接枝插层合成木质素基水凝胶的制备因素解析

,  ,  ,  ,

downloadPDF

上一篇

下一篇

王莹, 王星敏, 熊杰, 吴四维, 冉祝. 接枝插层合成木质素基水凝胶的制备因素解析[J]. 环境化学, 2020, (8): 2217-2226. doi: 10.7524/j.issn.0254-6108.2019051902
引用本文: 王莹, 王星敏, 熊杰, 吴四维, 冉祝. 接枝插层合成木质素基水凝胶的制备因素解析[J]. 环境化学, 2020, (8): 2217-2226. doi: 10.7524/j.issn.0254-6108.2019051902
shu
WANG Ying, WANG Xingmin, XIONG Jie, WU Siwei, RAN Zhu. Analysis of preparation factors of lignin-based hydrogels synthesized by graft-intercalation[J]. Environmental Chemistry, 2020, (8): 2217-2226. doi: 10.7524/j.issn.0254-6108.2019051902
Citation: WANG Ying, WANG Xingmin, XIONG Jie, WU Siwei, RAN Zhu. Analysis of preparation factors of lignin-based hydrogels synthesized by graft-intercalation[J]. Environmental Chemistry, 2020, (8): 2217-2226. doi: 10.7524/j.issn.0254-6108.2019051902
shu

接枝插层合成木质素基水凝胶的制备因素解析

  • 1. 重庆工商大学环境与资源学院, 重庆, 400067;

  • 2. 催化与环境新材料重庆市重点实验室, 重庆, 400067

    • 通讯作者: 王星敏, E-mail: wang_chem@tom.com ;
  • 基金项目:

    重庆市科委应用开发重点项目（cstc2017shms-zdyfX0063）和重庆市研究生科研创新项目（CYS18319）资助.

Analysis of preparation factors of lignin-based hydrogels synthesized by graft-intercalation

  • 1. College of Environment and Resources, Chongqing Technology and Business University, Chongqing, 400067, China;

  • 2. Chongqing Key Lab of Catalysis & Functional Organic Molecules, Chongqing, 400067, China

    • Corresponding author: WANG Xingmin, wang_chem@tom.com ;
  • Fund Project: Supported by Key Projects of Application and Development of Chongqing Science and Technology Commission(cstc2017shms-zdyfX0063) and Chongqing Graduate Research and Innovation Project(CYS18319).

  • 摘要: 以桑枝木质素提取物、丙烯酸为单体，以N，N'-亚甲基双丙烯酰胺为交联剂，以柠檬酸改性蒙脱土为插层剂，以（NH4）S2O8为引发剂，采用接枝插层制备木质素基水凝胶.利用均匀设计法优化获得适宜的组分配伍并解析组分间交互作用，通过SEM和FTIR分析技术表征制备水凝胶物相结构，探讨制备水凝胶对Mn2+、Zn2+、Pb2+的吸附性能.结果表明，当N，N'-亚甲基双丙烯酰胺质量为3.9730 g、木质素质量为0.7000 g、蒙脱土质量为0.1470 g时，制备水凝胶呈较规整蜂窝状多孔结构，且表面具有-OH、CO、N-H等官能团；制备水凝胶表面功能基团和空间构型对其吸附性能影响显著；吸水120 min溶胀率达60%，自然风干70 h保水率达20%；处理初始质量浓度分别为320、160、1000 mg·L-1的Mn2+、Zn2+、Pb2+溶液720 min，吸附量各达77.09、73.95、383.90 mg·g-1，表现出对金属离子良好的吸附性能.
    Abstract: Using mulberry branch lignin extract、acrylic acid as monomers, N,N'-methylene bisacrylamide as cross-linker, citric acid modified montmorillonite as intercalator and ammonium persulphate as initiator, making lignin-based hydrogels through graft polymerization method. Uniform design method was used to optimize the distribution of components and analyzed the interaction between components, the phase structure of the hydrogels was characterized by SEM and FTIR, and the adsorption performance of prepared hydrogels on Mn2+, Zn2+ and Pb2+ were investigated. The results showed that:When the raw materials were composed of 3.9730 g N,N'-methylene bisacrylamide, 0.7000 g lignin and 0.1470 g montmorillonite, there was regular honeycomb-like porous structure with -OH, C O, N-H functional groups on its surface. The surface functional groups and spatial configuration of prepared hydrogels significantly affected its adsorption properties. The swelling rate reached 60% within 120 minutes, besides after 70 hours of natural drying, the water retention rate reached 20%;The Mn2+, Zn2+, and Pb2+ solutions with initial mass concentrations of 320, 160, and 1000 mg·L-1 were treated for 720 min, and the adsorption capacities were 77.09, 73.95, and 383.90 mg·g-1, respectively, and the hydrogels showed great adsorption performance for metal ions.
  • 加载中
  • [1] 关莹, 陈阁谷, 张冰, 等. 农林生物质材料基水凝胶的研究进展[J]. 林产化学与工业, 2015, 35(2):171-178.

