磺酸基改性磁性吸附剂去除水中的Cu(II)

,

downloadPDF

上一篇

下一篇

王家宏, 雷思莉. 磺酸基改性磁性吸附剂去除水中的Cu(II)[J]. 环境化学, 2019, (8): 1785-1792. doi: 10.7524/j.issn.0254-6108.2018102603
引用本文: 王家宏, 雷思莉. 磺酸基改性磁性吸附剂去除水中的Cu(II)[J]. 环境化学, 2019, (8): 1785-1792. doi: 10.7524/j.issn.0254-6108.2018102603
shu
WANG Jiahong, LEI Sili. Removal of Cu(II) by sulfonic acid modified magnetic adsorbent[J]. Environmental Chemistry, 2019, (8): 1785-1792. doi: 10.7524/j.issn.0254-6108.2018102603
Citation: WANG Jiahong, LEI Sili. Removal of Cu(II) by sulfonic acid modified magnetic adsorbent[J]. Environmental Chemistry, 2019, (8): 1785-1792. doi: 10.7524/j.issn.0254-6108.2018102603
shu

磺酸基改性磁性吸附剂去除水中的Cu(II)

  • 陕西科技大学环境科学与工程学院, 西安, 710021

    • 通讯作者: 王家宏, E-mail: wangjiahong@sust.edu.cn ;
  • 基金项目:

    国家自然科学基金（21677092），陕西省教育厅专项（15JK1095）和陕西省大学生创新创业项目（1315）资助.

Removal of Cu(II) by sulfonic acid modified magnetic adsorbent

  • School of Environmental Science and Engineering, Shaanxi University of Science and Technology, Xi'an, 710021, China

    • Corresponding author: WANG Jiahong, wangjiahong@sust.edu.cn ;
  • Fund Project: Supported by the National Natural Science Foundation of China (21677092), the Scientific Research Program Funded by Shaanxi Provincial Education Department (15JK1095) and Undergraduate Training Program for Innovation and Entrepreneurship of Shaanxi Province(1315).

  • 摘要: 利用水热法制备出Fe3O4磁性粒子，通过正硅酸乙酯水解使Fe3O4外面包覆SiO2（Fe3O4@SiO2），最后利用3-氨丙基三甲氧基硅烷和氯磺酸进行改性，合成了磺酸基改性磁性吸附剂.采用FT-IR、BET和XRD等方法对合成吸附剂进行表征，并探讨接触时间、初始浓度、溶液pH值等因素对吸附性能的影响.表征结果显示，成功合成了磺酸基改性磁性Fe3O4@SiO2粒子；Fe3O4@SO3Na比表面积为20.4587 m-2·g-1.吸附实验结果显示，在25℃条件下，Fe3O4@SO3Na对Cu2+的吸附等温线符合Freundlich吸附等温方程，实验条件下最大吸附量为16.13 mg·g-1.Fe3O4@SO3Na吸附Cu2+可在1 h内达到吸附平衡且吸附动力学遵循拟二级动力学模型.溶液中存在盐离子时，发现盐离子的存在对吸附效果几乎没有影响；溶液中含有柠檬酸时对吸附效果产生抑制.吸附剂经3次循环使用后仍有吸附性能，表明吸附剂具有良好的再生性和经济性.
    Abstract: The Fe3O4 magnetic particles were prepared by hydrothermal method, and its surface coating of SiO2 was by hydrolysis of ethyl orthosilicate. Finally, the sulfonic acid group-modified magnetic adsorbent was synthesized by modification of Fe3O4@SiO2 with 3-aminopropyltrimethoxysilane and chlorosulfonic acid. The magnetic adsorbent was characterized by FT-IR, BET and XRD. The effects of contact time, initial concentration, solution pH and other factors on the adsorption performance were investigated. The characterization results showed that the sulfonic acid-modified magnetic Fe3O4@SiO2 particles were successfully synthesized and the specific surface area of Fe3O4@SO3Na is 20.4587 m-2·g-1. The adsorption experiment results depicted that the Cu2+ adsorption Fe3O4@SO3Na was well fitted by Freundlich adsorption isotherm model. The maximum adsorption capacity under experimental conditions was 16.13 mg·g-1. Adsorption of Cu2+ reached adsorption equilibrium within 1 h and the adsorption kinetics followed a pseudo-second-order kinetic model. When salt ions were present in the solution, it was found that the presence of salt ions had no effect on the adsorption effect. Adsorption of Cu2+ on the adsorbent was inhibited in presence of citric acid. The adsorbent still had good adsorption performance after 3 regenerations which shows recyclability of the system to reduce associated cost.
  • 加载中
  • [1] LI Q Z, CHAI L Y, WANG Q, et a1. Fast esterification of spent grain for enchanced heavy metal ions adsoption[J]. Bioresource Technology, 2010,101(10):3796-3799.
    [2] HUANG J, YE M, CHEN R, et al. Salicylidene Schiff base assembled with mesoporous silica SBA-15 for Cu(Ⅱ) removal in aqueous media[J]. Advanced Materials Research, 2011, 356-360(1):373-381.
    [3] 鞠峰, 胡勇有, 程建华,等. 铁屑内电解法处理EDTA溶液中络合铜离子[J]. 环境科学学报, 2011, 31(5):897-904.

