高效液相色谱分析四溴双酚A标准样品方法优化及应用

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

黄林艳, 鲁炳闻, 赵彦辉, 赵亚娴, 陈星羽, 房丽萍. 高效液相色谱分析四溴双酚A标准样品方法优化及应用[J]. 环境化学, 2020, (12): 3524-3530. doi: 10.7524/j.issn.0254-6108.2019082203
引用本文: 黄林艳, 鲁炳闻, 赵彦辉, 赵亚娴, 陈星羽, 房丽萍. 高效液相色谱分析四溴双酚A标准样品方法优化及应用[J]. 环境化学, 2020, (12): 3524-3530. doi: 10.7524/j.issn.0254-6108.2019082203
shu
HUANG Linyan, LU Bingwen, ZHAO Yanhui, ZHAO Yaxian, CHEN Xingyu, FANG Liping. Optimization and application of HPLC method for tetrabromobisphenol A reference material analysis[J]. Environmental Chemistry, 2020, (12): 3524-3530. doi: 10.7524/j.issn.0254-6108.2019082203
Citation: HUANG Linyan, LU Bingwen, ZHAO Yanhui, ZHAO Yaxian, CHEN Xingyu, FANG Liping. Optimization and application of HPLC method for tetrabromobisphenol A reference material analysis[J]. Environmental Chemistry, 2020, (12): 3524-3530. doi: 10.7524/j.issn.0254-6108.2019082203
shu

高效液相色谱分析四溴双酚A标准样品方法优化及应用

  • 国家环境保护污染物计量与标准样品研究重点实验室, 生态环境部环境发展中心环境标准样品研究所, 北京, 100029

    • 通讯作者: 房丽萍, E-mail: fang.liping@ierm.com.cn
  • 基金项目:

    环境发展中心立项科技项目（ZZ-2016-08）资助.

Optimization and application of HPLC method for tetrabromobisphenol A reference material analysis

  • State Environmental Protection Key Laboratory of Environmental Pollutant Metrology and Reference Materials, Institute for Environmental Reference Materials, Environmental Development Centre of the Ministry of Ecology and Environment, Beijing, 100029, China

    • Corresponding author: FANG Liping, fang.liping@ierm.com.cn
  • Fund Project: Supported by the Science and Technology Project of Environmental Development Center (ZZ-2016-08).

  • 摘要: 本文通过优化液相色谱柱、流动相和波长等条件，建立了高效液相色谱分析甲醇中四溴双酚A（TBBPA）标准样品的方法.结果表明，固定相为氰基的色谱柱，在80%乙腈+20%的0.1%氨水的流动相和212 nm波长条件下，TBBPA能获得峰型最好、响应最高的色谱峰.建立的高效液相色谱分析方法，在5.0—50 μg·mL-1浓度范围内，线性和精密度均良好，检出限为0.69 μg·mL-1，满足甲醇中TBBPA标准样品分析要求.将优化的仪器分析方法用于甲醇中TBBPA标准样品的均匀性检验和稳定性研究中，结果表明，研制的甲醇中TBBPA标准样品满足均匀性要求，且在17个月内室温和4℃冷藏条件均能稳定保存.本研究建立的高效液相色谱法也可用于其他TBBPA相关样品的分析中.
    Abstract: In this paper, a high performance liquid chromatography (HPLC) method for the determination of tetrabromobisphenol A (TBBPA) reference material (RM) in methanol was established by optimizing the kind of column, the condition of mobile phase and wavelength. The results showed that TBBPA exhibited the best peak type and the highest response under the following condition: mobile phase of 80% acetonitrile +20% 0.1% ammonia, and the wavelength of 212 nm. The established HPLC method had good linearity and precision within the concentration range of 5.0—50 μg·mL-1, and the detection limit was 0.69 μg·mL-1, which met the analysis requirements of TBBPA RM in methanol. The optimized method was used to test the homogeneity and stability of TBBPA RM in methanol. The results showed that the developed TBBPA RM was homogeneous and could be stored stably both at room temperature and 4 ℃ for 17 months. The established HPLC method in this study could also be used in the analysis of other TBBPA samples.
  • 加载中
  • [1] LIU K, LI J, YAN S J, et al. A review of status of tetrabromobisphenol A (TBBPA) in China[J]. Chemosphere, 2016, 148:8-20.
    [2] 孙国新, 王杰琼, 周成智, 等. 四溴双酚A在近岸海水中的光降解动力学研究[J]. 环境化学, 2018, 37(8):8-15.

    SUN G X, WANG J Q, ZHOU C Z, et al. Photodegradation kinetics of tetrabromobisphenol A in coastal water[J]. Environmental Chemistry, 2018, 37(8):8-15(in Chinese).

    [3] 夏炎, 韩伟立, 马安德. 广东省农耕土壤中四溴双酚A与六溴环十二烷的含量调查及其蓄积水平估算[J]. 环境化学, 2017, 36(6):1328-1334.

    XIA Y, HAN W L, MA A D. Contents, distribution and composition of tetrabromobisphenol A and hexabromocyclododecane in agricultural soils of Guangdong[J]. Environmental Chemistry, 2017, 36(6):1328-1334(in Chinese).