    GUAN Y,CHENG G G,ZHANG B et al. Research progress in agricultural and forestal biomass-basesd hydrogel[J]. Chemistry and Industry of Forest Products, 2015, 35(2):171-178(in Chinese).

    [2] 曹春, 巨天珍, 陈兴鹏. CMC/P(AMPS-co-AA)水凝胶对Pb(Ⅱ)的吸附动力学及吸附机理研究[J]. 环境化学, 2013,22(10):1909-1916.

    CAO C, JU T Z, CHEN X P. Adsorption kinetics and mechanism of Pb(Ⅱ) ion by CMC/P(AMPS-co-AA) hydrogel[J]. Environmental Chemistry, 2013,22(10):1909-1916(in Chinese).

    [3] 孙凤玲, 王吟. 天然生物质水凝胶吸附材料研究进展[J]. 材料导报, 2016, 30(9):137-143.

    SUN F L, WANG Y. A Review about hydrogel adsorbents produced from natural biomass[J]. Materials Reports, 2016, 30(9):137-143(in Chinese).

    [4] 向育君. 改性木质素磺酸钠水凝胶的制备和应用研究[D].长沙:湖南大学, 2013. XIANG Y J. Study on preparation and application of modified sodium lignosulfonate hydrogel[D]. Changsha:Hunan University, 2013(in Chinese).
    [5] GUO X, ZHANG S, SHAN X Q. Adsorption of metal ions on lignin.[J]. Journal of Hazardous Materials, 2008, 151(1):134-142.
    [6] 黎新明, 尹国强, 崔英德. 基于半纤维素和木质素的水凝胶研究进展[J]. 化工新型材料, 2011, 39(9):21-25.

    LI X M,YIN GQ,CUI Y D. Progress of hydrogels based on hemicellulose and lignin[J]. New Chemical Materials, 2011, 39(9):21-25(in Chinese).

    [7] HE X. Preparation of super-absorbents composites from kaolin/sodium lignosulfonate-g-AA-AM[J]. Scientia Silvae Sinicae, 2011, 47(8):134-138.
    [8] LIANG F B, SONG Y L, HUANG C P, et al. Synthesis of novel lignin-based ion-exchange resin and its utilization in heavy metals removal[J]. Industrial & Engineering Chemistry Research, 2013, 52(3):1267-1274.
    [9] DEMIRBAS A. Adsorption of lead and cadmium ions in aqueous solutions onto modified lignin from alkali glycerol delignication[J]. Journal of Hazardous Materials, 2004, 109(1):221-226.
    [10] 徐继红, 穆新科, 洪思明,等. 木质素基水凝胶对亚甲基蓝染料的吸附性能[J]. 环境工程学报, 2015, 9(10):4877-4882.

    XU J H, MU X K, HONG S M et al. Adsorption performance of methylene blue dye by lignin-based hydrogel[J]. Chinese Journal of Environmental Engineering, 2015, 9(10):4877-4882(in Chinese).

