零价铁活化过硫酸钠对偶氮染料4BS的脱色机理

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

唐玉朝, 尹汉雄, 黄健, 凌琪, 李卫华, 张萌. 零价铁活化过硫酸钠对偶氮染料4BS的脱色机理[J]. 环境化学, 2018, 37(5): 1071-1078. doi: 10.7524/j.issn.0254-6108.2017072103
引用本文: 唐玉朝, 尹汉雄, 黄健, 凌琪, 李卫华, 张萌. 零价铁活化过硫酸钠对偶氮染料4BS的脱色机理[J]. 环境化学, 2018, 37(5): 1071-1078. doi: 10.7524/j.issn.0254-6108.2017072103
shu
TANG Yuchao, YIN Hanxiong, HUANG Jian, LING Qi, LI Weihua, ZHANG Meng. Decoloration mechanism of azo dye 4BS by zero valent iron activated sodium persulfate[J]. Environmental Chemistry, 2018, 37(5): 1071-1078. doi: 10.7524/j.issn.0254-6108.2017072103
Citation: TANG Yuchao, YIN Hanxiong, HUANG Jian, LING Qi, LI Weihua, ZHANG Meng. Decoloration mechanism of azo dye 4BS by zero valent iron activated sodium persulfate[J]. Environmental Chemistry, 2018, 37(5): 1071-1078. doi: 10.7524/j.issn.0254-6108.2017072103
shu

零价铁活化过硫酸钠对偶氮染料4BS的脱色机理

  • 1.

    安徽建筑大学, 水污染控制与废水资源化安徽省重点实验室, 合肥, 230601

  • 基金项目:

    国家科技重大专项（2014ZX07405-003），安徽省教育厅自然科学重点项目（KJ2015A109），住建部科学技术项目（2016-K4-077）和大学生创新创业项目资助.

Decoloration mechanism of azo dye 4BS by zero valent iron activated sodium persulfate

  • 1.

    Key Laboratory of Anhui Province of Water Pollution Control and Wastewater Reuse, Anhui Jianzhu University, Hefei, 230601, China

  • Fund Project: Supported by the National Science and Technology Major Projects (2014ZX07405-003), Natural Science Foundation of Anhui Provincial Education Department(KJ2015A109), Ministry of Housing Science and Technology Project(2016-K4-077) and Innovation and Entrepreneurship Project of College Students.

