响应面法优化污泥炭催化湿式过氧化氢氧化降解间甲酚模拟废水

,  ,  ,  ,

downloadPDF

上一篇

下一篇

赵颖, 王亚旻, 卫皇曌, 于杨, 孙承林. 响应面法优化污泥炭催化湿式过氧化氢氧化降解间甲酚模拟废水[J]. 环境化学, 2016, 35(3): 516-525. doi: 10.7524/j.issn.0254-6108.2016.03.2015100801
引用本文: 赵颖, 王亚旻, 卫皇曌, 于杨, 孙承林. 响应面法优化污泥炭催化湿式过氧化氢氧化降解间甲酚模拟废水[J]. 环境化学, 2016, 35(3): 516-525. doi: 10.7524/j.issn.0254-6108.2016.03.2015100801
shu
ZHAO Ying, WANG Yamin, WEI Huangzhao, YU Yang, SUN Chenglin. Optimization of m-cresol degradation by sludge-derived carbon in catalytic wet peroxide oxidation using response surface methodology[J]. Environmental Chemistry, 2016, 35(3): 516-525. doi: 10.7524/j.issn.0254-6108.2016.03.2015100801
Citation: ZHAO Ying, WANG Yamin, WEI Huangzhao, YU Yang, SUN Chenglin. Optimization of m-cresol degradation by sludge-derived carbon in catalytic wet peroxide oxidation using response surface methodology[J]. Environmental Chemistry, 2016, 35(3): 516-525. doi: 10.7524/j.issn.0254-6108.2016.03.2015100801
shu

响应面法优化污泥炭催化湿式过氧化氢氧化降解间甲酚模拟废水

  • 1.

    中国科学院大连化学物理研究所, 大连, 116023;

  • 2.

    中国科学院大学, 北京, 100049

Optimization of m-cresol degradation by sludge-derived carbon in catalytic wet peroxide oxidation using response surface methodology

  • 1.

    Dalian Institute of Chemical Physics, Chinese Academy of Sciences, Dalian, 116023, China;

  • 2.

    University of Chinese Academy of Sciences, Beijing, 100049, China

  • 摘要: 以污水处理厂剩余污泥为原料制备硝酸改性活性炭,用于催化湿式过氧化氢氧化(CWPO)处理间甲酚模拟废水,以实现剩余污泥的资源化利用.使用物理吸附、程序升温脱附(TPD)、X射线荧光光谱(XRF)等表征方法对污泥炭的物理化学性质进行测定.而后采用响应面法(RSM)优化污泥炭CWPO降解间甲酚的反应条件,选取反应温度、反应时间、初始pH值、过氧化氢(H2O2)投加量及催化剂投加量为影响因子,总有机碳(TOC)去除率为响应值,应用中心组合设计(CCD)建立响应值与各影响因子之间关系的二次多项式数学模型,采用后退回归法进行模型精简,并通过方差分析对模型进行可信程度检验.优化结果表明,在反应温度为60℃,反应时间为120 min,初始pH=3.00,H2O2投加量为2.03 g·L-1,催化剂投加量为0.78 g·L-1的条件下,可达到最佳效果,此时预测模型的TOC去除率为44.6%,间甲酚转化率为100%.通过模型验证实验得到的TOC去除率为46.6%,仅与理论值相差2.0%,在95%的置信区间内,说明该模型具有可靠性.最后采用GC-MS对污泥炭CWPO降解间甲酚中间产物进行分析.
    Abstract: In this study, nitric acid modified activated carbon prepared from excess sludge produced in sewage treatment plant was employed to degrade m-cresol simulated wastewater by catalytic wet peroxide oxidation (CWPO), which helps to recycle and re-utilize the waste sludge. Physical adsorption, temperature programmed desorption (TPD) and X ray fluorescence spectrometry (XRF) were used to determine the physical and chemical characteristics of the sludge-derived activated carbon, and the response surface methodology (RSM) was applied to optimize the reaction conditions. Reaction temperature, reaction time, initial pH value, hydrogen peroxide(H2O2) dosage, catalyst dosage were selected as factors while total organic carbon (TOC) removal rate was the response. An quadratic polynomial mathematical model between the response and 5 impact factors was derived using the central composite design (CCD), refined using the backward regression method, and examined through the analysis of variance (ANOVA). The optimized reaction conditions in CWPO process were found out to the reaction temperature of 60℃, the reaction time of 120 min, initial pH=3.00, H2O2 dosage of 2.03 g·L-1, catalyst dosage of 0.78 g·L-1. TOC removal rate and m-cresol conversion reached their optimal values at 44.6% and 100%, respectively.Under these conditions, The TOC removal rate in the validation experiment was 46.6%. This experimental optimal TOC removal rate is only 2.0% more than its theoretical optimum and is within the 95% confidence interval. The intermediate products from the m-cresol degradation process by sludge derived activated carbon were also analyzed using GC-MS.
  • 加载中
  • [1] JIANG Y, CAI X, WU D, et al. Biodegradation of phenol and m-cresol by mutated Candida tropicalis[J]. Journal of Environmental Sciences, 2010, 22(4):621-626.
    [2] ZAZO J A, BEDIA J, FIERRO C M, et al. Highly stable Fe on activated carbon catalysts for CWPO upon FeCl3 activation of lignin from black liquors[J]. Catalysis Today, 2012, 187(1):115-121.
    [3] 刘琰,孙德智,李磊.常温常压下催化湿式过氧化氢氧化工艺的研究[J]. 化工环保,2006,26(2):83-86.

