深圳市2010-2017年降水中化学组分特征及来源解析
Chemical compositions and sources of precipitation in Shenzhen from 2010 to 2017
-
摘要: 为研究深圳市大气降水中化学组分特征及来源，对2010-2017年降水中主要离子浓度及来源进行分析，结果表明，8年间降水雨量加权pH年均值为5.01，雨量加权平均电导率年均值为14.19 μS·cm-1，酸雨频次年均占比为53.18%.降水中含量最高的阴离子SO42-、阳离子NH4+雨量加权平均当量浓度分别为27.82 μeq·L-1及25.63 μeq·L-1，主要离子及占比高低依次为SO42-、NH4+、NO3-、Cl-、Ca2+、Na+及H+，8年占比均值高达94.34%.中和降水中酸性组分的主要碱性离子为连续8年占比最高且稳中上升的NH4+，引起酸雨且前体化合物NOx含量逐年增大的致酸离子NO3-占比也逐年增大，为硫酸-硝酸混合型降水.降水中Na+、Cl-及Mg2+主要为海洋输入，轻度富集的Ca2+受地壳来源如建筑扬尘、土壤尘影响大，有相同释放源且中度富集的SO42-及高度富集的NO3-受人类活动如工业废气释放、机动车燃料排放及焚烧释放等影响大.降水中NO3-与NH4+及Ca2+、SO42-与NH4+、Ca2+及K+相关性明显，表明深圳市大气中存在NH4NO3、Ca（NO3）2、（NH4）2SO4、CaSO4及K2SO4等5种物质，而NH4+与SO42-、NO3-相关性更强，表明大气降水中（NH4）2SO4及NH4NO3占主导，揭示中和降水中酸性物质为NH3的概率最大.Abstract: To investigate the characteristics and sources of chemical compositions of precipitation in Shenzhen, the concentration and sources of major ions were analyzed in the precipitation collected during the period from 2010 to 2017. The results showed that rainfall volume weighted mean pH was 5.01, rainfall volume weighted mean conductivity was 14.19 μS·cm-1 and the frequency of acid rain was 53.18%. The rainfall volume weighted mean values of concentration for the highest contents of anion SO42- was 27.82 μeq·L-1, and that of cation NO3- was 25.63 μeq·L-1. And main ions and contributions in precipitation during eight years were SO42- > NO3- > Cl- > Ca2+> NH4+ > Na+ > H+, accounting for 94.34% of total ions concentration. And the ratio for NO3- as acid-causing ion had also an increasing trend due to the increased content of precursor compound NOx year by year, which was mixed with sulfuric acid and nitric acid in Shenzhen. Na+, Cl- and Mg2+ mainly derived from ocean input, slightly enriched Ca2+ was strongly affected by crustal sources such as building dust and soil dust, and moderately enriched SO42- and highly enriched NO3- primarily came from the emission by human activities such as industrial exhaust emissions, vehicle release and incineration release and so on. Good correlations between NO3-, NH4+ and Ca2+ as well as between SO42-, NH4+, Ca2+ and K+ were observed, which implied that NH4NO3, Ca(NO3)2, (NH4)2SO4, K2SO4 and CaSO4 all existed in atmosphere. Stronger correlations of NH4+ with SO42- and NO3- were observed, which indicated (NH4)2SO4 and NH4NO3 were the dominant components in the precipitates, and NH3 was the most proboble chemical to neutralize acidic substances.
-
Key words:
- Shenzhen /
- precipitation /
- chemical composition /
- sources apportionment
-
-
[1] GORHAN E. Acid deposition and its ecological effects:a brief history of research[J]. Environmental Science & Policy, 1998, 1:153-166. [2] 张俊平, 张新明, 曾纯军, 等. 酸雨对生态系统酸化影响的研究进展[J]. 农业环境科学学报, 2010, 29(Z1):245-249. ZHANG J P, ZHANG X M, ZENG C J, et al. Studying advances of effects of acid rain on acidifying of ecosystem[J]. Journal of Agricultural Environmental Science, 2010, 29(Z1):245-249(in Chinese).