  • 摘要: 以直接耐酸大红4BS为研究对象，利用零价铁（ZVI）活化过硫酸钠（PDS）对其进行脱色研究，考察了PDS浓度、ZVI浓度、pH、温度等对脱色的影响.结果表明，一定浓度的ZVI与PDS联合使用能促进大红4BS的脱色，在20 min时脱色率达98.79%，远高于使用单一药剂的效率，且反应符合准一级反应动力学方程.低pH有利于反应的进行，随着pH值降低，反应速率逐渐加快，在pH=10.42时，反应90 min仅脱色9.41%，而在pH=3.03时脱色率达95.57%.温度的升高虽然能加快大红4BS的脱色，但是会使PDS的利用率降低，当温度由20 ℃增大到60 ℃时，PDS的利用率降低12%，且温度对大红4BS降解速率的影响符合阿伦尼乌斯模型（R2=0.988），计算的活化能为14.44 kJ·mol-1.分别以叔丁醇与异丙醇为分子探针的自由基清除实验显示：ZVI活化PDS降解大红4BS是以SO4-·为主导的自由基反应过程.
    Abstract: Decolorization of direct fast scarlet 4BS by zero-valent iron activated persulfate was investigated in the present paper. The effects of PDS concentration, ZVI concentration, pH, and temperature on the decolorization effiecency were evaluated. The results show that the decolorization rate of 4BS gradually increased with the increase of PDS concentration and ZVI concentration. In a certain concentration range of ZVI and PDS the decolorization of red 4BS was significantly promoted, and the decolorization rate reached 98.79% within 20 min, much higher than the efficiency of any single agent. The pH value had a significant influence on the reaction, and the decolorization ratio were 9.41% and 95.57% at pH 10.42 and 3.03 within 90 min, respectively. Although the temperature accelerated the red 4BS decolorization, but PDS utilization was reduced about 12% when the temperature increased from 20℃ to 60℃. The influence of temperature on the degradation rate of red 4BS was in accordance with the Arrhenius model(R2=0.988), and the calculated activation energy was 14.44 kJ·mol-1. Radical scavenging by tert-butanol and isopropanol as molecular probes show that the degradation of red 4BS by ZVI activated persulfate is a SO4-· dominanted reaction process.
  • 加载中
  • [1] NETA P, HUIE R E, ROSS A B. Rate constants for reactions of inorganic radicals in aqueous solution[J].National Bureau of Stan, 1979, 17(3):1027-1284.
    [2] BUXTON G V, GREENSTOCK C L, HELMAN W P, et al. Critical view of rate constants for reactions of hydrated electrons, hydrogen atoms and hydroxyl radicals (·OH/·O-) in aqueous solution[J]. Journal of Physical Chemical Reference Data,1988,17(2):513-886.
    [3] LUNA J R T, PEREZ R O, POLO M S, et al. Role of HO·and SO4· radicals on the photodegradation of remazol red in aqueous solution[J].Chemical Engineering Journal, 2013, 223:155-163.
    [4] CHEN Y Q, DENG P Y, XIE P C, et al. Heat-activated persulfate oxidation of methyl and ethyl-parabens: Effect, kinetics, and mechanism[J]. Chemosphere, 2016, 11:1-9.
    [5] WU Y L, PRULHO R, BRIGANTE M, et al. Activation of persulfate by Fe(Ⅲ) species: Implications for 4-tert-butylphenol degradation[J]. Journal of Hazardous Materials, 2017, 322:380-386.
    [6] DENG D Y, LIN X T, OU J M, et al. Efficient chemical oxidation of high levels of soil-sorbed phenanthrene by ultrasound induced, thermally activated persulfate[J]. Chemical Engineering Journal, 2015,265: 176-183.
    [7] DAVIDIDOU K, MONTEAGUDO J M, CHATZISYMEON E, et al. Degradation and mineralization of antipyrine by UV-A LED photo-Fenton reaction intensified by ferrioxalate with addition of persulfate[J]. Separation and Purification Technology, 2017, 172:227-235.
    [8] BU L J, SHI Z, ZHOU S Q. Modeling of Fe(Ⅱ)-activated persulfate oxidation using atrazine as a target contaminant[J]. Separation and Purification Technology, 2016,169:59-65.
    [9] 高金龙, 马玉琳, 孟庆来, 等. 二价铁活化过硫酸盐降解土壤中十溴联苯醚[J].环境工程学报, 2016, 10(12): 7339-7343.

    GAO J L, MA Y L, MENG Q L, et al. Degradation of decabromodiphenyl ether in soil by sulfate activated with ferrous ions[J]. Chinese Journal of Environmental Engineering, 2016, 10(12): 7339-7343(in Chinese).

    [10] 于辉, 金春姬, 王鹏远, 等. Fe2+与Fe0活化过二硫酸盐降解活性艳蓝KN-R[J]. 环境科学研究, 2015, 28(1):88-95.

    YU H, JIN C J, WANG P Y, et al. Degradation of reactive brilliant blue KN-R by persulfate activated with Fe2+ and Fe0[J]. Research of Environmental Sciences, 2015, 28(1): 88-95(in Chinese).

    [11] VICENTE F, SANTOS A, ROMERO A, et al. Kinetic study of diuron oxidation and mineralization by persulphate: Effects of temperature, oxidant concentration and iron dosage method[J]. Chemical Engineering Journal, 2011, 170(1): 127-135.
    [12] 杨世迎, 马楠, 王静, 等. 零价铁/过二硫酸盐去除水中硝基苯的还原与氧化机理[J]. 环境化学,2013, 32(11): 2127-2133.

    YANG S Y, MA N, WANG J, et al. Reduction and oxidation reaction mechanism of nitrobenzene removal by zero-valent iron and persulfate[J]. Environmental Chemistry, 2013, 32(11):2127-2133(in Chinese).