    [11] 冯清华. 含木质素水凝胶的合成及其性能研究[D].广州:华南理工大学, 2012. FENG Q H. Synthseis and properties of lignin-containing hydrogels[D]. Guangzhou:South China University of Technology, 2012(in Chinese).
    [12] 曹秀格, 倪棠棣. 高效交联剂N,N'-亚甲基双丙烯酰胺的合成[J]. 化学工业与工程, 1999, 16(6):365-366.

    CAO X G, NI T D. Synthesis of highly efficient crosslinking N, N'-methylene bisacrylamide[J]. Chemical Industry and Engineering, 1999, 16(6):365-366(in Chinese).

    [13] 邓连霞. 丝胶蛋白基复合吸水材料的研制及结构性能表征[D].杭州:浙江大学, 2013. DENG L X. Preparation and characterization of sericin-based superabsorbent composite materials[D]. Hangzhou:Zhejiang University, 2013. (in Chinese).
    [14] 史艳茹, 薛振华, 王喜明,等. 木质纤维素-g-丙烯酸/蒙脱土水凝胶制备及吸附性能研究[J]. 功能材料, 2013, 44(4):502-506.

    SHI Y R, XUE Z H, WANG X M, et al. Preparation of lignocellulose-g-acrylic acid/montmorillonite hydrogels and its adsorption[J]. Functional Materials, 2013, 44(4):502-506(in Chinese).

    [15] 张明月. 农作物生物质基复合水凝胶的合成及对重金属离子吸附性能研究[D].长春:吉林大学, 2017. ZHANG M Y. Synthesis of crop biomass-based hydrogels and their adsorption properties for heavy metal ions[D]. Changchun,Jilin University, 2017(in Chinese).
    [16] 郭丹峰. 淀粉-丙烯酸-丙烯酰胺复合高吸水树脂的制备与性能[D].长沙:中南大学, 2014. GUO D F. Synthesis and capacity of super absorbent polymer of starch compositing AA and AM[D]. Changsha:Central South University, 2014(in Chinese).
    [17] RASCHIP I E, VASILE C, CIOLACU D, et al. Semi-interpenetrating polymer networks containing polysaccharides. I Xanthan/lignin networks[J]. High Performance Polymers, 2007, 19(5/6):603-620.
    [18] YOON K, SUNG H, HWANG Y, et al. Modification of montmorillonite with oligomeric amine derivatives for polymer nanocomposite preparation[J]. Applied Clay Science, 2007, 38(1):1-8.
    [19]
    [20] RASHIDZADEH A, OLAD A, SALARI D, et al. On the preparation and swelling properties of hydrogel nanocomposite based on sodium alginate-g-poly (acrylic acid-co-acrylamide)/clinoptilolite and its application as slow release fertilizer[J]. Journal of Polymer Research, 2014, 21(2):344-2935.
    [21] 吕文华. 木材/蒙脱土纳米插层复合材料的制备[D]. 北京:北京林业大学, 2004. LU W H. Preparation of wood/montmorillonite(MMT) intercalated nanocomposite[D]. Beijing:Beijing Forestry University, 2004(in Chinese).
    [22] 李萌. 阳离子型木质素基水凝胶的制备及其在废水处理中的应用[D].济南:齐鲁工业大学, 2016. LI M. Preparation of cationic lignin-based hydrogels and its application in wastewater treatment[D]. Jinan:Qilu University of Technology 2016(in Chinese).
    [23] 孙亚杰, 马艳丽, 代俊秀,等. 酶解木质素接枝聚丙烯酸多孔水凝胶的制备及表征[J]. 北京林业大学学报, 2016, 38(11):97-103.

    SUN Y J, MA Y L, DAI J X, et al. Preparation and characterization of enzymatic hydrolysis lignin-based hydrogel[J]. Journal of Beijing Forestry University, 2016, 38(11):97-103(in Chinese).
