豫北大田蔬菜种植区地下水重金属的分布特征及来源解析
Distributions and sources of heavy metals in groundwater of vegetable fields in North Henan Province
-
摘要: 选择豫北山前平原大田蔬菜种植区地下水为研究对象，分枯水期（5月）和丰水期（10月）采集地下水样品，采用电感耦合等离子体质谱仪（ICP-MS）分析重金属含量，借助空间分布特征，并结合主成分分析方法，对地下水重金属进行源解析.结果表明：（1）研究区枯水期和丰水期浅层地下水pH值均值分别为7.26和7.15，电导率（EC值）均值分别为1200 μS·cm-1和1256 μS·cm-1，丰水期浅层地下水表现为较低的pH值和较高的EC值.（2）研究区枯水期和丰水期浅层地下水重金属含量均低于《地下水质量标准》Ⅲ类标准，枯水期浅层地下水重金属含量均值大小依次为Ni> Zn> V> Cu> Cr> Co> As> Pb> Cd，丰水期浅层地下水重金属含量均值大小依次为V> Ni> Zn> Co> Cu> Cr> Pb> As> Cd.除V、Co和Ni外，其余重金属含量均值在枯水期和丰水期差异不显著.（3）受人类活动影响的Pb、Zn和As等重金属的空间分析结果表明，区内浅层地下水重金属含量较大的区域主要分布在区内东南部以及丹河和沁河交汇处附近，这两个区域土地利用方式主要为蔬菜用地，显示化学肥料对地下水重金属的影响.（4）采用主成分分析方法，提取4个主成分，主成分1包括Cr、Pb、Cd和V，其来源一致，可能与施用磷肥有关等；主成分2包括Ni和Cu，显示成土母质以及复合肥等肥料的混合作用；主成分3包括Co，显示其来自成土母岩；主成分4包括As和Zn，显示锌肥以及有机肥等肥料使用的影响.Abstract: Shallow groundwater of vegetable fields in North Henan Province was sampled during dry and wet season,and the heavy metal concentrations in groundwater were determined by ICP-MS. Spatial distributions of heavy metals in groundwater and principle component analysis were used to analyze the sources of heavy metals. The results demonstrated that the mean pH values of the shallow groundwater during dry season and wet season were 7.26 and 7.15,and the mean EC values were 1200 μS·cm-1 and 1256 μS·cm-1 respectively. The groundwater during wet season had low mean pH values and high mean EC values. The heavy metal concentrations in shallow groundwater in the two seasons did not exceed the "Groundwater Quality Standard" Class Ⅲ standard. Mean heavy metal concentrations decreased in the order of Ni> Zn> V> Cu> Cr> Co> As> Pb> Cd in dry season,and V> Ni> Zn> Co> Cu> Cr> Pb> As> Cd in wet season,respectively. Except for V,Co and Ni, the mean concentrations of other heavy metals had no obvious differences between dry and wet seasons. (3)The spatial distributions of Pb,Zn and As of shallow groundwater in the two seasons demonstrated that groundwater with high heavy metal concentrations mainly distributed in the southeast and west part of studied area which were mainly covered by vegetable fields with high application of fertilizers.Four major components could be extracted through PCA analysis. The first component,including Cr,Pb,Cd and V,might derive from phosphate fertilizer use,and the second component including Ni and Cu may reflect sources from both parent soil and rock and compound fertilizer,and the third one was Co mainly derived from parent soil and rock,and the last one included As and Zn from Zn fertilizer and organic fertilizer.