    [13] DENG J, SHAO Y, GAO N, et al. Zero-valent iron/persulfate(Fe0/PS) oxidation acetaminophen in water[J]. International Journal of Environmental Science and Technology, 2014, 11(4): 881-890.
    [14] VICENTE F, SANTOS A, ROMERO A, et al. Kinetic study of diuron oxidation and mineralization by persulphate: effects of temperature, oxidant concentration and iron dosage method[J]. Chemical Engineering Journal, 2011, 170(1): 127-135.
    [15] HAYON E, TREININ A, WILF J. Electronic spectra,photochemistry,and autoxidation mechanism of the sulfite-bisulfitepyrosulfite systems SO2-,SO3-,SO4-,and SO5- radicals[J]. Journal of the American Chemical Society, 1972, 94(1): 47-57.
    [16] 尹汉雄, 唐玉朝, 黄显怀, 等. 紫外光强化Fe(Ⅱ)-EDTA活化过硫酸盐降解直接耐酸大红4BS[J].环境科学研究,2017,30(7):1105-1111.

    YIN H X, TANG Y C, HUANG X H, et al.Decolorization effect of direct fast scarlet 4BS by Fe(Ⅱ)-EDTA activated peroxodisulfate under ultraviolet light[J]. Reserrch of Environmental Science, 2017, 30(7):1105-1111(in Chinese).

    [17]
    [18] WEI X Y, Gao N Y, Li C J, et al. Zero-valent iron (ZVI) activation of persulfate (PS) for oxidation of bentazon in water[J]. Chemical Engineering Journal, 2016,285: 660-670.
    [19] ROBERT E H, CAROL L C. Rate constants for hydrogen abstraction reactions of the sulfate radical,SO4- Alkanes and ethers[J]. International Journal of Chemical Kinetics,1989, 21(8): 611-619.
    [20] ZENG J W, HU L L, TAN X Q, et al. Elimination of methyl mercaptan in ZVI-S2O2-8 system activated with in-situ generated ferrous ions from zero valent iron[J]. Catalysis Today, 2016, 281(3): 520-526.
    [21] SONG S,XU L J, HE Z Q, et al.Photocatalytic degradation of C.I.Direct Red 23 in aqueous solutions under UV irradiation using SrTiO3/CeO2 composite as the catalyst[J].Journal of Hazardous Materials, 2008, 152(3): 1301-1308.
    [22] LIANG C J, WANG Z S, BRUELL C J. Influence of pH on persulfate oxidation of TCE at ambient temperatures[J]. Chemosphere. 2007,66(1): 106-113.
    [23] 廖云燕, 刘国强, 赵力, 等. 利用热活化过硫酸盐技术去除阿特拉津[J]. 环境科学学报, 2014, 34(4):931-937.

    LIAO Y Y, LIU G Q, ZHAO L, et al. Removal of atrazine in heat activated persulfate oxidation process[J]. Acta Scientiae Circumstantiae, 2014, 34(4):931-937(in Chinese).

    [24] 金晓英, 李任超, 陈祖亮. 纳米零价铁活化过硫酸钠降解2,4-二氯苯酚[J]. 环境化学, 2014, 33(5): 812-818.

    JIN X Y, LI R C, CHEN Z L. Degradation of 2,4-dichlorophenol by the interaction of nanoscale zero-valent iron with persulfate[J]. Environmental Chemistry, 2014, 33(5): 812-818(in Chinese).

    [25] SU J, LIN S, CHEN Z, et al. Dechlorination of p-chlorophenol from aqueous solution using bentonite supported Fe/Pd nanoparticles: Synthesis, characterization and kinetics[J]. Desalination, 2011, 280(1):167-173.
    [26] 杨世迎, 郑迪, 常书雅, 等. 基于零价铝的氧化/还原技术在水处理中的应用[J]. 化学进展,2016, 28(5): 754-762.

    YANG S Y, ZHENG D, CHANG S Y, et al. Zero valent aluminum based oxidation/reduction technology applied in water treatment[J]. Progress in Chemistry, 2016, 28(5):754-762(in Chinese).

    [27] LIANG C J, SU H. Identification of sulfate and hydroxyl radicals in thermally activated persulfate[J]. Industrial & Engineering Chemistry Research, 2009, 48(11): 5558-5562.
    [28] 邓靖, 冯善方, 马晓雁, 等. 热活化过硫酸盐降解水中卡马西平[J]. 化工学报, 2015, 66(1):410-418.