[3] ANATOLAKI C, TSITOURIDOU R. Relationship between acidity and ionic composition of wet precipitation. A two years study at an urban site, Thessaloniki, Greece[J]. Atmospheric Research, 2009, 92(1):100-113. [4] 赵艳霞, 侯青, 徐晓斌, 等. 2005年中国酸雨时空分布特征[J]. 气候变化研究进展, 2006, 5(2):242-245. ZHAO Y X, HOU Q, XU X B, et al. Spatial and temporal distribution characteristics of acid rain in China in 2005[J]. Progress in Climate Change Research, 2006, 5(2):242-245(in Chinese).
[5] BASAK B, ALAGHA O. The chemical composition of rainwater over Buyukcekmece Lake, Istanbul[J]. Atmospheric Research, 2004, 71, 275-288. [6] ZUNCKEL M, SAIZAR C, ZARAU J. Rainwater composition in Northeast Uruguay[J]. Atmospheric Environment, 2003, 37, 1601-1611. [7] LARSSEN T E, LYDERSEN D, TANG Y, et al. Acid rain in China[J]. Environmental Science Technology, 2006, 40:418-425. [8] DAS N, DAS R, CHAUDHURY, G R. Chemical composition of precipitation at background level[J]. Atmospheric Research, 2010, 95:108-113. [9] ALI K, MOMIN G A, TIWARI S, et al. Fog and precipitation chemistry at Delhi, North India[J]. Atmospheric Environment, 2004, 38, 4215-4222. [10] 黄奕龙, 王仰麟, 张利萍, 等. 深圳市大气降水化学组成演化特征分析:1980-2004年[J]. 生态环境, 2008, 17(1):147-152. HUANG Y L, WANG Y L, ZHANG L P, et al. Chemical composition characteristic of atmospheric precipitation in Shenzhen from 1980 to 2004[J]. Ecology and Environment, 2008, 17(1):147-152(in Chinese).
[11] 牛彧文, 何凌燕, 胡敏. 深圳大气降水的化学组成特征[J]. 环境科学, 2008, 29(4):1014-1019. NIUY W, HE L Y, HU M. Chemical Characteristics of Atmospheric Precipitation in Shenzhen[J]. Environmental Science, 2008, 29(4):1014-1019(in Chinese).
[12] 霍铭群, 孙倩, 谢鹏, 等. 大气颗粒物和降水化学特征的相互关系[J]. 环境科学, 2009, 30(11):3159-3166. HUO M Q, SUN Q, XIE P, et al. Relationship between atmospheric particles and rain water chemistry character[J]. Environmental Science, 2009, 30(11):3159-3166(in Chinese).
[13] 颜敏, 喻本德, 郑卓云, 等. 深圳市酸雨变化特征及形成原因分析[J]. 生态环境学报, 2013, 22(11):1814-1818. YAN M, YU B D, ZHENG Z Y, et al. Variation characteristics and causes analysis of acid rain in Shenzhen city[J]. Ecology and Environmental Sciences, 2013, 22(11):1814-1818(in Chinese).
[14] 陈军苗. 深圳市近年来酸性降水特征及其成因分析研究[J]. 环境科技与管理, 2014, 39(8):53-56. CHEN J M. Analysis on characteristics and causes of acidic precipitation in Shenzhen in recent years[J]. Environmental Technology and Management, 2014, 39(8):53-56(in Chinese).
[15] 国家环境保护局. 大气降水中氟、氯、亚硝酸盐、硝酸盐、硫酸盐的测定离子色谱法:GB/T 13580.5[S]. 北京:中国标准出版社, 1992:3. State Bureau of Environmental Protection. Determination of fluorine, chlorine, nitrite, nitrate and sulphate in meteoric water by Ion Chromatography:GB/T 13580.5[S]. Beijing:China Standard Press, 1992 :3(in Chinese).
[16] 中华人民共和国卫生部, 中国国家标准化管理委员会. 生活饮用水标准检验方法金属指标电感耦合等离子体发射光谱法:GB/T 5750.6[S]. 北京:中国标准出版社, 2006:5-7. Ministry of Health of the People's Republic of China, China National Standardization Management Committee. Standard Test methods for drinking water-metal indicators ICP emission spectrometry:GB/T 5750.6 [S]. Beijing:China Standard Press, 2006:5-7(in Chinese).
[17] 国家环境保护局. 大气降水中铵盐的测定:GB/T 13580.11[S]. 北京:中国标准出版社, 1992:61-62. State Bureau of Environmental Protection. Determination of ammonium in the wet precipitation:GB/T 13580.11 [S]. Beijing:China Standard Press,1992:61-62(in Chinese).