    [4] BOAS M, FELDT-RASMUSSEN U, MAIN K M. Thyroid effects of endocrine disrupting chemicals[J]. Molecular & Cellular Endocrinology, 2012, 355(2):240-248.
    [5] COVACI A, VOORSPOELS S, ABDALLAH M A E, et al. Analytical and environmental aspects of the flame retardant tetrabromobisphenol-A and its derivatives[J]. Journal of Chromatography A, 2009, 1216(3):346-363.
    [6] 刘红玲, 刘晓华, 王晓祎, 等. 双酚A和四溴双酚A对大型溞和斑马鱼的毒性[J]. 环境科学, 2007, 28(8):1784-1787.

    LIU H L, LIU X H, WANG X W, et al. Toxicity of BPA and TBBPA to Daphnia magna and Zebrafish Brachydanio rerio[J]. Environmental Scinece, 2007, 28(8):1784-1787(in Chinese).

    [7] 孙翠香, 田宇, 谢倩, 等. 气相色谱/质谱测定电子垃圾拆解区土壤中四溴双酚A的方法[J]. 生态环境学报, 2013, 22(10):1717-1720.

    SUN C X, TIAN Y, XIE Q, et al. Determination of tetrabromobisphenol-A in the electronic waste area soil by gas chromatography-mass spectrometry[J]. Ecology and Environmental Sciences, 2013, 22(10):1717-1720(in Chinese).

    [8] YANG S W, WANG S R, LIU H L, et al. Tetrabromobisphenol A:Tissue distribution in fish, and seasonal variation in water and sediment of Lake Chaohu, China[J]. Environmental Science & Pollution Research International, 2012, 19(9):4090-4096.
    [9] NI H G, ZENG H. HBCD and TBBPA in particulate phase of indoor air in Shenzhen, China[J]. Science of the Total Environment, 2013, 458/460(3):15-19.
    [10] XIE Z, EBINGHAUS R, LOHMANN R, et al. Trace determination of the flame retardant tetrabromobisphenol A in the atmosphere by gas chromatography-mass spectrometry[J]. Analytica Chimica Acta, 2007, 584(2):333-342.
    [11] 丁洁, 张圣虎, 刘济宁, 等. 液相色谱-串联质谱法测定污水处理厂水样中双酚A、四溴双酚A及烷基酚类化合物[J]. 色谱, 2014, 32(5):529-534.

    DING J, ZHANG S H, LIU J N, et al. Determination of bisphenol A, tetrabromobisphenol A and Alkylphenols in water samples of sewage treatment plant Using liquid chromatography and analytical methods[J]. Chinese Jouranl of Chromatography, 2014, 32(5):529-534(in Chinese).

    [12] INTHAVONG C, HOMMET F, BORDET F, et al. Simultaneous liquid chromatography tandem mass spectrometry analysis of brominated flame retardants (tetrabromobisphenol A and hexabromocyclododecane diastereoisomers) in French breast milk[J]. Chemosphere, 2017, 186:762-769.
    [13] KANG H, WANG X, ZHANG Y, et al. Simultaneous extraction of bisphenol A and tetrabromobisphenol A from milk by microwave-assisted ionic liquid microextraction[J]. Rsc Advances, 2015, 5(19):14631-14636.
    [14] 王小红, 董社英, 张帅鹏, 等. 超声辅助-分散液相微萃取/高效液相色谱法测定沉积物中双酚A及其衍生物[J]. 分析试验室, 2015, 34(8):878-881.

    WANG X H, DONG S Y, ZHANG S P, et al. Rapid determination of Bisphenol A and its main derivatives in sediment using ultrasound-dispersive liquid-liquid microextraction combined with HPLC[J]. Chinese Journal of Analysis Laboratory, 2015, 34(8):878-881(in Chinese).

    [15] 毛丽, 余益军, 孙兆海, 等. 四溴双酚A的水溶性与辛醇/水分配系数及其影响因素初探[J]. 环境化学, 2010, 29(4):583-587.

    MAO L, YU Y J, SUN Z H, et al. Water solubility and octanol/water partition behavior of tetrabromobisphenol A[J]. Environmental Chemistry, 2010, 29(4):583-587(in Chinese).

    [16] 国家质量监督检验检疫总局. 标准样品工作导则(3)标准样品定值的一般原则和统计方法:GB/T 15000.3-2008/ISO guide 35[S]. 北京:中国标准出版社, 2008. National Quality Supervision and Inspection and Quarantine. Directives for the work of reference materials(3)-Reference materials-General and statistical principles for certification:GB/T 15000.3

    -2008/ISO guide 35[S]. Beijing:Chinese Specification Press, 2008(in Chinese).

    [17] 环境保护部. 环境标准样品研复制技术规范:HJ/T 173-2017[S]. 北京:中国环境出版社, 2017. Ministry of Environmental Protection. Technical specifications for development of environmental reference materials:HJ/T 173-2017[S]. Beijing:China Environment Press, 2017

    (in Chinese).