-
Key words:
- vegetable fields /
- groundwater /
- heavy metals /
- distributions /
- sources analysis /
- North Henan
-
-
[1] WONGSASULUK P,CHOTPANTARAT S,SIRIWONG W,et al. Heavy metal contamination and human health risk assessment in drinking water from shallow groundwater wells in an agricultural area in Ubon Ratchathani province,Thailand[J]. Environmental Geochemistry and Health,2014,36(1): 169-182. [2] CARLSON-LYNCH H,BECK B D,BOARDMAN P D. Arsenic risk assessment[J]. Environmental Health Perspectives,1994,102(4): 354-356. [3] MUSHAK P,CRROCETTI A F. Risk and revisionism in arsenic cancer risk assessment[J]. Environmental Health Perspectives,1995,103(7-8): 684-689. [4] 高继军,张力平,黄圣彪,等.北京市饮用水源水重金属污染物健康风险的初步评价[J]. 环境科学,2004,25(2): 47-50. GAO J J,ZHANG L P,HUANG S B,et al. Preliminary health risk assessment of heavy metals in drinking waters in Beijing[J]. Environmental Science,2004,25(2):47-50 (in Chinese).
[5] 杨彦,于云江,魏伟伟,等.常州市浅层地下水重金属污染对城区,城郊居民健康风险评价[J]. 环境化学,2013,32(2): 202-211. YANG Y,YU Y J,WEI W W,et al. Health risk assessment of heavy metals in shallow groundwater in urban and suburban areas of Changzhou[J]. Environmental Chemistry,2013,32(2): 202-211 (in Chinese).
[6] 王若师,许秋瑾,张娴,等.东江流域典型乡镇饮用水源地重金属污染健康风险评价[J]. 环境科学,2012,33(9): 3083-3088. WANG R S,XU Q J,ZHANG X,et al. Health risk assessment of heavy metals in typical township water sources in Dongjiang River Basin[J]. Environmental Science,2012,33(9): 3083-3088 (in Chinese).
[7] 王铁军,查学芳,熊威娜,等.贵州遵义高坪水源地岩溶地下水重金属污染健康风险初步评价[J]. 环境科学研究,2008,21(1): 46-50. WANG T J,CHA X F,XIONG W N,et al. Primary study of health risk assessment of heavy metals in karst groundwater in Gaoping area in Zunyi City,Guizhou Province[J]. Research of Environmental Sciences,2008,21(1):46-50 (in Chinese).
[8] 张妍,李发东,欧阳竹,等.黄河下游引黄灌区地下水重金属分布及健康风险评估[J]. 环境科学,2013,34(1): 121-128. ZHANG Y,LI F D,OUYANG Z,et al. Distribution and health risk assessment of heavy metals of groundwater in the irrigation distirct of the lower reaches of Yellow River[J]. Enviromnetal Science,2013,34(1): 121-128 (in Chinese).
[9] 丁昊天,袁兴中,曾光明,等.基于模糊化的长株潭地区地下水重金属健康风险评价[J]. 环境科学研究,2009,22(11): 1323-1328. DING H T,YUAN X Z,ZENG G M,et al. Health risk assessment from heavy metals in groundwater of Changsha-Zhuzhou-Xiangtan district base on fuzzy theory[J]. Research of Environmental Sciences,2009,22(11): 1323-1328 (in Chinese).
[10] 张芳,常春平,李静,等.胶东半岛农村地区地下水重金属健康风险评价——以山东省莱阳市为例[J]. 环境科学与技术,2013,36(9): 180-186. ZHANG F,CHANG C P,LI J,et al. Health risk assessment of heavy metals in groundwater in rural area of jiaodong peninsula: A case study in Laiyang City,Shandong Province[J]. Environmental Science & Technology,2013,36(9): 180-186 (in Chinese).
[11] ALLOWAY B J. Sources of heavy metals and metalloids in soils,in heavy metals in soils: Trace metals and metalloids in soils and their bioavailability[M]. Springer Netherlands: Dordrecht,2013:11-50. [12] ATAFAR Z,MESDAGHINIA A,NOURI J,et al. Effect of fertilizer application on soil heavy metal concentration[J]. Environmental Monitoring and Assessment,2010,160(1-4): 83-89. [13] 李德成,李忠佩,周祥,等.不同使用年限蔬菜大棚土壤重金属含量变化[J]. 农村生态环境,2003,19(3): 38-41. LI D C,LI Z P,ZHOU X,et al. Contents of heavy metal elements in soils of vegetable greenhouse different in age[J]. Rural Eco-Environment,2003,19(3): 38-41 (in Chinese).