    LIU Y, SUN DZ, LI L,et al. Study on catalytic wet hydrogen peroxide oxidation process under room temperature and atmospheric pressure[J]. Environmental Protection of Chemical Industry, 2006, 26(2):83-86(in Chinese).

    [4] NAVALON S, ALVARO M, GARCIA H. Heterogeneous Fenton catalysts based on clays, silicas and zeolites[J]. Applied Catalysis B:Environmental, 2010, 99(1/2):1-26.
    [5] DHAOUADI A,ADHOUM N. Heterogeneous catalytic wet peroxide oxidation of paraquat in the presence of modified activated carbon[J]. Applied Catalysis B:Environmental, 2010, 97(1/2):227-235.
    [6] MUNOZ M, DE PEDRO Z M, CASAS J A, et al. Improved wet peroxide oxidation strategies for the treatment of chlorophenols[J]. Chemical Engineering Journal, 2013, 228:646-654.
    [7] MUNOZ M, DE PEDRO Z M, MENENDEZ N, et al. A ferromagnetic gamma-alumina-supported iron catalyst for CWPO. Application to chlorophenols[J]. Appl Catal B-Environ, 2013, 136:218-224.
    [8] DI LUCA C, IVORRA F, MASSA P, et al. Alumina supported fenton-like systems for the catalytic wet peroxide oxidation of phenol solutions[J]. Ind Eng Chem Res, 2012, 51(26):8979-8984.
    [9] WANG X, ZHU N, YIN B. Preparation of sludge-based activated carbon and its application in dye wastewater treatment[J]. Journal of hazardous materials, 2008, 153(1/2):22-27.
    [10] LI W H, YUE Q Y, GAO B Y, et al. Preparation and utilization of sludge-based activated carbon for the adsorption of dyes from aqueous solutions[J]. Chemical Engineering Journal, 2011, 171(1):320-327.
    [11] KHATAEE A R, ZAREI M, MORADKHANNEJHAD L. Application of response surface methodology for optimization of azo dye removal by oxalate catalyzed photoelectro-Fenton process using carbon nanotube-PTFE cathode[J]. Desalination,2010,258(1/3):112-119.
    [12] DAVARNEJAD R, MOHAMMADI M, ISMALI A F. Petrochemical wastewater treatment by electro-Fenton process using aluminum and iron electrodes:Statistical comparison[J]. Journal of Water Process Engineering, 2014, 3:18-25.
    [13] TRAWCZYNSKI J, SUPPAN S, SAYAG C, et al. Surface acidity of the activated CBC[J]. Fuel Processing Technology, 2002, 77-78:317-324.
    [14] BAS D, BOYACIH. Modeling and optimization I:Usability of response surface methodology[J]. Journal of Food Engineering, 2007, 78(3):836-845.
    [15] WU D F,LI Y D, SHI Y H,et al. Effects of the calcination conditions on the mechanical properties of a PCoMo-Al2O3 hydrotreating catalyst[J]. Chemical Engineering Science, 2002, 57(17):3495-3504.
    [16] BEG Q K,SAHAI V,GUPTA R. Statistical media optimization and alkaline protease production from Bacillus mojavensis in a bioreactor[J]. Process Biochemistry, 2003, 39(2):203-209.
    [17] ARALAN-ALATON I, AKIN A, OLMEZ-HANCI T. An optimization and modeling approach for H2O2/UV-C oxidation of a commercial non-ionic textile surfactant using central composite design[J]. Journal of Chemical Technology & Biotechnology, 2010, 85:493-501.
    [18] ANA R, FARALDOS M, ANA B. Role of the activated carbon surface on catalytic wet peroxide oxidation[J]. Industrial and Engineering Chemistry Research, 2008, 47:8166-8174.
    [19] GORGULHO F, MESQUITA J, GONCALVES F, et al. Characterization of the surface chemistry of carbon materials by potentiometric titrations and temperature-programmed desorption[J]. Carbon, 2008, 46(12):1544-1555.
    [20] MORENO-CASTILLA C, CARRASCO-MARIN F, MALDONADO-HODARY F J, et al. Effects of non oxidant and oxidant acid treatments on the surface properties of an activated carbon with very low ash content[J]. Carbon, 1998, 36:145-151.
    [21] DOMINGUEZ C M, OCON P, QUINTANILLA A, et al. Highly efficient application of activated carbon as catalyst for wet peroxide oxidation[J]. Applied Catalysis B:Environmental, 2013, 140-141:663-670.
    [22] 董俊明,曾光明,杨朝晖.催化湿式过氧化氢氧化法的研究[J]. 环境科学动态,2004,(3):29-31. DONG J M, ZENG G M, YANG Z H. Research of catalytic wet hydrogen peroxide oxidation method[J]. Environmental Science Trends, 2004