    DENG J, FENG S F, MA X Y, et al. Degradation of carbamazepine in water by thermally activated persulfate[J]. Ciesc Journal, 2015, 66(1):410-418(in Chinese).

    [29] 林玉满, 朱妍, 陈祖亮. 纳米Ni/Fe双金属去除水溶液中直接耐酸大红4BS的研究[J]. 安全与环境学报,2011, 11(1):51-55.

    LIN Y M, ZHU Y, CHEN Z L. Removal of direct fast scarlet 4BS from aqueous solution with nanoscale Ni/Fe bimetallic particles[J]. Journal of Safety & Environment, 2011, 11(1):51-55(in Chinese).

    [30] 陈郁, 全 燮. 零价铁处理污水的机理及应用[J]. 环境科学研究, 2000, 13(5): 24-26.

    CHEN Y, QUAN X. The mechanism of the treatment of wastewater using zero-valent iron and its application[J]. Research of Environmentalences, 2000, 13(5):24-26(in Chinese).

  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1316
  • HTML全文浏览数:  1266
  • PDF下载数:  430
  • 施引文献:  0
出版历程
  • 收稿日期:  2017-07-21
  • 刊出日期:  2018-05-15
唐玉朝, 尹汉雄, 黄健, 凌琪, 李卫华, 张萌. 零价铁活化过硫酸钠对偶氮染料4BS的脱色机理[J]. 环境化学, 2018, 37(5): 1071-1078. doi: 10.7524/j.issn.0254-6108.2017072103
引用本文: 唐玉朝, 尹汉雄, 黄健, 凌琪, 李卫华, 张萌. 零价铁活化过硫酸钠对偶氮染料4BS的脱色机理[J]. 环境化学, 2018, 37(5): 1071-1078. doi: 10.7524/j.issn.0254-6108.2017072103
shu
TANG Yuchao, YIN Hanxiong, HUANG Jian, LING Qi, LI Weihua, ZHANG Meng. Decoloration mechanism of azo dye 4BS by zero valent iron activated sodium persulfate[J]. Environmental Chemistry, 2018, 37(5): 1071-1078. doi: 10.7524/j.issn.0254-6108.2017072103
Citation: TANG Yuchao, YIN Hanxiong, HUANG Jian, LING Qi, LI Weihua, ZHANG Meng. Decoloration mechanism of azo dye 4BS by zero valent iron activated sodium persulfate[J]. Environmental Chemistry, 2018, 37(5): 1071-1078. doi: 10.7524/j.issn.0254-6108.2017072103
shu

零价铁活化过硫酸钠对偶氮染料4BS的脱色机理

  • 1. 安徽建筑大学, 水污染控制与废水资源化安徽省重点实验室, 合肥, 230601
  • 收稿日期:  2017-07-21
基金项目:

国家科技重大专项（2014ZX07405-003），安徽省教育厅自然科学重点项目（KJ2015A109），住建部科学技术项目（2016-K4-077）和大学生创新创业项目资助.

摘要: 以直接耐酸大红4BS为研究对象，利用零价铁（ZVI）活化过硫酸钠（PDS）对其进行脱色研究，考察了PDS浓度、ZVI浓度、pH、温度等对脱色的影响.结果表明，一定浓度的ZVI与PDS联合使用能促进大红4BS的脱色，在20 min时脱色率达98.79%，远高于使用单一药剂的效率，且反应符合准一级反应动力学方程.低pH有利于反应的进行，随着pH值降低，反应速率逐渐加快，在pH=10.42时，反应90 min仅脱色9.41%，而在pH=3.03时脱色率达95.57%.温度的升高虽然能加快大红4BS的脱色，但是会使PDS的利用率降低，当温度由20 ℃增大到60 ℃时，PDS的利用率降低12%，且温度对大红4BS降解速率的影响符合阿伦尼乌斯模型（R2=0.988），计算的活化能为14.44 kJ·mol-1.分别以叔丁醇与异丙醇为分子探针的自由基清除实验显示：ZVI活化PDS降解大红4BS是以SO4-·为主导的自由基反应过程.
