纳米Cu2O/珍珠贝壳复合光催化材料的制备与表征

,  ,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

邹晓兰, 朱校斌, 于艳卿, 李超峰, 李红, 王新亭, 周利, 郭书举. 纳米Cu2O/珍珠贝壳复合光催化材料的制备与表征[J]. 环境化学, 2011, 30(8): 1480-1485.
引用本文: 邹晓兰, 朱校斌, 于艳卿, 李超峰, 李红, 王新亭, 周利, 郭书举. 纳米Cu2O/珍珠贝壳复合光催化材料的制备与表征[J]. 环境化学, 2011, 30(8): 1480-1485.
shu
ZOU Xiaolan, ZHU Xiaobin, YU Yanqing, LI Chaofeng, LI Hong, WANG Xinting, ZHOU Li, GUO Shuju. PREPARATION AND CHARACTERIZATION OF NANO-Cu2O/PEARL SHELL COMPOSITE PHOTOCATALYST[J]. Environmental Chemistry, 2011, 30(8): 1480-1485.
Citation: ZOU Xiaolan, ZHU Xiaobin, YU Yanqing, LI Chaofeng, LI Hong, WANG Xinting, ZHOU Li, GUO Shuju. PREPARATION AND CHARACTERIZATION OF NANO-Cu2O/PEARL SHELL COMPOSITE PHOTOCATALYST[J]. Environmental Chemistry, 2011, 30(8): 1480-1485.
shu

纳米Cu2O/珍珠贝壳复合光催化材料的制备与表征

  • 1.

    中国科学院海洋研究所, 青岛, 266071;

  • 2.

    中国科学院研究生院, 北京, 100049

  • 基金项目:

    国家863项目(2006AA06Z362)

    国家海洋局公益性项目(200905021-4)资助.

PREPARATION AND CHARACTERIZATION OF NANO-Cu2O/PEARL SHELL COMPOSITE PHOTOCATALYST

  • 1.

    Institute of Oceanology, Chinese Academy of Sciences, Qingdao, 266071, China;

  • 2.

    Graduate School of Chinese Academy of Sciences, Beijing, 100049, China

  • Fund Project:

  • 摘要: 以煅烧后的珍珠贝壳为载体,采用原位水解法制备出纳米Cu2O/珍珠贝壳复合光催化材料.通过活性大红染料B-3G的脱色实验对光催化材料的活性进行讨论,并采用XRD、SEM、EDS、FT-IR和UV-Vis对材料进行表征.结果表明,以1050 ℃煅烧的珍珠贝壳为载体制备的纳米Cu2O/珍珠贝壳复合材料的光催化活性最强.Cu2O颗粒产率高且呈椭球状,平均粒径为20 nm;水解负载过程中,Cu2O颗粒与珍珠贝壳载体间形成了新的化学键.纳米Cu2O/珍珠贝壳复合材料对紫外光及可见光均有良好的吸收.
    Abstract: Nano-Cu2O/pearl shell composite photocatalysts were prepared through in-situ hydrolysis process with calcined pearl shells as carriers. Photocatalytic activities of these products were investigated by the decolorization of Reactive Red dye B-3G in solutions. These catalysts were characterized by XRD, SEM, EDS, FT-IR and UV-Vis. The experimental results show that the photocatalyst prepared with pearl shells calcined at 1050 ℃ has the highest photocatalytic activity. Loaded Cu2O particles, with an average diameter of 20 nm, are oval in shape. New chemical bonds have formed between Cu2O particles and pearl shell carriers during the in-situ hydrolysis process. Nano-Cu2O /pearl shell composite photocatalyst has good response to both ultraviolet and visible light.
  • 加载中
  • [1] Hara M, Kondo T, Komoda M, et al. Cu2O as a photocatalyst for overall water splitting under visible light irradiation [J]. Chem Commun, 1998, 3:357-358
    [2] Zahmakiran M, Özkar S. Preparation and characterization of zeolite framework stabilized cuprous oxide nanoparticles [J]. Mater Lett, 2009,63(12): 1033-1036
    [3] Kakuta S, Abe T. Photocatalytic activity of Cu2O nanoparticles prepared through novel synthesis method of precursor reduction in the presence of thiosulfate [J]. Solid State Sci, 2009,11(8): 1465-1469
    [4] Reddy K R, Sin B C, Yoo C H, et al. A new one-step synthesis method for coating multi-walled carbon nanotubes with cuprous oxide nanoparticles [J]. Scripta Mater, 2008,58(11):1010-1013
    [5] Yu Y, Ma L L, Huang W Y, et al. Coating MWNTs with Cu2O of different morphology by a polyol process [J]. J Solid State Chem, 2005,178(5):1488-1494
    [6] Ramírez-Ortiz J, Ogura T, Medina-Valtierra J, et al. A catalytic application of Cu2O and CuO films deposited over fiberglass [J]. Appl Surf Sci, 2001,174(34):177-184
    [7] Xu C, Wang X, Yang L, et al. Fabrication of a graphene-cuprous oxide composite [J]. J Solid State Chem, 2009,182(9): 2486-2490
    [8] 姚红霞,嘎日迪,杨保军,等.离子交换法纳米Cu2O的制备及光催化性能的研究 [J]. 分子催化, 2009,23(2):173-176
    [9] Chen J Y, Zhou P J, Li J L, et al. Studies on the photocatalytic performance of cuprous oxide/chitosan [J]. Carbohydr Polym, 2008,72(1): 128-132
    [10] Yeom S H, Jung K Y. Recycling wasted scallop shell as an adsorbent for the removal of phosphate [J]. J Ind Eng Chem, 2009,15(1):40-44
    [11] Currey J D. Mechanical-properties of mother of pearl in tension [J]. Proc R Soc Lond Ser B-Biol Sci, 1977,196(1125):443-463
    [12] 卢欢亮, 王伟.改性钙基吸附剂对垃圾焚烧模拟烟气中镉的吸附研究 [J]. 环境科学学报, 2005,25(8):999-1003
    [13] 李泳,张兆霞,宋文东.以贝壳粉为载体的纳米二氧化钛浸渍方法 . 中国, 200810026525,2009,1,28
    [14] 梅光军,师伟,解科峰,等.纳米氧化亚铜的制备及其光催化性能研究 [J]. 资源环境与工程, 2007,21(3):335-338
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1249
  • HTML全文浏览数:  1233
  • PDF下载数:  408
  • 施引文献:  0
出版历程
  • 收稿日期:  2010-10-11
邹晓兰, 朱校斌, 于艳卿, 李超峰, 李红, 王新亭, 周利, 郭书举. 纳米Cu2O/珍珠贝壳复合光催化材料的制备与表征[J]. 环境化学, 2011, 30(8): 1480-1485.
引用本文: 邹晓兰, 朱校斌, 于艳卿, 李超峰, 李红, 王新亭, 周利, 郭书举. 纳米Cu2O/珍珠贝壳复合光催化材料的制备与表征[J]. 环境化学, 2011, 30(8): 1480-1485.
shu
ZOU Xiaolan, ZHU Xiaobin, YU Yanqing, LI Chaofeng, LI Hong, WANG Xinting, ZHOU Li, GUO Shuju. PREPARATION AND CHARACTERIZATION OF NANO-Cu2O/PEARL SHELL COMPOSITE PHOTOCATALYST[J]. Environmental Chemistry, 2011, 30(8): 1480-1485.
Citation: ZOU Xiaolan, ZHU Xiaobin, YU Yanqing, LI Chaofeng, LI Hong, WANG Xinting, ZHOU Li, GUO Shuju. PREPARATION AND CHARACTERIZATION OF NANO-Cu2O/PEARL SHELL COMPOSITE PHOTOCATALYST[J]. Environmental Chemistry, 2011, 30(8): 1480-1485.
shu

纳米Cu2O/珍珠贝壳复合光催化材料的制备与表征

  • 1.  中国科学院海洋研究所, 青岛, 266071;
  • 2.  中国科学院研究生院, 北京, 100049
  • 收稿日期:  2010-10-11
基金项目:

国家863项目(2006AA06Z362)

国家海洋局公益性项目(200905021-4)资助.

摘要: 以煅烧后的珍珠贝壳为载体,采用原位水解法制备出纳米Cu2O/珍珠贝壳复合光催化材料.通过活性大红染料B-3G的脱色实验对光催化材料的活性进行讨论,并采用XRD、SEM、EDS、FT-IR和UV-Vis对材料进行表征.结果表明,以1050 ℃煅烧的珍珠贝壳为载体制备的纳米Cu2O/珍珠贝壳复合材料的光催化活性最强.Cu2O颗粒产率高且呈椭球状,平均粒径为20 nm;水解负载过程中,Cu2O颗粒与珍珠贝壳载体间形成了新的化学键.纳米Cu2O/珍珠贝壳复合材料对紫外光及可见光均有良好的吸收.