    , (3):29-31(in Chinese).

    [23] MARTINEZ F, PARIENTE I, BREBON C, et al. Chemical surface modified-activated carbon cloth for catalytic wet peroxide oxidation of phenol[J].Chem Technol Biotechnol, 2014, 89(8):1182-1188.
    [24] BOSSMANN S H, OLIVEROS E, GOB S, et al. New evidence against hydroxyl radicals as reactive intermediates in the thermal and photochemically enhanced fenton reactions[J]. Journal of Physical Chemistry A, 1998, 102(28):5542-5550.
    [25] LIU P J, HE S B, WEI H Z, et al. Characterization of α-Fe2O3/γ-Al2O3catalysts for catalytic wet peroxide oxidation of m-cresol[J]. Ind Eng Chem Res, 2015, 54(1):130-136.
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1072
  • HTML全文浏览数:  996
  • PDF下载数:  592
  • 施引文献:  0
出版历程
  • 收稿日期:  2015-10-08
  • 刊出日期:  2016-03-15
赵颖, 王亚旻, 卫皇曌, 于杨, 孙承林. 响应面法优化污泥炭催化湿式过氧化氢氧化降解间甲酚模拟废水[J]. 环境化学, 2016, 35(3): 516-525. doi: 10.7524/j.issn.0254-6108.2016.03.2015100801
引用本文: 赵颖, 王亚旻, 卫皇曌, 于杨, 孙承林. 响应面法优化污泥炭催化湿式过氧化氢氧化降解间甲酚模拟废水[J]. 环境化学, 2016, 35(3): 516-525. doi: 10.7524/j.issn.0254-6108.2016.03.2015100801
shu
ZHAO Ying, WANG Yamin, WEI Huangzhao, YU Yang, SUN Chenglin. Optimization of m-cresol degradation by sludge-derived carbon in catalytic wet peroxide oxidation using response surface methodology[J]. Environmental Chemistry, 2016, 35(3): 516-525. doi: 10.7524/j.issn.0254-6108.2016.03.2015100801
Citation: ZHAO Ying, WANG Yamin, WEI Huangzhao, YU Yang, SUN Chenglin. Optimization of m-cresol degradation by sludge-derived carbon in catalytic wet peroxide oxidation using response surface methodology[J]. Environmental Chemistry, 2016, 35(3): 516-525. doi: 10.7524/j.issn.0254-6108.2016.03.2015100801
shu

响应面法优化污泥炭催化湿式过氧化氢氧化降解间甲酚模拟废水

  • 1.  中国科学院大连化学物理研究所, 大连, 116023;
  • 2.  中国科学院大学, 北京, 100049
  • 收稿日期:  2015-10-08

摘要: 以污水处理厂剩余污泥为原料制备硝酸改性活性炭,用于催化湿式过氧化氢氧化(CWPO)处理间甲酚模拟废水,以实现剩余污泥的资源化利用.使用物理吸附、程序升温脱附(TPD)、X射线荧光光谱(XRF)等表征方法对污泥炭的物理化学性质进行测定.而后采用响应面法(RSM)优化污泥炭CWPO降解间甲酚的反应条件,选取反应温度、反应时间、初始pH值、过氧化氢(H2O2)投加量及催化剂投加量为影响因子,总有机碳(TOC)去除率为响应值,应用中心组合设计(CCD)建立响应值与各影响因子之间关系的二次多项式数学模型,采用后退回归法进行模型精简,并通过方差分析对模型进行可信程度检验.优化结果表明,在反应温度为60℃,反应时间为120 min,初始pH=3.00,H2O2投加量为2.03 g·L-1,催化剂投加量为0.78 g·L-1的条件下,可达到最佳效果,此时预测模型的TOC去除率为44.6%,间甲酚转化率为100%.通过模型验证实验得到的TOC去除率为46.6%,仅与理论值相差2.0%,在95%的置信区间内,说明该模型具有可靠性.最后采用GC-MS对污泥炭CWPO降解间甲酚中间产物进行分析.