[14] 曾希柏,李莲芳,梅旭荣.中国蔬菜土壤重金属含量及来源分析[J]. 中国农业科学,2007,40(11): 2507-2517. ZENG X B,LI L,MEI X R. Heavy metal content in soils of Chinese vegetable land and source analysis[J]. Scientia Agricultura Sinica,2007,40(11): 2507-2517 (in Chinese).
[15] 刘海军,李艳,张睿昊,等.北京市集约化种植土壤硝态氮分布和迁移速率研究[J]. 北京师范大学学报: 自然科学版,2013,49(2): 266-270. LIU H J,LI Y,ZHANG R H,et al. Nitrate distribution and movement in soil profile under intensive cropping system in Beijing[J]. Journal of Beijing Normal University (Natural Science),2013,49(2): 266-270 (in Chinese).
[16] 侯晶,陈振楼,许世远,等.大田蔬菜地春季硝态氮淋溶特征研究[J]. 土壤通报,2006,37(4): 691-695. HOU J,CHEN Z L,XU S Y,et al. NO3--N leaching character from vegetable land in springtime[J]. Chinese Journal of Soil Science,2006,37(4): 691-695 (in Chinese).
[17] 蒋辉.河南省博爱县平原区地下水环境质量数字化综合评价[J]. 水文地质工程地质,2004,31(3): 46-50. JIANG H. Integrated digitization evaluation of environmental quality of groundwater in the Bo'ai country plain area in Henan Province[J]. Hydrogeology & Engineering Geology,2004,31(3): 46-50 (in Chinese).
[18] 宋志刚,谢蕾蕾,何旭洪. SPSS16使用教程[M]. 北京:人民邮电出版社,2008. SONG Z G,XIE L L,HE X H. SPSS 16.0 Guide to Data Analysis[M]. Beijing: Posts & Telecom Press,2008 (in Chinese).
[19] 李姗姗,曹广超,石平超,等.青岛城区土壤重金属元素空间分布及其现状评价[J]. 生态与农村环境学报,2015,31(1): 112-117. LI S S,CAO G C,SHI P C,et al. Status quo and evaluation of the spatial distribution of heavy metals in urban soil of Qingdao City[J]. Jounral of Ecology and Rural Environment,2015,31(1): 112-117 (in Chinese).
[20] MICO C,RECATALA L,PERIS M. Assessing heavy metal sources in agricultural soils of an European Mediterranean area by multivariate analysis[J]. Chemosphere,2006,65(5): 863-872. [21] 张东,刘丛强,汪福顺,等.农业活动干扰下地下水无机碳循环过程研究[J]. 中国环境科学,2015,35(11): 3359-3370. ZHANG D,LIU C Q,WANG F S,et al. Inorganic carbon cycling in subsurface environment infulenced by agricultural activities[J]. China Environmental Science,2015,35(11): 3359-3370 (in Chinese).
[22] 王起超,麻壮伟.某些市售化肥的重金属含量水平及环境风险[J]. 农村生态环境,2004,20(2): 62-64. WANG Q C,MA Z W. Heavy metals in chemical fertilizer and environemntal risks[J]. Rural Eco-Environment,2004,20(2): 62-64 (in Chinese).
[23] 咏梅,张漫,王圣伟,等. 山东省滨城区农田土壤重金属来源解析及评价[J]. 中国农业大学学报,2014,19(6): 119-125. YONG M,ZHANG M,WANG S W,et al. Farmland soil heavy metal source analysis and evaluation in Bincheng country of Shandong Province,China[J]. Journal of China Agricultural University,2014,19(6): 119-125 (in Chinese).
[24] MORTVEDT J J. Heavy metal contaminants in inorganic and organic fertilizers[J]. Fertilizer Research,1995,43(1): 55-61. -
