electrolytically. Particular attention was paid to the treatment efficiency of different particle sizes, dosages, stacking modes, and manner of insulation in the system. The results verified that when the filling particle dosage was 600 000 mg·L-1, the COD removal efficiency reached 52.9%. When using the α stacking mode, namely, a longer effective length of the particle electrode along the electric field line direction, higher particle-side current, terminal voltage, and COD removal rate were obtained. Moreover, when a cellulose acetate particle electrode in a loading fully insulated manner, which can effectively prevent the formation of a short-circuit current, and an electrocatalytic process of 30 min were used, the COD removal rate of particles was 20% higher than it was when no insulation coated with phenolic resin on carbon surface.
- three-dimensional electrode /
- particle electrode /
- stacking mode /
- degree of insulation

[1]	王晓东,王文娟.空气氧化处理天然气处理厂检修污水探索[J].石油与天然气化工,2011,40(2):211-213
[2]	BACKHURST J R,Conclson J M.,GOODRIDGE F, et al. A proliminary investignation of fluidized bed electrodes[J]. Journal of the Electrochemical Society,1969,116(11):1600-1607
[3]	张鹏娟,买文宁,赵敏,等.三维电极法深度处理维生素生产废水[J].环境工程学报,2013,7(3):897-902
[4]	熊英健,范娟,朱锡海.三维电极电化学水处理技术研究现状及方向[J].工业水处理,1998,18(1):5-8
[5]	陈武,李凡修,梅平,等.废水处理的电化学方法研究进展[J].湖北化工,2001,3(1):10-12
[6]	LE T Q, KQ J H. Effect of hydrofoil flexibility on the power extration of a flapping tidal generator via two-and three-dimensional flow simulations[J]. Renewable Energy,2015,80(68):275-285
[7]	冯冻国,赵卫星,姜奕,等.三维电极在水处理中的运用[J].应用化工,2010,39(9):1391-1393
[8]	孟庆杰,吴勇,柯斌,等.三维电极法在污水处理中的运用[J].应用技术,2012,11(35):35-38
[9]	陈卫国,朱锡海.电催化产生H₂O₂和·OH及去除废水中有机污染物的应用[J].中国环境科学,1998,18(2):148-150
[10]	ZHAO Huazhang, SUN Yan, XU Lina, et al. Removal of Acid Orange 7 in simulated wastewater using a three-dimensional electrode reactor:Removal mechanisms and dye degradation pathway[J].Chemosphere,2010,78(1):46-51
[11]	ZHANG Chao, JIANG Yonghai, LI Yunlin, et al. Three-dimensional electrochemical process for wastewater treatment:A general review[J]. Chemical Engineering Journal,2013,228(13):455-467
[12]	张芳,李光明,盛怡,等.三维电解法处理苯酚废水的粒子电极研究[J].环境科学,2007,8(8):1715-1719
[13]	班福忱,刘炯天,程琳,等.三维和二维电极法催化降解苯酚废水[J].沈阳建筑大学学报(自然科学版),2009,25(1):156-160
[14]	陈武,艾俊哲,李凡修,等.电化学反应器:三维电极中粒子电极应用研究[J].荆州师范学院报,2002,25(5):76-78
[15]	汤亚飞,鲍仁冬,程姗.三维电极体系中填充粒子的工作机理[J].武汉工程大学学报,2012,34(9):59-61
[16]	张芳,李光明,等.三维电极法处理苯酚废水的粒子电极研究[J].环境科学,2007,28(8):1715-1719
[17]	张垒,段爱明,王丽娜,等.流化床三维电极电催化氧化深度处理焦化废水[J].生态环境学报,2012,21(2):370-374
[18]	汤亚飞,鲍仁冬,程姗.三维电极体系中填充粒子的工作机理[J].武汉工程大学学报,2012,34(9):59-61
[19]	张垒,段爱明,等.流化床三维电极电催化氧化深度处理焦化废水[J].生态环境学报,2012,21(2):370-374
[20]	姜峰.匀强电场中电势差的推论及应用[J].物理教学探讨,2009,27(10):25-26
[21]	钟锐超,周德鸿,陈卫国,等.粒子电极堆放方式对三维电极体系性能的影响研究[J].环境科学学报,2011,31(10):2174-2178
[22]	乔启成,赵跃民,王立章,等.三维电极体系中有机物降解电流效率及动力学[J].石油学报(石油加工),2013,29(3):532-538
[23]	周抗寒,周定.用涂抹活性炭提高复极性电解槽电解效率[J].环境科学,1994,15(2):38-41