[18] AYER G P. Some practical aspects of acid deposition measurements:Presentation to the 3rd Expert Meeting on Acid Deposition Monitoring Network in East Asia[R]. Japan:Niigata Prefecture, 1995. [19] 张俊平, 胡月明, 王长委, 等. 深圳市酸雨特征及其成因分析[J]. 水土保持学报, 2007, 29(4):1014-1019. ZHANG J P, HU Y M, WANG C W, et al. Analysis of characteristics and sources of acid rain in Shenzhen City[J]. Journal of Soil and Water Conservation, 2007, 29(4):1014-1019(in Chinese).
[20] HUANG Y L, WANG Y L, ZHANG L P. Long-term trend of chemical composition of wet atmospheric precipitation during 1986-2006 at Shenzhen City, China[J]. Atmospheric Environment, 2008, 42:3740-3750. [21] 周志彬, 梁鸿, 马嵩. 深圳市酸雨时空变异特征[J]. 环境科技与管理, 2016, 28(4):65-68. ZHOU Z B,LIANG H,MA S. Temporal and spatial variability of acid rain in Shenzhen[J]. Environmental Technology and Management, 2016, 28(4):65-68(in Chinese).
[22] 杜建飞. 上海酸雨物理化学特征及氮湿沉降研究[D]. 上海:复旦大学, 2012. DU J F. Physical and chemical characters of acid rain and nitrogen wet deposition over Shanghai[D]. Shanghai:Fudan University, 2012(in Chinese). [23] 陈魁, 肖致美, 李鹏, 等. 天津市大气降水化学组分变化趋势及来源研究[J]. 环境科学学报, 2015, 35(4):956-964. CHEN K, XIAO Z M, LI P, et al. Trend and sources of chemical composition of atmospheric precipitation in Tianjin[J]. Journal of Environmental Science, 2015, 35(4):956-964(in Chinese).
[24] XING J W, SONG J M, YUAN H M, et al. Chemical characteristics, deposition ffluxes and source apportionment of precipitation components in the Jiaozhou Bay, North China[J]. Atmospheric Research, 2017, 190:10-20. [25] 余益军, 程钟, 李江, 等. 常州市2014年降水化学组成及来源浅析[J]. 环境化学, 2015, 34(11):2136-2138. YU Y J, CHEN Z, LI J, et al. Chemical composition and sources of precipitation in Changzhou in 2014[J]. Environmental Chemistry, 2015, 34(11):2136-2138(in Chinese).
[26] BALASUBRAMANIAN R, VICTOR T, CHUN N. Chemical and statistical analysis of precipitation in Singapore[J]. Water Air Soil Pollution, 2011, 130:451-456. [27] POSSANZINI M, BUTTINI P, DIPALO V. Characterization of a rural area in terms of dry and wet deposition[J]. Science of the Total Environment, 1988, 74:111-120. [28] 李凤岐, 高会旺. 环境海洋学[M]. 北京:高等教育出版社, 2013. LI F Q, GAO H W. Environmental Oceanography[M]. Beijing:Higher Education Press, 2013(in Chinese). [29] 王珉, 胡敏. 青岛沿海大气气溶胶中氯亏损的研究[J]. 环境科学学报, 2000, 20(9):40-43. WANG M, HU M. Chlorine depletion in atmospheric aerosols off Qingdao coast[J]. Journal of Environmental Science, 2000, 20(9):40-43(in Chinese).
[30] 中国环境监测总站主编. 中国土壤元素背景值[M]. 北京:中国环境科学出版社, 1990. Editor in chief of China Environmental Monitoring Station. Background value of soil elements in China[M]. Beijing:China Environmental Science Press, 1990(in Chinese). [31] XIAO H, XIE L, LONG A, et al. Use of isotopic compositions of nitrate in TSP to identify sources and chemistry in South China Sea[J]. Atmospheric Environment, 2015, 109:70-78. [32] HU G P, BALASUBRAMANIAN R, Wu C D. Chemical characterization of rainwater at Singapore[J]. Chemosphere, 2003, 51(8):747-755. [33] XIAO H, XIAO H, LONG A, et al. Who controls the monthly variations of NH4+ nitrogen isotope composition in precipitation?[J]. Atmospheric Environment, 2012, 54:201-206. -