    JU F, HU Y Y, CHENG J H, et al.Treatment of chelated copper in EDTA solution by iron chip inner-electrolysis[J]. Journal of Environmental Science,2011, 31(5):897-904(in Chinese).

    [4] 吴亚琪, 徐畅, 赵越,等. 硅酸钙-壳聚糖聚合物制备及其对重金属废水的吸附特性[J]. 环境化学,2016,35(3):562-567.

    WU Y Q, XU C, ZHAO Y, et al.Preparation of calcium silicate chitosan polymer and the adsorptive removal of heavy metals in wastewater[J]. Environmental Chemistry,2016,35(3):562-567.

    [5] KONG A, JI Y, MA H, et al. A novel route for the removal of Cu(Ⅱ) and Ni(Ⅱ) ions via homogeneous adsorption by chitosan solution[J]. Journal of Cleaner Production, 2018,192(1):801-808.
    [6] KRSTIC V, UROSEVOC T, Pesovski B, et al. A review on adsorbents for treatment of water and wastewaters containing copper ions[J].Chemical Engineering Science, 2018,192:273-287.
    [7] ZHOU Q, LIAO B, LIN L, et al. Adsorption of Cu(Ⅱ) and Cd(Ⅱ) from aqueous solutions by ferromanganese binary oxide-biochar composites.[J]. Science of the Total Environment, 2017, 615(1):115-122.
    [8] LIU X, ZHONG Z, TANG Y, et al. Review on the synthesis and applications of Fe3O4 nanomaterials[J]. Journal of Nanomaterials, 2013, 2013(33):209-214.
    [9] WANG J, BI L, JI Y, et al. Removal of humic acid from aqueous solution by magnetically separable polyaniline:Adsorption behavior and mechanism[J]. Journal of Colloid and Interface Science, 2014, 430:140-146.
    [10] CHEN K, HE J, LI Y, et al. Removal of cadmium and lead ions from water by sulfonated magnetic nanoparticle adsorbents[J]. Journal of Colloid and Interface Science,2017, 494(1):307-316.
    [11] DONG C, ZHANG F, PANG Z, et al. Efficient and selective adsorption of multi-metal ions using sulfonated cellulose as adsorbent[J]. Carbohydrate Polymers, 2016, 151(1):230-236.
    [12] AZARIFAR D, BADALKHANI O, Abbasi Y, et al. Silica-modified magnetite Fe3O4 nanoparticles grafted with sulfamic acid functional groups[J].Sulfur Reports,2016, 37(6):656-673.
    [13] KIASAT A R, DAVARPANAH J. Fe3O4@Silica sulfuric acid core-shell composite as a novel nanomagnetic solid acid:Synthesis, characterization and application as an efficient and reusable catalyst for one-pot synthesis of 3,4-dihydropyrimidinones/thiones under solvent-free conditions[J]. Research on Chemical Intermediates, 2015, 41(5):2991-3001.
    [14] KISTER O, ROESSNER F. Synthesis and characterization of mesoporous and amorphous silica modified with silica organo sulfogroups[J].Journal of Porous Materials, 2012, 19(1):119-131.
    [15] HASANZADEH R, MOGHADAM P N, BAHRI N, et al. sulfonated magnetic nanocomposite base on reactive PGMA-MAn copolymer@Fe3O4 nanoparticles:Effective removal of Cu(Ⅱ) ions from aqueous solutions[J].International Journal of Ploymer Science,2016,2016(1):1-15.
    [16] PATHAK S, DEBNATH K, MOLLICK M M R, et al. Facile cyclization in the synthesis of highly fused diaza cyclooctanoid compounds using retrievable nano magnetite-supported sulfonic acid catalyst[J]. Rsc. Advances, 2014, 4(45):23779-23789.
    [17] QU Q, GU Q, GU Z, et al. Efficient removal of heavy metal from aqueous solution by sulfonic acid functionalized nonporous silica microspheres[J]. Colloids & Surfaces A Physicochemical & Engineering Aspects, 2012, 415(48):41-46.
    [18] AKHAVAN B, JARVIS K, MAJEWSKI P. Plasma polymer-functionalized silica particles for heavy metals removal[J]. ACS Applied Materials & Interfaces, 2015, 7(7):4265-4274.
